Anji Tianjian Electrical Technology TJ-311LY Instruction Manual

Sound amplifier

Hide thumbs

Table Of Contents

Instruction Manual

Anji Tianjian Electrical Technology Co，Ltd

Sound amplifier

User Manual

TJ-311LY

Dear users: Please read this manual carefully before you use our sound amplifier TJ-311LY.

Introduction: This product can be used alone, can also be installed in other equipment to use, such as massage chair, seat.

Table of Contents

Need help?

Do you have a question about the TJ-311LY and is the answer not in the manual?

Questions and answers

Summary of Contents for Anji Tianjian Electrical Technology TJ-311LY

Page 1 Sound amplifier User Manual TJ-311LY Dear users: Please read this manual carefully before you use our sound amplifier TJ-311LY. Introduction: This product can be used alone, can also be installed in other equipment to use, such as massage chair, seat.
Page 2 I.Points to note This product is designed and manufactured to ensure personal safety, but it may be dangerous if not used correctly. In order to ensure safety, the following must be observed in the installation: 1, This product should pay attention to moisture proof, waterproof, fireproof. Whether used alone or installed on a device. 2, Please pay attention to maintain good ventilation, the sound net cover should not be blocked, such as newspapers, clothing and other items will hinder ventilation.
Page 3 3. Bluetooth function. III. Performance parameters Model number：TJ-311LY Product voltage：12V Product current：2A Product power：24W Input Voltage of power adapter：100-240V Input Frequency：50-60HZ Input Current：0.8A Output voltage of the power adapter：12V Output Current：2A Maximum size of product components： Net weight：2.3KG Power requirements：AC110-240V 50Hz/60Hz ...
Page 4 damaged. Please pull out the power plug after power off.  When the power supply is connected to this product, the construction shall be configured according to the requirement of greater than total output power. Ambient temperature：-10℃~40℃ Ambient humidity：≤90% Ⅳ、Installation Diagram...
Page 5 1. This product is installed around the ship-shape control box. 2. Note the numbers on the boat shape control box. 3. Insert the cord from the wooden box into the stern of the boat shape control box, the White Jack under number 1. 4.
Page 6 Malfunction phenomenon Serial number Method of elimination Silent, power indicator not on Check the product power plug and power socket is in good contact. Is the electrical outlet correct:AC110-240V 50Hz/60Hz. Check that the musical signal wire connected to the product is in good contact. Silent, power indicator is normal Whether the music supply power is turned on, whether the volume is turned Whether the volume of this product is turned on.
Page 7  The company has the final right to interpret this manual.  Reserves the right to modify the technical rules without prior notice.  This manual is subject to change without prior notice.  If the contents in this user's manual do not conform to your product, please take the material object as the standard. ...
Page 8 FCC Statement FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.
