- Page 1 Kemro OP 350/C-1100 Operating panel Project engineering manual V2.00 Translation of the original instructions...
- Page 2 KEBA GmbH Automation, Leonard-Weiss-Straße 40, D-73037 Göppingen, Tel.: +49 7161 9741-0, Fax: +49 7161 9741-40, E-Mail: keba@keba.com KEBA Corp., 100 West Big Beaver Road, Troy, MI 48084, US, Tel.: +1 248 526-0561, Fax: +1 248 526-0562, E-Mail: usa@keba.com Beijing Austrian KEBA Science and Technology Development Ltd., Room B516, Nan Xin Cang Tower, A22 Dong Si Shi Tiao, Dong Cheng District, Beijing, 100027, P.R.
- Page 3 Record of Revision Record of Revision Version Date Change in chapter Description changed by V1.00 08-2008 Newly created meis V2.00 1-2009 Changes to the general document revision of all OP 3xx operating panels Project engineering manual V2.00 © KEBA 2009...
-
Page 5: Table Of Contents
Connections and wiring....................24 Pin assignment...................... 24 Power supply operating panel (0V | 24V).............. 24 5.2.1 Connection diagram................25 5.2.2 Plug specification................... 25 5.2.3 Cable specification................. 25 Protective earthing....................26 Digital inputs......................26 Project engineering manual V2.00 © KEBA 2009... - Page 6 Mechanical properties................40 11 EC directives and standards..................41 11.1 Operating panel OP 350/C-1100................41 11.1.1 EC Directives..................41 11.1.2 Declaration of conformity................ 42 11.1.3 Standards....................43 11.1.4 Standards for the American market............43 Project engineering manual V2.00 © KEBA 2009...
-
Page 7: Introduction
The operating panel is designed for complex operating tasks in the industrial sector in conjunction with a control of the Kemro K2 product family from the KEBA AG. The typical applications areas include injection molding machines, robots, presses, machine tools. The operating panel may only be used for the applications described here. -
Page 8: Notes On This Document
Hilfe dieser Handbücher ein K2-200 System installieren und EN: 65353 Systemhandbuch warten. Programmierer, die die Maskener- DE: 1000311 Kemro.view.standard K2-beans stellung für das Bedienpanel und die Tastenauswertung auf der Steuer- EN: 1000315 Programmierhandbuch ung realisieren. Project engineering manual V2.00 © KEBA 2009... - Page 9 Operating panel Introduction Dok.Nr. Bezeichnung Zielgruppe DE: 1000193 Kemro.view.standard Visualisierung EN: 1000197 Schulungsunterlagen DE: 1000113 Kemro.view.standard Visualisierung EN: 1000123 Benutzerhandbuch DE: 1000114 Kemro.view.standard Visualisierung EN: 1000196 Installationshandbuch DE: 1000441 Kemro.view.standard Visualisierung EN: 1000475 Programmierhandbuch Project engineering manual V2.00 © KEBA 2009...
-
Page 10: Safety Notes
The following areas of application for the operating panel are expressly forbid- den: ● Use in areas where there is a risk of explosion or fire ● Use in the mining sector ● Use in the open air Project engineering manual V2.00 © KEBA 2009... -
Page 11: Safety Instructions For Personal Safety
In principle, the operating panel may not be opened since this results in loss of the warranty. Exception: Excluded from this is maintenance work that is expressly allowed by KEBA. Any other manipulations to the operating panel will also result in loss of warranty. -
Page 12: Operating Panel Description
The visualization on the control is realized by kemro.view.standard (no visu- alization runtime system on the operating panel required). Operating panel enhancements The range of functions of an operating panel can be enhanced with the KEBA components listed below. Separate manuals are available for these compo- nents. -
Page 13: Front View
... 12.1'' TFT display (256,000 colors, SVGA, 800 x 600 pixel) with touch screen Description Button which can be labeled using labeling strips. Button with red LED that can be labeled using labeling strips. Project engineering manual V2.00 © KEBA 2009... -
Page 14: Rear View
Device layout on the operating panel back side (shown without wiring) ... DIP switch for the address setting of the ... Slots for button labeling using labeling operating panel strips ... Ground bolt for protective earthing Project engineering manual V2.00 © KEBA 2009... -
Page 15: Device Dimensions
Keypad and LED assignment The following image shows the assignment of the KEY- and LED-Codes on the keypad. The KEY- and/or LED-Code is required to activate the keys and LEDs through the software. Project engineering manual V2.00 © KEBA 2009... -
Page 16: Power-Led
Internal error → Contact serv- flashing slowly (2 s period du- Connection to the touch con- ration) troller failed. ice technician Internal error → Contact serv- flashing quickly (1 s period du- Touch defect ration) ice technician Project engineering manual V2.00 © KEBA 2009... -
Page 17: Status Led (Operating Panel Back Side)
White drawing film is best suited for button labeling which can be provided with the desired icons in the specified visibility field. For the labelling strips, we recommend the following materials from Folex: Project engineering manual V2.00 © KEBA 2009... - Page 18 Once the paper strip is completely inserted, the film is removed again. We recommend a paper with 160 g/m², however, no inserting aid may be used here. Fig.3-7: Arrangement of the labeling strips Project engineering manual V2.00 © KEBA 2009...
-
Page 19: Ordering Information
Operating panel Operating panel description Fig.3-8: Dimensions of the labeling strips (specifications in mm) Ordering information 3.6.1 Ordering information legend Abbreviation Significance Operating panel (Operating Panel) CPU module of the Kemro K2 control Project engineering manual V2.00 © KEBA 2009... -
Page 20: Operating Panel
72262 such as toggle switches etc. For OP power supply 2-pole plug 67613 (0V | 24V DC) ● 20-pole female con- nector and Plug set XT 120/A 72236 ● 2-pole plug Project engineering manual V2.00 © KEBA 2009... -
Page 21: Mounting And Installation Instructions
Space requirement Please see the device dimensions for the space requirement to the rear (= installation depth). The following dimensions are recommended for the mount- ing holes and the opening of the operating panel. Project engineering manual V2.00 © KEBA 2009... -
Page 22: Mounting The Operating Panel
Risk of injury when mounting the operating panel! ● When screwing on the operating panel, observe that it is well fastened and does not tilt forward out of the mounting opening. The operating pane is not completely mounted. Project engineering manual V2.00 © KEBA 2009... -
Page 23: Removing The Operating Panel
To ensure protection type IP54 (front side), the back side of the operating panel must be fitted with a seal (not included in the delivery of KEBA). The operating panel with seal must be installed flush on the mounting surface. -
Page 24: Connections And Wiring
PL..Graphics: Graphics interface for the control The interface cables that can be ordered from KEBA are in the chapter 3.6 "Ordering information" on page 19 for further information. Power supply operating panel (0V | 24V) The operating panel is supplied by 24 V DC. -
Page 25: Connection Diagram
3.6.3.2 "Connector" on page 5.2.3 Cable specification Cable type: Unshielded cable Cross-section The actual permissible wire cross-section is specified by the electrical condi- tions of the connected equipment an the female connectors used: Project engineering manual V2.00 © KEBA 2009... -
Page 26: Protective Earthing
For such cases, use the conforming digital inputs of the control. Information For the selection of the switching elements, the chapter 10 "Technical data" on page 39 specifications in section "Digital inputs" are to be taken into account. Project engineering manual V2.00 © KEBA 2009... -
Page 27: Plug Specification
0.13 mm² min. with wire sleeves according to DIN 46 228/1, 0.34 mm² max. with AEH with collar DIN 46 228/4, min. 0.13 mm² with AEH with collar DIN 46 228/4, max. 0.34 mm² Project engineering manual V2.00 © KEBA 2009... -
Page 28: Cable Specification
An addressing occurs via the DIP switches 1 and 2 on the back side of the operating panel. The operating panel used the address 0x10h in the delivery state. Other devices connected to this interface cannot be operated with this address. Project engineering manual V2.00 © KEBA 2009... -
Page 29: Cable Specification
Cable type: shielded, twisted pair data cables with a characteristic impedance of 100 - 120 Ω. The connector casing must be completely conductive. The cable shielding must connect surface-to-surface with the shield cover of the plug. Project engineering manual V2.00 © KEBA 2009... -
Page 30: Usb Module Supply (Vcc-Usb)
USB module XE 010/x is already connected to the operating panel and to the USB module in the delivery state. 5.7.1 Cable specification The supply cable is also available as replacement part, see chapter 3.6.1 "Ordering information" on page Project engineering manual V2.00 © KEBA 2009... -
Page 31: Graphic Interface (Graphics)
The graphic interface Graphics (15-pole DSUB female connector) is used to connect the operating panel via a connection cable XW 041-xxx to the control. 5.8.1 Cable specification Only cables from KEBA are to be used. Connecting cable, type: XW 041-xxx (graphic/RS-485-A cable). Ordering data, see chapter 3.6.3.2 "Connector" on page 5.8.1.1... - Page 32 Connections and wiring OP 350/C-1100 Information Only cables recommended by KEBA may be used! These cables are availa- ble in different lengths (order numbers, see chapter 3.6.1 "Ordering infor- mation" on page 19). Project engineering manual V2.00 © KEBA 2009...
-
Page 33: Configuration
The DIP switch setting printed in bold depict the delivery state. DIP-Switch Function 1=OFF, 2=OFF 1=OFF, 2=ON 1=ON, 2=OFF 1=ON, 2=ON no meaning 6=ON Terminating resistor for RS-485-A interface running Project engineering manual V2.00 © KEBA 2009... -
Page 34: Operation And Handling
Software No application has been stored in the operating panel. It is activated directly through the control system. The device will not trigger any error messages. It is possible to perform firmware updates. Project engineering manual V2.00 © KEBA 2009... -
Page 35: Programmierhinweise
● Eine Applikation für verschiedene Bediengeräte ● Umfangreiche Service- und Diagnosefunktionen ● Mächtige Standard-Systemfunktionen ● Optimierte Touch-Bedienung ● Online-Einheitenumschaltung ● Integrierte Hardcopy-Funktionalität ● Flexibles Online-Hilfesystem auf HTML-Basis ● Intuitive, grafische Ablaufprogrammierung ● Programmierschnittstelle für Kundenerweiterungen Project engineering manual V2.00 © KEBA 2009... -
Page 36: Maintenance
KEBA for repair. Packaging, shipment The device is wrapped into protective packaging material for shipment. For reasons of environmental protection KEBA appreciates receiving the original packaging material for multiple use. The protective packaging does not qualify as adequate transport packaging and hence is not suited for transportation via carrier haulage or airplane. - Page 37 Operating panel Maintenance Exception 40 percent sodium hydroxide causes slight white discolorations. Project engineering manual V2.00 © KEBA 2009...
-
Page 38: Operating Panel Disposal
● The materials are recyclable in accordance with their labeling. You can make an important contribution to protecting our environment by reusing, renewing and recycling materials and old appliances. Project engineering manual V2.00 © KEBA 2009... -
Page 39: 10 Technical Data
24 V DC Applied contact current: 5 mA (supply exclusively by Vout) Galvanic isolation: Status display: None Min. update cycle: 60 ms 10.1.4 Interfaces Serial interface: ● Type: RS-485-A ● Baud rate: 115 kbit/s Project engineering manual V2.00 © KEBA 2009... -
Page 40: Mechanical Properties
External dimensions: ● Width: 335 mm ● Height: 450 mm ● Depth: 50.6 mm Front: ● Front plate: Aluminium ● Decor film: Polyester ● Seal: Circumferential round cord Housing: Metal Weight: 3.5 kg Project engineering manual V2.00 © KEBA 2009... -
Page 41: 11 Ec Directives And Standards
Operating panel OP 350/C-1100 11.1.1 EC Directives Guideline 2004/108/ EC directive on the electromagnetic compatibility Information This product was developed for the use in industrial areas and can cause radio interference when used in residential areas. Project engineering manual V2.00 © KEBA 2009... -
Page 42: Declaration Of Conformity
EC directives and standards OP 350/C-1100 11.1.2 Declaration of conformity Project engineering manual V2.00 © KEBA 2009... -
Page 43: Standards
8). 11.1.4 Standards for the American market For the American market, the following standard was also taken into account: 11.1.4.1 UL test for industrial control equipment UL 508, 2001 Industrial Control Equipment Project engineering manual V2.00 © KEBA 2009...
