  • Page 1 CINEO C1030 Mass Coin Recycling System Installation (January 2015)
  • Page 2 All product names mentioned in this document are registered trademarks. Copyright © Wincor Nixdorf International GmbH, 2015 All rights including the rights to the translation, reprinting, and transmission or copying by any means, in whole or in part, are reserved. Offenders will be liable for damages. All rights including rights resulting from a patent grant or registration of a utility or design are reserved.

  • Page 3: Table Of Contents

    Tools you need ........................... 7 Requirements ..........................8 Components ..........................9 Hopper ..........................10 Installing the CINEO C1030 in the Store ................... 11 Removing the Transportation Locks ..................11 Safety Feature Conveyer Unit .................... 18 Connecting the CINEO C1030 ....................22 Start up ..........................
  • Page 4 Recycling the CINEO C1030 ....................30...

  • Page 5: Introduction

    Spare Parts Introduction With the CINEO C1030 Wincor Nixdorf offers an entry-level model for coin processing in cash offices. This system processes up to 8 coin denominations and recycles them. Thus, coins are available again for dispensing. Capacity per denomination averages 1,200 coins (based on the 1 €...

  • Page 6: Warranty

     discrepancies between package contents and delivery ticket or  functional defects, please inform your contracting parties or the branch office of Wincor Nixdorf immediately. Please indicate the number of your delivery ticket and delivery ticket position and serial number of the respective device.

  • Page 7: Setting Up The Device

    Sketch of the Installation Area Setting Up the Device Install the CINEO C1030 into an environment without extremly conditions. The device should be placed on a level ground. Avoid vibrations, dust, moisture, heat and strong magnetic fields. Sketch of the Installation Area...

  • Page 8: Esd (Electrostatic Sensitive Devices)

    ESD (Electrostatic Sensitive Devices) Electrostatic sensitive devices (ESD) may be marked with this sticker. When you handle components fitted with ESDs, you must observe the following points under all circumstances:  Unplug the power before inserting or removing components containing ESDs. ...

  • Page 9: Important Notes

     Make sure that no objects (such as paper clips) can reach the interior of the device, since electrical shocks or short-circuits could result.  To avoid overheating of the power supply unit ensure that the CINEO C1030 receives adequate ventilation.

  • Page 10: Connecting Peripherals

     CINEO C1030 is the result of state-of-the-art technology. Therefore, please also ensure that the CINEO C1030 is operated under modern building and technical conditions in order to ensure flawless and efficient operation.

  • Page 11: Tools You Need

    Tools you need Tools you need Keep the following tools at hand for working on the CINEO C1030: Socket wrench 7 mm (blind screen device front and compartment front) Open-end wrench 30 mm Allen screw H6 (to remove the C1030 from the palett) Flathead screwdrivers (two sizes) e.g.

  • Page 12: Requirements

    • Provision of storage or service as required. • Provision of a level floor to locate the CINEO C1030. The system has to be stable and must not tilt. The maximum incline must not exceed 2%. The feet of the unit can overcome a height difference of up to 10 mm.

  • Page 13: Components

    Components Components Pole Light Coin Input Card Reader Receipt Printer TH230+ Display BA92 Lock Lock RejectedCoins Cash Drawer CIT Box CIT Reject Coins Overflow...

  • Page 14: Hopper

    Removing the Transpotation Locks Hopper Switch off the device befor removing a hopper. Otherwise damages may occur. Set the hopper always to the same position as installed before. The hopper must be set as shown in the picture below. The label must be visible from outside.

  • Page 15: Installing The Cineo C1030 In The Store

    Removing the Transpotation Locks Installing the CINEO C1030 in the Store The CINEO C1030 will be delivered on a pallet with a size in industry standard 800 mm x 1200 mm. Caution! Always wear safety gloves and safety shoes with steel toe caps while transporting heavy appliances.
  • Page 16 Removing the Transpotation Locks Remove foils and foam material. Do not unwrap the pole light! Keep packed...
  • Page 17 Removing the Transpotation Locks Remove 3 screws with a Tx 20 screwdriver and release the transportation lock on the bottom drawer. Pick up the keys for the CINEO C1030 in the bottom drawer.
  • Page 18 Removing the Transpotation Locks Push the second pallet (scope of delivery) in front of the CINEO C1030 as shown in the picture below. Second Pallet Unlock the CINEO C1030…. Pull out the carrier completely.
  • Page 19 Removing the Transpotation Locks Remove two black transport locks at the bottom of the CINEO C1030. Two Transport Locks...
  • Page 20 Removing the Transpotation Locks Remove two transport locks with a Tx20 screwdriver in the carrier nearby the cash tray. Remove the four Inbus screws at the bottom of the CINEO C1030 which fixes the device at the pallet. Push in the carrier completely, close the CINEO C1030 and lock it.
  • Page 21 Removing the Transpotation Locks Now unlock the CINEO C1030 again and pull out the carrier completely. Remove the red transport locks shown in the picture below. Remove four screws of the transportation lock in the back of the CINEO C1030.

  • Page 22: Safety Feature Conveyer Unit

    Removing the Transpotation Locks To pull out the unit you must hold it on the green levers only. Safety Feature Conveyer Unit For all works on the conveyer and behind it (as with the BEETLE /S-II) secure it in its position. Being pulled out, the safety lock is in position shown below.
  • Page 23 Removing the Transpotation Locks Close the locking upwards and the conveyer is fixed in place for safe working. Safety Locking fixed Remove four screws at the back of the transportation lock and release it.
  • Page 24 Removing the Transpotation Locks Remove the first two hopper at each side of the CINEO C1030. Release the transport locks (see arrow) on both sides with a Tx 10 screwdriver. To prevent damages to the device mount the two hopper in their original position again.
  • Page 25 Removing the Transpotation Locks …and install it with one screw.

  • Page 26: Connecting The Cineo C1030

    Power Connection and LAN Support The CINEO C1030 supports Ethernet 10/100 BASE-T local area network (LAN) communication protocol. The CINEO C1030 provides a female RJ-45 connection port for the LAN. LAN and power supply will be connected at the back side of the device.

  • Page 27: Disconnecting The System From The Mains

     Plug the power plug to the house installation.  Plug in the power and the LAN cable (optional).  Unlock and open the front door of the CINEO C1030.  Push the button at the power distributor to position 1 and the systems starts up.

  • Page 28: Appendix

    Appendix Appendix Dimensions...

  • Page 29: Block Diagram

    Appendix Block Diagram Find a A3-Block Diagram to print out for better visibility on the WN Internet:...

  • Page 30: Technical Data

    Appendix Technical Data Supply Voltage Range 110 – 120 V; 220 – 240 V Nominal Frequency 50/60 Hz Data Transmission Port V.24 Dimensions (H x W x D) 1,274 mm x 750 mm x 530 mm Weight: without coins approx. 390 kg Current Consumption Standby (EPC, Cash Module) 350 mA, 67 W...

  • Page 31: Further Documentation

    System’s Housing Clean the housing of the CINEO C1030 with a vacuum cleaner or cloth. Eliminate damage to paint, if necessary and possible.

  • Page 32: Approved Cleaning Materials

    Appendix Approved Cleaning Materials The items listed below can be ordered from Wincor Nixdorf branch office or your Wincor Nixdorf sales partner. Product Name Order Number Explanations Professionell cleaning set for 01750097335 For cleaning and maintaining EDP devices keyboards and varnished and...

  • Page 33: Certificates

    Therefore, you will find the CE mark on the device or on its packaging. Tested Safety In addition, the CINEO C1030 has received the UL symbol and cUL symbol. FCC-Class A Declaration This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 34 CINEO C1030 was designed according to the Wincor Nixdorf standard “Environmentally Conscious Product Design and Development”. CINEO C1030 is manufactured without the use of CFCs and CCHs and is manufactured to a great extent out of materials and components which are recyclable.
  • Page 35 Wincor Nixdorf International GmbH D-33094 Paderborn Order No.: 01750264336A...
