AS W2 0 0

Mask

Vending Machine

User Guide

Th ank y ou fo r choo s i ng TOP VME .

Table of Contents

Need help?

Do you have a question about the ASW200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Top ASW200

Page 1 AS W2 0 0 Mask Vending Machine User Guide Th ank y ou fo r choo s i ng TOP VME .
Page 3: Table Of Contents
C o n t e n t 1. Introduction ........................1 1-1. Overview........................1 1-2. Features ......................... 1 2. Specifications......................... 2 2-1. General .......................... 2 2-2.Electronic ........................2 2-3.Mechanical ........................2 3. Content ........................... 2 4. Dimensions ........................3 5. Main Control Board .....................4 5-1.
Page 4: Introduction
The management system uses an online mode to know real-time when the unit needs replenishment, current transaction amounts and errors. 1-2. Features ASW200 ASW210 ASW230 ASW250 Convenient refill...
Page 5: Specifications
Consumption (ASW250) Standby:15.4W Working:25.3W Max.:29.7W Temperature range indoor 2-3.Mechanical ASW200 : 117 KG ASW210 : 117.5 KG Weight ASW230 : 119.5 KG ASW250 : 119.5 KG Average weight ± 5% Dimension 1941 X 813 X 380 mm ( ± 5mm ) Screen Size 21.5-inch Product display window/...
Page 6: Dimensions
ASW2 Series 4. Dimensions Unit : mm [ inch ] 813 32.01 380 14.96 R3 0.12 R6 0.24 355.5 14.00 10 0.39...
Page 7: Main Control Board
Mask Vending Machine 5. Main Control Board Main screen digital display 上目倉倉倉一道道道頁錄一二三 5-1. Key Function (L) - Previous page: Use to enter menu settings and return to the previous page.
Page 8: Display
ASW2 Series 5-2. Display Main Screen number: Display the total qty on the vending machine Amount: Number of stock (ASW200、ASW210、ASW230) Price: Set the selling price. Motor: Lever rotation test. Home: Position the lever, must have stock on the shelves Muti: Set pulse multiplier (ASW230、ASW250) Sen: Test all switches except the door open switch, Shelves must be empty 5-3.
Page 9: Setting Price
Mask Vending Machine 5-4. Setting Price 1. Press (M) twice to display Price 2. Press (C1) once to display P1 001, keep pressing (C1) repeatedly to increase the value for CH1. Press (N) to decrease the value. 3. Press (C2) once to display P2 001, keep pressing (C2) repeatedly to increase the value for CH2.
Page 10: Lever Position
ASW2 Series 5-6. Lever Position Minimum of 2 products need to be placed on each shelf 1. Press (M) four times to display Home 2. Press (C1) once and rail 1 will dispense one product. 3. Press (C2) once and rail 2 will dispense one product. 4.
Page 11: Description
Easy card Coin Acceptor NHI card ASW230 Bill Acceptor ASW250 Remaining quantity display Bill Acceptor 1. Speakers (Except model ASW250) 2. 21.5inch high-resolution monitor (ASW200、210、230) /Product display window (ASW250) 3. Buttons (ASW230、250) 4. Payment module 5. Lock 6. Pick up tray...
Page 12: Fixing Machine To A Wall
ASW2 Series 6-1. Fixing Machine to a wall Hole position (We recommend using 8mm outer diameter anchor bolts) 1. Drill holes according to the recommended size and following the length of bolts used. 2. Insert the anchor bolt into the drilled places and use a rubber hammer to insert into place 3.
Page 13: Machine Feet
Mask Vending Machine 6-2. Machine Feet Nut A Nut B Fixed position Fixed position 1. After placing the unit in the desired position, turn the fixed feet until they have contact to the ground. 2. Use a wrench to tighten nut A. 3.
Page 14: Asw250Product Display Window
ASW2 Series 2. If the breaker jumper is triggered, always make sure what is causing it before returning the machine back to work. 3. If the motherboard needs replacing, always turn off the control board switch first. 6-4. ASW250Product Display Window Replaceable products 1.
Page 15: Locks
Mask Vending Machine 6-5. Locks 1. Insert the key and turn 90 degrees to the right. 2. The lock will automatically pop up. Turn the lock 90 degrees to the right.
Page 16: Power Cable
6-6. Power Cable For shipping, the power cord will be placed inside the unit. Please loosen the three screws on the A plate and remove the power cord and tighten the plate back into place. 7. Troubleshooting Display Description Corrective action Goods out of place, not pressing on Channel Jam Reposition the goods...
Page 17 Taiwan Top Vending Machine Electronics Co., Ltd. NO.11, Anzhong St., Luzhu Dist., Taoyuan City338, Taiwan, (R.O.C.) Phone : +886-3-3115969．Fax : +886-3-3115970 E-mail : sales@topvme.com.tw Website : www.topvme.com...
Page 18 Top Vending Machine Electronics Co., Ltd. w w w .topv me .co m...
