- Page 1 LM6 SUBMERSIBLE TRANSMITTER INSTALLATION AND OPERATING MANUAL WINTERS INSTRUMENTS www.winters.com MANUFACTURER OF INDUSTRIAL INSTRUMENTATION...
- Page 2 LM6 Installation, Operation Manual Description and Features: • Designed for continuous level measurement in water or other liquids with low viscosity • 316L SS probe with stainless steel sensor for ease of cleaning • Available ranges from H2O up to 300 psi •...
-
Page 3: General Information
This operating manual is copyrighted. The contents of this operating manual reflect the version available at the time of printing. It has been issued to our best knowledge. However, errors may have occurred. Winters Instruments is not liable for any incorrect statements and their effects. -
Page 4: Product Identification
The probes have been developed for continuous level measurement. It is the operator's respon-sibility to check and verify the suitability of the de-vice for the intended application. If any doubts remain, please contact our sales department in order to ensure proper usage. Winters Instruments is not liable for any incorrect selections and their effects! Permissible media are gases or liquids, specified in the data sheet. - Page 5 LM6 Installation, Operation Manual Place the protective cap on the pressure port again immediately after disassembling. Handle the unprotected diaphragm very carefully - it is very sensitive and may be easily damaged. Do not use any force when installing the device to prevent damage of the device and the plant! When placing the device into operation or after maintenance work, the probe has to be submerged slowly into the medium! A rough immersion into the medium can damage or destroy the diaphragm.
- Page 6 LM6 Installation, Operation Manual Establish the electrical connection of the device according to the technical data shown on the manufacturing label, the following table and the wiring diagram. Wiring Diagram Pin Configuration Electrical Connection Cable Colours (DIN 47100) Supply+ White...
-
Page 7: Initial Start-Up
If the diaphragm is calcified, it is recommended to send the device to Winters Instruments for decalcification. Please read therefore the chapter “Service / Repair” below. -
Page 8: Service / Repair
Please inform us by sending an email to: return@bdsensors.de. Include the number of devices sent and request a RMA. Then clean the device and pack it shatterproof before send it to Winters Instruments indicating the RMA. Disposal... - Page 9 WINTERS INSTRUMENTS Tel: 1-800-WINTERS / www.winters.com...
- Page 10 WINTERS INSTRUMENTS MANUFACTURER OF INDUSTRIAL INSTRUMENTATION Winters Instruments is a global manufacturer of premium quality pressure and temperature instrumentation, with distribution partners in over 90 countries. Please contact us for your nearest Regional Manager. Corporate - Canada Canada - Calgary...
