Product Specifications
HARDWARE
Smoke Sensitivity
Protection
Requirements
Supply Voltage
Operating
Temperature & Humidity
Cables
DESCRIPTION
Detects smoke in the local environment. Use in conjunction with
ZPE 4-Channel Relay and 8-Channel GPIO Modules (USB-powered).
Sends notification when the detector is triggered and remotely powers off.
Control and read status with CLI, WebUI, SNMP, or Restful APIs.
We suggest placing
this product here
*Rack cage may be a different model or size.
FOR MOUNTING
a. Detach base from unit.
b. Mount base with screws, top down and parallel
to the ground.
c. Reattach top cover.
ASSEMBLED IN THE USA
ZPESYSTEMS.COM
+1.844.4ZPESYS
All rights reserved.
September 8, 2022
ZPE-SMK-U01
Complies with EN 54-7:2000+ A1:2002
IP30 Ingress
ZPE-IO8-U01 & ZPE-RL4-U01
SOLD SEPARATELY
Must be installed to the Nodegrid environment
prior to setting up Smoke Detector
12V with USB Adapter
-10º to 55° C (14º to 131º F)
93±3% at 40° C (104º F)
Relay & Power
Relay & Power Extension: 4 meters (13 feet)
IO Extension Cable: 4 meters (13 feet)
USB Adapter: 1 meter (3.33 feet)
Quick Install Guide
Smoke Detector (USB)
ZPE-SMK-U01
COMPATIBLE WITH
ALL NODEGRID DEVICES
ZPESYSTEMS.COM
Advertisement
Summary of Contents for ZPE ZPE-SMK-U01
- Page 1 DESCRIPTION Detects smoke in the local environment. Use in conjunction with ZPE 4-Channel Relay and 8-Channel GPIO Modules (USB-powered). Sends notification when the detector is triggered and remotely powers off. Control and read status with CLI, WebUI, SNMP, or Restful APIs.
- Page 2 "Sensor Quick Install Guide" section at: Cable zpesystems.com/user-manuals/ 4-Channel RR Loc OPTIONAL: To configure data collection in Relay ZPE Data Lake, refer to Appendix C in the latest Module FR Loc ZPE Cloud Manual at: Smo e ZPE-RL4-U01 zpesystems.com/user-manuals/ Smo e...
