Sony ILCE-6500 Service Manual
Interchangeable lens digital camera
Hide thumbs
Also See for ILCE-6500:
- Manual (413 pages) ,
- Service manual (75 pages) ,
- Help manual (585 pages)
Table of Contents
Advertisement
Quick Links
SERVICE MANUAL
Ver. 1.0 2016.11
SERVICE NOTE (Check the following note before the service.)
– ENGLISH –
1-1.
PRECAUTION ON REPLACING THE SY-1077 BOARD
1-2.
PRECAUTION FOR REPLACEMENT OF IMAGER
1-3.
CHECKING THE Wi-Fi FUNCTION
– JAPANESE –
1-1. SY-1077基板交換時の注意
1-2. イメージャ交換時の注意
1-3. Wi-Fi機能の確認
INTERCHANGEABLE LENS DIGITAL CAMERA
The components identified
Les composants identifiés par
by mark 0 or dotted line with
une marque 0 sont critiques
mark 0 are critical for safety.
pour la sécurité.
Replace only with part number
Ne les remplacer que par une
specified.
pièce portant le numéro spécifié.
ILCE-6500_L2
9-896-798-31
ILCE-6500
2
LEVEL
US Model
Canadian Model
AEP Model
UK Model
Russian Model
E Model
Indian Model
Australian Model
Chinese Model
Korea Model
Japanese Model
Tourist Model
Sony Corporation
Revision History
Ver.
Date
History
1.0
2016.11
Official Release
989679831.pdf
S.M. Rev.
Contents
issued
—
—
2016K08-1
© 2016.11
Published by Sony Techno Create Corporation
