- Page 1 XOU24BWDDGO I worked really hard on this manual - PANEL READY FRENCH DOOR COMBO so please read it...
- Page 2 UNDERCOUNTER When buying any XO appliance, you can be con you have chosen a high quality, innovative and stylish product from a company that cares about you! If you require service or have questions, there are 2 ways to contact our ventilation experts;...
-
Page 3: Where Things Are
where things are 4 - 7 Before You Get Started Installer Checklist Find Your Model Safet y Instructions Electrical and Grounding Instructions 8 - 1 3 Installation Instruc tions Sizes and Installation Dimensions Integrated Panel Dimensions Leveling Your XO 14 - 19 O p erating Instruc tions Control System Over view Set ting the Temperature... - Page 4 the job isn’t done until To ensure that the installation process is successfully completed, here are few things to review... Is the unit plugged in? Are the controls on? (Panel will illuminate.) Are the controls operating correctly? Has the unit been properly leveled - both side to side and front to back - with all 4 leveling feet securely making contact with the floor? If it is an OVERLAY unit - have the panels been securely attached and properly aligned? After installation, does the door open sufficiently to fully extend the shelves?
- Page 5 BEVERAGE CENTER | WINE COOLER COMBO XOU24BWDDGO record your serial number here in case you need it later...
- Page 6 your safety matters Pl ease re ad t hro ugh compl etely befo re using yo ur XO Unit To prevent damage to the door gasket, the door must be opened all the way before pulling shelves out. The appliance must be positioned so that the plug is accessible. Empty your XO unit before attempting to move the appliance.
- Page 7 Failure To Fo llow All El ec trical Safet y M easures M ay Re sult in Serious Injur y, Fire Or Deat h All electrical work should only be performed by an INDOOR USE ONLY: experienced, licensed electrician. XO Refrigerators, wine cellars and beverage All XO units MUST be grounded for safe operation centers described in this manual are rated for come equipped with a 3 Prong molded cord/plug for that...
- Page 8 a perfect fit use free standing - or - install under counter ALL XO UNDERCOUNTER UNITS ARRIVE PRE-WIRED WITH LOW PROFILE PLUGS FOR EASY INSTALLATION 35 1/4” MAX 34 1/8” MIN 7" 4" 24” WHEN INSTALLING WITH THE HINGE SIDE NEXT TO A WALL - LEAVE ADEQUITE SPACE FOR CABINET HANDLES 90°...
- Page 9 ( or small, as the case would be height & width XOU24BWDDGO 24” COMBO 1/8” HIGH 23 7/8” WIDE depth MODELS WITH OVERLAY DOORS DOOR MUST BE ABLE TO OPEN 90 MINIMUM...
- Page 10 11 5/8” (295.5MM) 3 1/4” (82.5mm) min 29 3/4” GLASS CANNOT BE COVERED (756mm) BY A FULL PANEL 30” (762mm) max* * IF FRAME HEIGHT EXCEEDS 30” ADDITIONAL STEPS ARE REQUIRED. 2 7/8” 2 7/8” (73mm)
- Page 11 let’s face it 8) screw attachment 3. Before the frame has been mounted to the door; attach your handle hardware, at the height of your choosing, drill counter sunk screw holes to align with your handle to help ensure the panel lies flat.
- Page 12 7. Drill the handle attachment holes for the fasteners through the frame (from step 3). 8. Remove the clamps (and/or tape) 9. Attach your handle using flat head or truss head bolts. 10. Re-install the rubber gasket by pressing it into the slot making sure it is evenly seated and flat.
- Page 13 it’s like zen - but cooler get your level out DO NOT NEGLECT THIS IMPORTANT STEP Rotate to raise or lower the LEVELING LEGS located at each of the four corners until all four legs are seated firmly on the floor and the interior floor of the unit is level both front to back and side to side.
- Page 14 XOU24BWDDGO COMBO BEVERAGE CENTER | WINE COOLER INDIVIDUAL CONTROL PANELS INDEPENDENT CARBON ELEMENTS INDEPENDENT COOLING FANS SIX GLIDING TWO GLIDING WINE RACKS GLASS SHELVES INDIVIDUAL DOOR LOCKS FRONT COOLING VENTS LEVELING LEGS...
-
Page 15: Take Control
take control temperature Your Combo Beverage Center |Wine Cooler has two identical control panels. Single Zone Wine Cooler Temp. Settings Beverage Center Temp. Settings Factory Preset: 54 F (Ideal Storage) Factory Preset: 43 F Adjustable Range: 41 F to 64 F Adjustable Range: 34 F to 50 F Your Combo Beverage Center |Wine Cooler remembers your temperature setting in case of a power failure and automatically adjusts to the previous setting when power is restored. - Page 16 take control continued colors! Wh en you turn your combo unit on, the interior light is wh ite, press and the light will ch ange to blue. Press again and the light will ch ange to amber. switching modes When you turn your XO Unit on, it is set to work in standard mode. Press ECO mode is turned on.
- Page 17 single zone control combo beverage center | wine coolers ON /OFF But ton Press & Hold for 1 Second to turn ON Press & Hold for 3 Seconds to turn OFF Press to Silence Alarm Light Function But ton Toggle Bet ween 3 Light Functions L1, L2, L3 Indicator Light TEMPER ATURE D ISPL AY...
- Page 18 how many... The capacity of your Beverage Center Side is: The capacity of your Wine Cooler Side is: Top Shelf 20 Cans (double stacked) per Rack 3 Bordeaux Bottles (750ml) Lower Shelf 10 Cans # of Racks x 6 Racks Bottom 19 Cans Bottom...
- Page 19 juggling space is easy with xo STEP 1: Remove the shelf FULLY EX TEND LIFT SHELF LIFT THE PULL OUT STEP 2: Remove and re -position the shelf glides FRONT STRAIGHT REAR SHELF FRONT SHELF REAR SHELF FRONT SHELF GLIDE SUPPORT GLIDE SUPPORT GLIDE SUPPORT GLIDE SUPPORT...
-
Page 20: Energy Savi Ng Ti P
a little tlc goes a long way C l e a ni ng t h e In si d e: Walls, floor, inside window, and shelves - Some water deposits and dust can be removed with a dry paper towel, others may require a damp cloth. C l e ani ng t h e Ou t s i d e: Outer case - It is important to keep the area clean where the door seals against the cabinet. - Page 21 a breathe of fresh air for best results change every 3 to 6 months Your Air Refresh Ch arcoal Filter s Located H ere P/N: XOUAIRFILTER Rotate th e filter 1/4 turn to un lock Pull straight out to remove Align the t abs and inser t the new filter Rotate filter 1/4 turn...
- Page 22 faq’s There doesn’t appear to be any power to the unit. There are 3 easy to check common causes: (1) Check to see if a fuse has blown or circuit breaker has tripped & replace or reset. (2) Check to ensure the plug is fully inserted into the outlet. (3) A power surge may have caused the unit to shut down to protect itself - Unplug the unit, wait 5 seconds and plug it back in.
-
Page 23: Warranty
we’ve got your back 90 DAY LOVE IT or LEAVE IT. For 90 Days all our products are backed by our unique Love it or Leave it Guarantee. TWO-YEAR PARTS & LABOR LIMITED WARRANTY. XO warrants to the original purchaser of every new XO refrigerated unit, the cabinet and all parts thereof, to be free from defects in material or workmanship under normal and proper use and maintenance as specified by XO and upon proper installation and start-up in accordance with the instruction packet supplied with each XO unit. - Page 24 XO APPLIANCE ROSELAND , N J 07068 24 EISENHOWER PARKWAY WWW.XOAPPLIANCE.COM P. 973.403.8900...
