Summary of Contents for heimgard Indoor 360
- Page 1 Indoor 360° camera 2 Requires a Heimgard smart home...
-
Page 2: What Is In The Box
What is in the box A. Camera B. Micro USB power cable C. EU USB power adapter D. Screws & wall anchors E. Mounting bracket F. Positioning map For wall mounting, you will also need electric drill, as well as a twist drill bit when using wall anchors. -
Page 3: Device Overview
Device overview LED-indicator Camera lens Join / reset button Ethernet port Power input To locate the reset button (I), gently slide the camera lens (H) up to the top of the camera. The button is located at the bottom left of the lens housing. - Page 4 LED indicator status Powered o . Rebooting after reset. RED LIGHT FLASHING Network connection failed. SOLID RED LIGHT Booting. Device malfunction. RED AND GREEN LIGHT FLASHING Firmware upgrading. GREEN LIGHT FLASHING Waiting for network. SOLID GREEN LIGHT Operating properly.
-
Page 5: Camera Configuration
Camera configuration Open the Heimgard app and follow these steps to connect your camera. Manage Devices Select Indoor 360° camera 2 from the list. Connect the power cable (B) to the power input (K). Insert the power cable into the USB power adapter (C). - Page 6 From the drop-down menu, select the name of your Wi-Fi network (SSID). NOTE! Select 2.4 GHz (not 5 GHz) if you have both options. You can also enter the network name (SSID) manually. Remember to distinguish between uppercase and lowercase letters. On the line below, enter your Wi-Fi password, then tap Next.
- Page 7 Hold the phone in front of the camera lens (H) and slowly move it away until the QR code is accepted (LED indicator (G) goes from flashing calm green to fast flashes indicating that the camera is connecting to your Wi-Fi network). When the camera is connected to the network, the LED indicator (G) on the camera will light solid green, and you will automatically be taken...
-
Page 8: Configuration And Use
Configuration and use Advanced settings: The camera can be used for two purposes: Recording and Generic. Generic: The camera does not record when it detects motion. In the app you can stream and start recording manually. Recording: On motion: The camera will record when motion is detected. On motion when away: The camera will record only when “Away mode”... - Page 9 Where to place your camera Place the camera as high as possible, in a place where it has a good overview of the area it is to capture and near a power outlet.
-
Page 10: Mounting Examples
Mounting examples Freestanding on a table / shelf Floor Wall mounting... -
Page 11: Wall Mounting
Wall mounting Before you start: Make sure that the wall material is strong enough to support 3 times the weight of the camera, and that you use screws that are suitable for the wall material. The supplied screws are intended for wood or similar material and can in combination with the wall anchors be used for mounting in concrete. -
Page 12: Factory Reset
Factory reset To locate the reset button (I), gently slide the camera lens (H) up to the top of the camera. The button is located at the bottom left of the lens housing (see the illustration below). Press and hold the reset button (I) for 10 seconds to disconnect the camera from your network. -
Page 13: Need Help
Heimgard smart home solution. Heimgard Technologies AS hereby declares that radio equipment of the type Indoor 360° Camera 2 is in accordance to Directive 2014/53 / EU. The full text of the EU Declaration of Conformity is available at the following... - Page 14 heimgard.com...
