Summary of Contents for bejot A1

  • Page 1 mechanisms and armrests manual...
  • Page 2 be:in motion be:flexible be:active...

  • Page 3: Table Of Contents

    M+X mechanism A1 mechanism MPD mechanism A mechanism O4 mechanism AR4 mechanism O5 mechanism AR5 mechanism OV mechanism B mechanism SW mechanism B+X mechanism Z mechanism EF+X mechanism additional adjustments FS mechanism armrest adjustments FS+X mechanism...

  • Page 4: General Information

    Bejot products are made of high quality materials. To ensure long-lasting use of the material, special care must be taken when cleaning the furniture. Depending on the upholstery used, certain rules must be followed regarding how to clean the fabric. When cleaning, do not apply any type of liquid directly to the fabric.
  • Page 5 (DEM, DEMA) are used for soft surfaces – carpets and rugs. • soft wheels (DEMD, DEMAD) are suitable for hard floors – wood floors and laminate floors. warranty Any repairs must be carried out by qualified personnel only. Warranty terms and conditions for Bejot products can be found at www.bejot.eu.

  • Page 6: A1 Mechanism

    A1 mechanism Swivel mechanism without height adjustment. User weight range: up to 110 kg. available in models: booi, hens, in access, lumi, orte, ox:co, umm, vieni...

  • Page 7: A Mechanism

    A mechanism 1. height adjustment Height-adjustable swivel mechanism. User weight range: up to 110 kg. To raise the height: 1. Seat height adjustment. • Lift yourself off the seat. • Pull the lever up with your right hand. available in models: To lower the height: •...

  • Page 8: Ar4 Mechanism

    AR4 mechanism Swivel, rocker mechanism, without height adjustment, with 2D movement. The mechanism has a rubber joint. Synchronous back and seat tilt range +7˚ backward and -4˚ forward. User weight range: 45–135 kg. 1. A button to lock the movement in the initial position (3˚). available in models: booi, in access, lumi, orte, ox:co...
  • Page 9 1. 2D movement lock To lock the rocker movement: • Slide the button up. To unlock the rocker movement: • Slide the button down.

  • Page 10: Ar5 Mechanism

    AR5 mechanism Swivel, rocker mechanism, height adjustable, with 2D movement. The mechanism has a rubber joint. Synchronous backrest and seat tilt range +7° backwards and -4° forwards. User weight range: 45–135 kg. 1. Seat height adjustment. 2. Button to lock movement in the initial position (3˚). available in models: in access, lumi, orte, ox:co...
  • Page 11 1. height adjustment 2. 2D movement lock To raise the height: To lock the rocker movement: • Lift yourself off the seat. • Slide the button up. • Pull the lever up with your right hand. To unlock the rocker movement: To lower the height: •...

  • Page 12: B Mechanism

    B mechanism Self-weighting synchro mechanism in which the spring force adjusts automatically to the weight of the seated person. Backrest/seat tilt adjust- ment range: 20˚/5˚, with backrest locking in 4 positions. User weight range: 45-110 kg. 1. Seat height adjustment. 2.
  • Page 13 1. height adjustment 2. backrest lock To raise the height: To lock the backrest movement: • Lift yourself off the seat. • While pushing your back against the • Use your right hand to move the lever down. backrest, choose a comfortable backrest position.

  • Page 14: B+X Mechanism

    B+X mechanism Self-weighting synchro mechanism in which the spring force adjusts automatically to the weight of the seated person. Backrest/seat tilt ad- justment range: 20˚/5˚, with backrest locking in 4 positions. User weight range: 45-110 kg. 58mm range of seat depth adjustment in 5 positions. 1.
  • Page 15 1. height adjustment 2. backrest lock To raise the height: To lock the backrest movement: • Lift yourself off the seat. • While pushing your back against the • Use your right hand to move the lever down. backrest, choose a comfortable backrest position.

  • Page 16: Ef+X Mechanism

    EF+X mechanism Synchro mechanism with backrest lock in 5 positions (tilt adjustment range: backrest 22˚, seat 11˚), seat depth adjustment (range 60 mm) and 5˚ angle of seat tilt in working position with lock in 2 positions. User weight range: 45-120 kg. 1.
  • Page 17 1. height adjustment 2. synchronised backrest and seat tilt adjustment To raise the height: To lock the backrest movement: • Lift yourself off the seat. • With your back pressed against the back- • Pull the lever up with your right hand. rest, choose a comfortable back position (the lever should be moved upwards).

  • Page 18: Fs Mechanism

    FS mechanism Fast-synchro with backrest fixed in 4 positions. Range of recline angle: backrest 20˚ and seat 8˚. User weight range: 50–120 kg. 1. Height adjustment. 2. Backrest and seat tilt adjustment. 3. Backrest and seat tilt lock. available in models: corr, double, dual, eleven, mate, milla, momo...
  • Page 19 1. height adjustment 2. backrest and seat tilt adjustment To raise the height: To reduce the spring force: • Lift yourself off the seat. • While sitting in the chair, turn the knob • Pull the lever up with your right hand. backwards your right hand.

  • Page 20: Fs+X Mechanism

    FS+X mechanism Fast-synchro with backrest fixed in 4 positions (range of recline angle: backrest 20˚ and seat 8˚) with seat depth adjustment (range: 58 mm). User weight range: 50–120 kg. 1. Height adjustment. 2. Backrest and seat tilt adjustment. 3. Backrest and seat tilt lock. 4.
  • Page 21 1. height adjustment 2. backrest and seat tilt adjustment To raise the height: To reduce the spring force: • Lift yourself off the seat. • While sitting in the chair, turn the knob • Pull the lever up with your right hand. backwards your right hand.

  • Page 22: K Mechanism

    K mechanism Synchro mechanism, rocker, polished aluminium, with backrest locking in 4 positions. Backrest and seat adjustment range 16˚. User weight range: 45-110 kg. 1. Seat height adjustment. 2. Backrest lock. 3. Tension adjustment crank. available in models: lumi...
  • Page 23 1. height adjustment 2. backrest lock To raise the height: To lock the rocking movement: • Lift yourself off the seat. • Sit in the chair. • Pull the lever up with your right hand. • Press down on the backrest with your back until the desired tilt position is reached (the To lower the height: lever should be downward).

  • Page 24: M Mechanism

    M mechanism Synchro mechanism with locking in 4 positions. Adjustment range of backrest 22˚ and seat 13˚. User weight range: 45-120 kg. 1. Seat height adjustment. 2. Synchronised back and seat tilt adjustment. 3. Backrest tilt adjustment. available in models: corr, dual, eleven, lift, mate, milla, momo...
  • Page 25 1. height adjustment 2. synchronised back and seat tilt adjustment To raise the height: To lock the backrest movement: • Lift yourself off the seat. • With your back pressed against the back- • Pull the lever up with your right hand. rest, choose a comfortable back position (the lever should point down).

  • Page 26: M+X Mechanism

    M+X mechanism Synchro mechanism with backrest lock in 4 positions (tilt adjustment range: 22° backrest, 13° seat), adjustable seat depth (60 mm range). User weight range: 45-120 kg. 1. Seat height adjustment. 2. Synchronous backrest and seat tilt adjustment. 3. Backrest tilt force adjustment. 4.
  • Page 27 1. height adjustment 2. synchronous backrest and seat tilt adjustment To raise the height: To lock the movement of the backrest: • Lift yourself off the seat. • Press your back against the backrest and • Pull the lever up with your right hand. choose a convenient backrest position.

  • Page 28: Mpd Mechanism

    MPD mechanism Rotatable, comfortable rocker mechanism with tilt force adjustment (rear titl: 16˚), without height adjustment. User weight range: 45–135 kg. 1. Backrest tilt adjustment. available in models: booi, umm, vieni...
  • Page 29 1. backrest tilt force adjustment To reduce spring force: • While sitting in the chair, turn the knob clockwise. To increase the resistance force of the backrest: • While sitting in the chair, turn the knob counterclockwise.

  • Page 30: O4 Mechanism

    O4 mechanism Swivel mechanism with 3D movement function (forwards, backwards and sideways), without height adjustment. User weight range: up to 110 kg. available in models: in access, lumi, orte, ox:co...

  • Page 31: O5 Mechanism

    O5 mechanism 1. height adjustment Swivel mechanism with 3D movement function (forward, backward and sideways), with height adjustment. User weight range: up to 110 kg. To raise the height: • Lift yourself off the seat. • Pull the lever up with your right hand. 1.

  • Page 32: Ov Mechanism

    OV mechanism Rocker mechanism (frame colour) with backrest locking in one position (0˚). User weight range: up to 120 kg. 1. 2D movement lock button. available in models: ovidio...
  • Page 33 1. height adjustment 2. 2D movement lock To raise the height: To lock 2D movement: • Lift yourself off the seat. • Sit in the chair. • Move the button up with your right hand. • Move the button down with your left hand. To lower the height: To unlock 2D movement: •...

  • Page 34: Sw Mechanism

    SW mechanism Self-weighting synchro mechanism with backrest locking in 5 positions (spring force adjusts automatically to the sitter's weight, no manual ad- justment required), tilt adjustment (backrest 20°, seat 6°) and seat depth adjustment (range 60 mm). The mechanism recognises the user's weight (45-120 kg) and automatically adjusts the synchronised tilt of the backrest and seat to it.
  • Page 35 1. height adjustment 2. synchronised back and seat tilt adjustment To raise the seat: To lock the movement of the backrest and • Lift yourself off the seat. seat: • Pull the lever up with your right hand. • Push your back against the backrest and select a comfortable backrest position (the To lower the seat: button must be extended for movement to...

  • Page 36: Z Mechanism

    Z mechanism An intelligent 3D swivel mechanism that keeps the body in constant motion. It has an adjustable seat height. User weight range: 50–120 kg. 1. Seat height adjustment. available in models: lupp...
  • Page 37 1. height adjustment To raise the seat: • Raise yourself off the seat. • Pull the hoop up. To lower the seat: • Sit in the chair. • Pull the hoop up.

  • Page 38: Additional Adjustments

    additional adjustments lift 10R chair adjustment • Press the button and raise or lower the backrest at the same time. backrest height adjustment • Release the button to lock the backrest at the desired height. dual chair adjustment To raise the backrest: •...
  • Page 39 lumbar support depth adjustment adjustment in chairs: corr, dual, in access, mate To extend the lumbar support: • Turn the knob forward. To retract the lumbar support: • Turn the knob back. lumbar support height adjustment ceo chair adjustment double chair adjustment •...
  • Page 40 lumbar support height adjustment eleven chair adjustment momo chair adjustment • Grasp the lumbar support with • Grasp the lumbar support with two two hands and move it up or down hands and move it up or down de- depending on the height you choose. pending on the height you choose.

  • Page 41: Armrest Adjustments

    armrest adjustment P48 armrest P49 armrest available in chairs: corr, double, dual, available in chairs: corr, double, dual, eleven, lift, mate, milla, momo eleven, mate, milla, momo 1. Height adjustment (range 80 mm): 1. Height adjustment (range 80 mm): Press the button and simultaneously Press the button and simultaneously move the armrest up or down to the move the armrest up or down to the...
  • Page 42 P60B armrest P54 armrest available in chairs: corr, double, milla, available in chairs: ceo momo 1. Height adjustment (range 50 mm): The armrest has 4 height locks, 1. Height adjustment (range 100 mm): adjustable upwards at each level. To Press the button and simultaneously raise one level: pull the armrest up move the armrest up or down to the until you feel resistance, then gently...

  • Page 43: Availability Of Mechanisms

    availability of mechanisms EF+X FS+X ✓ ✓ ✓ booi ✓ ✓ ✓ ✓ ✓ ✓ ✓ corr ✓ ✓ ✓ ✓ double ✓ ✓ ✓ ✓ ✓ ✓ dual ✓ ✓ ✓ ✓ ✓ ✓ eleven ✓ hens ✓ ✓ ✓...

  • Page 44: Swivel Chair Assembly

    swivel chair assembly step 1. Connect the wheels to the base by pushing step 2. Place the damper in the base. a pin into the hole at the end of each cross arm. step 3. Place the seat on the damper. step 4.
  • Page 45 notes...
  • Page 46 Bejot sp. z o.o. ul. Wybickiego 2A, Manieczki, 63-112 Brodnica n. Poznań, POLAND tel.: +48 (61) 281 22 25, e-mail: biuro@bejot.eu www.bejot.eu edition 06/2022...
