Epsilon Electronics H2-IN-1-BK User Manual

尺寸：66*87.5mm
Attention
1.Please don't let the children play the product.
2.Please don't disassemble this product by yourself.
3.Please stay away from the signal interference place,to prevent TWS
headset signal connection instability.
4.Please don't put the product in water or fire.
5.High temperature and severe cold,the headset performance will be
User Manual
degradation.
1. Instruction of Buttons
With the headset off, tap and hold the touch-key for
3 seconds to turn on or When the earphone is removed
Power on
from the charging cabin, it is turned on automatically
Tap the touch-key for either one of the earphones to
Answering
answer the phone when a call is incoming.
H2-IN-1-BK
Tap the touch-key for either one of the earphones to end
Hang up
the call during a call
When a call is incoming, tap and hold either one of the
Reject
earphones for 2 seconds to reject the incoming call.
In the phone call,there are new calls in,Double-Click the
touch-key ,retain the current call( A),and connect the
Three-way new phone calls( B);Double-Click the touch-key once
calling again, can switch between A/B phone calls. Short press
once to hang up the current call, it will cutover to another
call automatically
Voice
Triple tap either one of the earphones for voice activation
activation
Tap either one of the earphones to pause or resume
Play/Pause
playback when music playing
Please read the instructions carefully
Tap and hold the right earphone for 2 seconds
Volume +
to increase the volume when music playing
before using the product
Tap and hold the left earphone
Volume -
to decrease the volume when music playing
Double tap the left earphone to skip to the previous track
Previous track
during music playback
Double tap the right earphone to skip to the next track
Next track
during music playback
3. Indicator Light
When standby, hold down one earphone for 4 seconds,
Power off
and two earphones can be shut down at the same time
Auto If pairing is not completed within 5 minutes,the headset Power on
Power-Off will auto power-off
Pairing mode
2. Functional Operation
Connection
1)Dual ear pairing model
succeeded
Using the earphone for the first time,Take out two earphones, the
Music playing
earphone will automatically start up and establish a connection.or
operated manually when the headset off, tap and hold the R/L earphone
touch-key for 5 seconds at the same time until the red and blue light Calls coming
flashes alternately, R/L earphone will automatically complete pairing,
During talking
The earphone has a voice telling you to team up successfully, (At this time,
one earphone red and blue light flash alternately, the other earphone blue
light flash slowly).Then open the bluetooth menu of the device and search Power off
the bluetooth name "H2GO 2IN1" to connect.
Earphone
※Note：After the first pairing, the next time when take out it from the
Charging
charging case,The earphone will automatically connect to the last
connected phone or Bluetooth device.
Low battery
2)Single ear pairing model
Take out any one earphone to start up, Tap the touch-key to the red and
blue lights flashing alternately.Or with the headset off,tap and hold the
touch-key for 5 seconds until the light flashes red and blue alternately,
Then open the bluetooth menu of the device and search the bluetooth
4. Headset Accessories
name "H2GO 2IN1" to connect; now earphone can be used independently.
3)Speaker base
1) 1x Instruction
When the headset is turned on and connected, put it in the
2) 1x Charging cable
speaker base, close the cover (hall switch works), and turn
on the speaker amplifier to play music. The audio of the
3) 6x Ear buds(two are equipped on the headset)
Hall switch headset (left headset) can be switched to the speaker to
control play. Open the cover and turn off the speaker amplifier.
to release
Note: when the headset is off, put it in the speaker base,
only charge the headset, but not the speaker amplifier.
for 2 seconds to release
Charging for the battery case，the red light flashes，
Fully charged，the red light bright.
Charging
Put the R/L headset into the charging bin. The charging
case can charge the headset. The blue lights.
5. Structural Component Description
Microphone
The blue LED flashes 3 times
The red and blue LED lights flash alternately
The blue LED flashes once every 6 seconds
Charging/audio contact point
The blue LED flashes once every 6 seconds
Touch-key area
The blue LED flashes quickly
The blue LED flashes once every 6 seconds
Indicator Light
The red LED flashes 3 times then goes out
The red LED stay on when on charging,
when charging is completed the red LED goes out
When the battery is low, the red led flashes warning,
and there is a sound prompt
Speaker
Indicator Light
Charging port
6. Technical Specification
Products NO. H2-IN-1-BK
Button mode Touch-Key
Bluetooth Version Bluetooth 5.0+EDR
Support agreement A2DP，AVRCP ，HFP，HSP
Transmission frequency 2.40GHz~2.48GHz
Headset speaker 16±15%Ω
Sensitivity 91±3dB/1KHz
Frequency response 20Hz~20KHz
Operation range 10m
Headset Play time
5h（Maximum volume）
Talk time 5h
Headset Charging time ≤2h
Headset Battery capacity
3.7V/40mAh；Li-Polymer
Base Charging
DC5V/500mA
Base Battery capacity 3.7V/500mAh
Speaker Rated power 3W
Speaker box Play time 3-4h
Dimension 92*46*35mm
