Mini Pick-Up Broom
For
Mini Skid Steer Loaders
And
Mini Track Loaders
Operator's Manual
Maintenance and Parts Information
Do not use or operate this machine until this manual has been read and
understood.
Read the Operation & Maintenance Manual entirely. When you see this
symbol, the subsequent instructions and warnings are serious - follow
without exception. Your life and the lives of others depend on it!
Advertisement
Related Manuals for Spartan Equipment Mini Pick-Up Broom
Summary of Contents for Spartan Equipment Mini Pick-Up Broom
- Page 1 Mini Pick-Up Broom Mini Skid Steer Loaders Mini Track Loaders Operator's Manual Maintenance and Parts Information Do not use or operate this machine until this manual has been read and understood. Read the Operation & Maintenance Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception.
- Page 2 IMPORTANT If this machine is used by an employee or is loaned or rented to others, make certain that the operator(s) prior to operating: • Is instructed in safe and proper use. Reviews understands operation maintenance manual(s) pertaining to the machine. Remember, the operator is responsible for the safe operation and maintenance of the machine.
- Page 3 10-11 ROUTINE MAINTENANCE 12-15 PARTS INFORMATION 16-18 GENERAL SPECIFICATIONS REFERENCE INFORMATION Write the correct information for YOUR MINI PICK-UP BROOM in the spaces below. Always use these numbers when referring to your MINI PICK-UP BROOM. MINI PICK-UP BROOM Serial Number...
- Page 4 WARNING: the Operation and Maintenance Manual(s) pertaining between DANGER and intermediate to the Spartan Equipment™ Mini Pick-Up Broom(also CAUTION. referred to as "attachment") and the mini skid steer loader/mini track loader (hereafter referred to as "loader"). DANGER: denotes the most serious Throughout this manual reference may be made to "hazard.
- Page 5 Know how to stop all equipment Do not modify equipment or add attachments that operation in case of emergency. are not approved by Spartan Equipment. Avoid the possibility of personal injury and/or Remember, YOU are responsible for the safe machine damage.
- Page 6 SERIAL NUMBER AND SAFETY DECAL LOCATIONS Serial Number Location: It is important to refer to the serial number of the attachment when making repairs or ordering parts. Early or later models (identification made by serial number) may use different parts, or it may be necessary to use different procedures in doing a specific operation.
- Page 7 SERIAL NUMBER AND SAFETY DECAL LOCATIONS...
- Page 8 USER'S INSTRUCTIONS FOR MOUNTING THE MINI PICK-UP BROOM After uncrating the attachment, use the following procedure to mount the attachment to the loader. Instructions for mounting to a ride-on Instructions for mounting to a walk- mini skid loader: behind mini skid loader: 1.
- Page 9 Female JIG Swivel) fittings on the ends of the lead hoses. 7. Connect the hydraulic quick couplers from the Mini Pick-up Broom to the loader. Be sure to thread the hoses through the hose holder on the loader. Bungee straps can be used as an alternate method of securing the hoses.
- Page 10 NOTE: For steering lever functions, refer to your loader's operation and maintenance manual. IMPORTANT: When turning at a high rate of speed, raise the front wheel of the Mini Pick-up Broom off the ground. Excessive speed can damage the caster assembly.
- Page 11 (rotating clockwise, or towards the operator), and move the Mini Pick-up Broom backward. The Mini Pick-up Broom cutting edge will scrape the debris while the bristles will sweep the debris off the surface and into the bucket.
- Page 12 Use No. 2 lithium base gun grease when lub- ricating all Mini Pick-up Broom grease fittings. Grease the 2 zerks on the caster wheel after every 8 hours of operation.
- Page 13 ROUTINE MINI PICK-UP BROOM MAINTENANCE Replacing Brush Sections Remove the side rubber shields from both sides on the Mini Pick-up Broom. Remove the (2) end plate mounting bolts and nuts (on each side), retain for later assembly. NOTE: The motor and hex drive block will be removed with the end plate.
- Page 14 ROUTINE MINI PICK-UP BROOM MAINTENANCE Replacing Brush Sections (continued) Remove the bearing retaining bolt and washer. Loosen the set screws on the bearing assembly and slide off the bearing/endplate assembly. Remove the (3) bolts holding the brush retainer to the brush tube.
- Page 15 ROUTINE MINI PICK-UP BROOM MAINTENANCE Replacing Brush Sections (continued) Reattach the brush retainer. Slide on the bearing/end plate assembly. Tighten the set screws on the bearing assembly. Install the bearing retaining bolt and washer. Move the arbor and brush assembly into the bucket housing.
- Page 16 MINI PICK-UP BROOM PARTS INFORMATION...
- Page 17 MINI PICK-UP BROOM PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NUMBER 318403 BRACKET PIVOT RH 318404 BRACKET PIVOT LH 318427 SHEILD RUBBER SIDE 400331 BODY PICK UP BROOM 48 400343 SHIELD RUBBER FRONT 48 318499 CASTER ASSEMBL Y 8 X 2...
- Page 18 MINI PICK-UP BROOM PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NUMBER 318459 DRIVE BLOCK HEX 1" BORE-SNAP RING INCLUDED 203741 FLANGET 3-BOL T 1-1/8" 202159 BRG INSERT 1-1/4" SM 400307 ARBOR 45 W/A 318411 WAFER CONVOLUTED POL Y 24" OD OPT.
- Page 19 MINI PICK-UP BROOM PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NUMBER 400311 MOTOR 41.3 400381 HOSE 1/2 X 100 10MB-8FJX...
- Page 20 MINI PICK UP BROOM GENERAL SPECIFICATIONS...
- Page 21 NOTES...
- Page 22 NOTES...
- Page 23 Spartan Equipment to improve its products whenever it is possible and practical to do so. Spartan Equipment reserves the right to make changes and or add improvements at any time without incurring any obligation to make such changes or add such improvements to products previously sold.
- Page 24 PIN 300437 Date Printed: 4/21/2015 Printed in U.S.A. Spartan Equipment...
