- Page 1 流光开关 LS240系列 流光开关PRO LS230系列 流光开关Lite 使用说明书 V1.0...
- Page 2 产品介绍 LifeSmart 流光开关系列支持双向通信及手机远程控制，通过 手机可以随时随地控制智能开关并查看智能开关状体啊，从 而控制与它连接的每个电器设备，同时可以和其他智能设备 （如动态感应器，智慧插座等）形成联动。 流光开关创新地将 LED 灯光元素融入其中，用户可以自定义 开关灯效，解决摸黑开关等的难题。同时流光开关可以直接 取代传统开关面板，不仅可以通过物理按键开关灯光，还可 以使用手机 app 控制，形成双控。...
- Page 3 规格参数 尺寸 露出墙外尺寸: 86*86*11mm 整机尺寸: 86*86*36mm 重量 PRO: 一联124g 二联136g 三联148g Lite: 一联116g 二联128g 三联140g 功率 <0.6W 输入 220V~ 50/60Hz 负载 1-500W/路 1-200W/路 无线协议 CoSS 无线距离 200m （开放场） 工作温度 -5~45℃ 工作湿度 5~90%...
- Page 4 安装方法 L3: 接出的第三路火线 L2: 接出的第二路火线 L1: 接出的第一路火线 L: 接入的火线 N: 接入的零线 L3 L2 L1 注意： 接出线路数量根据不同的底部套件而变化，请以实物为准； 建议安装高度不超过2米； 本产品在实际安装使用时，需在工作回路上配套有相应规格的过电流保 护装置(如:带过电流保护的剩余电流动作断路器)，将故障电流限制在10A 以内。 警告： 因为安装涉及到强电，务必请专业电工操作 。...
- Page 5 安装方法 切断安装处的电源， 确认所接电线未带电。 取出智能控制底部套件， 进行接线。 将安装的电线有序地理进开关底盒， 安放好底部套件， 并使用左右两侧 的螺丝固定。 取出开关面板， 将面板扣到底部 套件上， 确认上、 下各两个卡扣 到位， 否则可能因为接触不良无 法正常使用。 打开安装处的电源， 设备自动开 启。 配置好智慧中心，在 LifeSmart App 中点击“添加新设备” ，选 择 “流光开关 PRO” 或 “流光开 关 Lite” ，参照 App 提示进行操 作并完成配对。 * 产品外观请以实物为准...
- Page 6 声明...
- Page 7 技术支持 制造商: 杭州行至云起科技有限公司 地址: 杭州市萧山区平澜路518号悦盛国际中心22楼 保修说明...
- Page 8 保修说明 杭州行至云起科技有限公司及其许可者版权所有，保留一切权利。 P/N 88010340 A0...
- Page 9 BLEND Switch User Guide V1.0 Model: LS230,LS240 series...
- Page 10 The LifeSmart BLEND Switch Series replaces your traditional switch with smart home technology to make your life easier. Combined with the LifeSmart Smart Station and the free LifeSmart App, you have infinite control possibilities. In addition to traditional switch control of your lights and switched outlets, you can choose combination controls over all of your LifeSmart Smart Home products.
-
Page 11: Specifications
SPECIFICATIONS Size Outside the wall: 86*86*11mm Overall: 86*86*36mm Weight PRO: 124g(1way) 136g(2 way) 148g(3 way) Lite: 116g(1way) 128g(2 way) 140g(3 way) Power consumption <0.6W Input AC 100-240V 50/60Hz Maximum load Resistive Load: 500W per channel Inductive/Capacitive Load: 200W per channel Wireless protocol CoSS Wireless distance... -
Page 12: Wiring Instruction
WIRING INSTRUCTION L3 L2 L1 L3: Switch-out Live Wire 3 L: Switch-in Live Wire L2: Switch-out Live Wire 2 N: Switch-in Neutral Wire L1: Switch-out Live Wire 1 NOTE: The number of output lines varies according to different smart control accessories, please refer tothe actual product. -
Page 13: Installation
Restore the power supply, the device will turns on automatically. After configuration of the Smart Station, choose “Add Device” in LifeSmart App, select “BLEND Switch PRO” or “BLEND Switch Lite” to enter pairing process. Follow the instruction on the app to finish... -
Page 14: Warranty Description
WARRANTY DESCRIPTION Thank you for purchasing this LifeSmart product. In order to protect your rights, please read the following content carefully: The warranty period of our company's products is one year from the date of purchase or longer if local laws impose a longer minimum term, in which case the minimum term is the warranty period. - Page 15 Products that have the barcode tampered with or removed; Devices that have been tampered with or customized outside of LifeSmart Terms Of Service as on the LifeSmart APP and website; User-caused damage, such as inappropriate voltage input, high temperature, accidental spillage, physical damage, etc;...
- Page 16 DECLARATION DECLARATION OF CONFORMITY Hereby, LifeSmart declares that the radio equipment type is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://global.ilifesmart.com/ce/docs/ Notice: This device may be used in each member state in EU.
