  • Page 1 User’s Guide P/N 071787-001 ™ MobileLAN power 6/12...
  • Page 2 Canadian service and technical support: 1-800-668-7043 Canadian media supplies ordering information: 1-800-268-6936 Outside U.S.A. and Canada: Contact your local Intermec service supplier. The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.

  • Page 3: Table Of Contents

    Contents Before You Begin vii Warranty Information vii Safety Summary vii Warnings, Cautions, and Notes viii About This Guide ix Prerequisite Skills and Knowledge ix Introduction Introducing the Power Bridge 1-3 About the Power Bridge 1-3 Power Bridge—Front View Detail 1-4 LEDS—6-Port Option 1-5 6-Port Power Bridge Status Indications 1-5 LEDS—12-Port Option 1-6...
  • Page 4 Installing and Setting Up the Power Bridge Installing the Power Bridge 2-3 Verifying Kit Contents 2-3 Recording Identification Information 2-4 Choosing a Suitable Site 2-4 Rack Mounting (12-Port Bridge Only) 2-5 Shelf Mounting 2-6 Setting Up the Power Bridge 2-6 Powering Up 2-6 6-Port Option 2-7 12-Port Option 2-7...
  • Page 5 Specifications and Troubleshooting 6-Port Specifications B-3 Physical Specifications B-3 Environmental Specifications B-3 Electrical Specifications B-3 Ethernet Interface B-4 Serial Port Interface B-4 12-Port Specifications B-4 Physical Specifications B-4 Environmental Specifications B-4 Electrical Specifications B-5 Ethernet Interface B-5 Serial Port Interface B-5 Troubleshooting B-5 Commonly Asked Technical Support Questions B-6...

  • Page 7: Before You Begin

    Warranty Information To receive a copy of the standard warranty provision for this product, contact your local Intermec sales organization. In the U.S.A, call 1-800-755-5505; in Canada, call 1-800-668-7043. Note: Opening this product may void the warranty. The internal workings of this product can only be accessed by Intermec service personnel.

  • Page 8: Warnings, Cautions, And Notes

    Warnings, Cautions, and Notes Warning Warnings contain directions that must be followed for personal and product safety. Follow all directions carefully. Avertissement Les avertissements comprennent des instructions qui doivent être respectées pour assurer la sécurité des personnes et de l’équipement. Respectez scrupuleusement toutes les instructions.

  • Page 9: About This Guide

    About This Guide This document provides information and procedures regarding hardware installation, setup, configuration, and management of the Power Bridges. Prerequisite Skills and Knowledge This guide is intended for use by network administrators who are responsible for installing and setting up network equipment; consequently, it assumes a basic working knowledge of LANs (Local Area Networks).
  • Page 10 kjhkjh...

  • Page 11: Introduction

    Introduction...

  • Page 13: Introducing The Power Bridge

    This chapter introduces the Power Bridge and explains how it can be used in your network. Introducing the Power Bridge This chapter covers the following topics: About the Power Bridge Power Bridge—front view detail LEDs—6-port option LEDs—12-port option Power Bridge—rear view detail Network configuration examples Power Ethernet devices About the Power Bridge...

  • Page 14: Power Bridge-Front View Detail

    The Power Bridge features the following: Remote power feeding of Ethernet terminals 6 or 12 10BaseT/100BaseTx data + power combined channels Universal 90 to 264 VAC, 50 to 60 Hz power input Independent overload and short-circuit protection for each channel Port status indications as specified in this manual RS-232 software download, monitoring, and control serial port Standard 19-inch, 1.5U rack mountable (12-port option)

  • Page 15: Leds-6-Port Option

    10BaseT/100BaseTx Data Input Ports, Lower 6/12 Ports The Power Bridge has 6/12 10BaseT/100BaseTx data input ports, configured as Media Dependant Interface (MDI) (non-crossover). These ports are designed to carry Ethernet data only (Tx/Rx) over the standard 2-wire pairs (RJ-45 pins 1/2 and 3/6). 10BaseT/100BaseTx Data and Power Output Ports, Upper 6/12 Ports The Power Bridge has 6/12 Data and Power ports configured as MDI (non-crossover).

  • Page 16: Leds-12-Port Option

    6-Port Power Bridge Status Information Port LED Port Load Conditions Non-active load or unplugged port Green Active load is plugged in and complies with normal load conditions Orange Overload conditions or shorted terminal port or forced external voltage feed (constant DC) into the port Green–...

  • Page 17: 12-Port Power Bridge Status Indications

    Two LEDs (one green and one orange) per port provide port status. The Power Active LED (green) indicates that the terminal unit has been identified as Power over LAN Enabled and is active and receiving power. The Power Not Active LED (orange) indicates that the port is not supplying power and is not active.

  • Page 18: Power Bridge-Rear View Detail

    12-Port Power Bridge Status Indications (continued) AC LED Main Power Status Main internal power supply unit is unplugged or faulty Main power supply unit is plugged in and under normal operating conditions Blinking Main power supply unit voltage exceeds specified limits Alarm LED Remarks...

  • Page 19: Console Port

    Console Port Use the console port (DB-9 connector) to connect a terminal and to perform local out-of-band management. The console port uses a standard null modem cable and is set to 19,200 baud, 8 data bits, no parity, and 1 stop bit. Information Label The Information label (located on the bottom of the 1-port Power Bridge and on the rear of the 12-port Power Bridge) shows the...

  • Page 20: Network Configuration Examples

    Network Configuration Examples The following illustration shows network configuration examples. Powering Ethernet Devices The Power Bridge may be used to power any Ethernet device with power requirements that are within the specified powering capabilities. As shown in the previous illustration, the Power Bridge may be used to power end devices such as IP phones, web cameras, laptop computers, and others.

  • Page 21: Installing And Setting Up The Power Bridge

    Installing and Setting Up the Power Bridge...
  • Page 22 asdf...

  • Page 23: Installing The Power Bridge

    This chapter contains information needed to install and set up the Power Bridge. Installing the Power Bridge This section covers the following topics: Verifying kit contents Recording identification information Choosing a suitable site Rack mounting (12-port Bridge only) Shelf mounting Warning You must read the safety information provided in Appendix A before carrying out any installation, removal,...

  • Page 24: Recording Identification Information

    Recording Identification Information Before proceeding with the Power Bridge placement and installation, record the serial number here for future reference. The serial number is located on the Information label on the bottom or rear of the Power Bridge. Serial Number: Choosing a Suitable Site The Power Bridge is suited for use in an office environment where it can be free-standing or mounted in a standard 19-inch equipment rack.

  • Page 25: Rack Mounting (12-Port Bridge Only)

    Rack Mounting (12-Port Bridge Only) The Power Bridge is 1.5U high and fits in most standard 19-inch racks. Caution Disconnect all cables from the Power Bridge before continuing. Conseil Déconnectez tous les câbles du Pont d’alimentation avant de continuer. To mount the Power Bridge in a rack 1.

  • Page 26: Shelf Mounting

    Shelf Mounting When shelf-mounting the 12-port Power Bridge, the self-adhesive rubber feet provided in the kit should be placed on the underside of the Power Bridge. Be sure to place the rubber feet on the provided 90° angle marking in order to ensure stable placement. No more than four (4) Power Bridges are to be placed on top of one another if the units are shelf-mounted.

  • Page 27: 6-Port Option

    6-Port Option 1. The Main LED lights up. 2. The Main LED and Port LEDs light up. 3. The Main LED and Port LEDs light up. 4. The Main LED lights up. 5. All Port LEDs are ready for normal indications. 12-Port Option 1.

  • Page 28: Connecting Cables To End Devices

    Connecting Cables to the Power Bridge Ethernet RJ-45 IN Switch/Hub data data data spare spare data spare spare 6HH )LJXUH  RQ SDJH  Connecting Cables to End Devices The Power Bridge contains proprietary line sensing capabilities that enable it to send power only to end devices that are enabled to receive power.
  • Page 29 To connect end devices to the Power Bridge 1. Connect a Category 5, 6, or 6e cable to the end device directly (if the device is Power over LAN Enabled) or use an external splitter. 2. Connect the opposite end of the same cable to the RJ-45 wall outlet. Monitor the response of the corresponding Port LEDs.

  • Page 31: Safety Information

    Safety Information...
  • Page 32 asdf...

  • Page 33: Important Safety Information

    This chapter explains safety information. Important Safety Information Installation and removal of the Power Bridge must be carried out by qualified personnel only. You must read the following safety information before installing, removing, or maintaining the Power Bridge. Warning Read the installation instructions in Chapter 2 before connecting the Power Bridge to its power source.
  • Page 34 Warning This product relies on the building installation for short-circuit (overcurrent) protection. Ensure that a fuse or circuit breaker no larger than 120 VAC, 15A U.S. (240 VAC, 10A international) is used on the phase conductor. Avertissement Ce produit suppose qu’une protection contre les courts-circuits (surcharges) est assurée par le bâtiment.
  • Page 35 Warning For shelf-mounted equipment, be certain that the surface is stable and strong enough to support the equipment. Do not stack more than four (4) Power Bridges on top of one another. Avertissement Pour tout équipement monté sur une étagère, assurez-vous que la surface est stable et suffisamment solide pour soutenir l’équipement.

  • Page 36: Power Cord Set

    Power Cord Set The power cord must be approved for the country in which it is used. Country Approvals U.S.A. and The cord set must be UL-approved and CSA certified. Canada The minimum specification for the flexible cord is: No. 18 AWG Type SV or SJ 3-conductor The cord set must have a rated current capacity of at least 10A.
  • Page 37 Specifications and Troubleshooting...
  • Page 38 asdf...

  • Page 39: 6-Port Specifications

    This appendix lists the 6- and 12-port Power Bridge hardware specifications, electrical specifications, and troubleshooting. 6-Port Specifications This section lists the various specifications of the 6-port Power Bridge. Physical Specifications Dimensions Height: 44 mm (1.73 in) with rubber feet Width: 241 mm (9.5 in) Length: 400 mm (15.75 in) Weight 1.6 kg (3.5 lb)

  • Page 40: Ethernet Interface

    Ethernet Interface Input (Data In): 6 ports; Ethernet 10BaseT/100BaseTx Output (Data & Power Out): 6 ports; Ethernet 10BaseT/100BaseTx and 48 Serial Port Interface Connector Type DB9 male serial data monitor port 12-Port Specifications This section lists the various specifications of the 12-port Power Bridge.

  • Page 41: Electrical Specifications

    Electrical Specifications Input voltage Input current at 110 VAC Total power consumption, continuous, 12 ports at full load Output power, per port Nominal output voltage, per port Ethernet Interface Input (Data In): 12 Ports; Ethernet 10BaseT/ 100BaseTx Output (Data & Power Out): 12 Ports; Ethernet 10BaseT/100BaseTx, and 48 VDC Serial Port Interface Connector Type...

  • Page 42: Commonly Asked Technical Support Questions

    Commonly Asked Technical Support Questions Problem/Question Possible Solution/Answer The Power Bridge is Verify that the AC power cord is correct, plugged into the main functioning, and has a solid ground connection. AC inlet but does not Verify that the AC inlet is supplying power (test power up.
  • Page 43 Commonly Asked Technical Support Questions (continued) Problem/Question Possible Solution/Answer The Power Active and The Power Bridge did not detect a connected end Power Not Active LEDs device; therefore, the port is not providing on one port are not lit, power. Verify that you are using a standard UTP and the corresponding Category 5, 6, or 6e cable, including all 8 wires end device does not...
  • Page 44 Commonly Asked Technical Support Questions (continued) Problem/Question Possible Solution/Answer The end device operates, Verify that the Power Active LED on the but there is no data link. Power Bridge front panel is lit continuously. Verify that the Data In and Data & Power Out ports correspond.
  • Page 45 Commonly Asked Technical Support Questions (continued) Problem/Question Possible Solution/Answer A Power Not Active LED Wait 5 to 10 seconds while the Power Not on one port is lit, and the Active LED is on and the end device is end device is not connected—if the LED changes to Power operating.
  • Page 46 jhgfsdf...
