SERVICE AND MAINTENANCE INSTRUCTIONS
VERTICAL/HORIZONTAL/MULTI−POSITION FAN COIL UNITS
FEM4, FCM4, FSA4, FEA4, FSM4, FSU4, FXM4, FVM4, FMA4,
NOTE: Read the entire instruction manual before starting the
installation.

TABLE OF CONTENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FEM4P, FEM4X, FXM4X, FEA4X, WAHA, WAPM,
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WAPT, WAPL, WAHM, WHAT, WAHL, WAXM,
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SAFETY CONSIDERATIONS

Improper
installation,
adjustment,
maintenance, or use can cause explosion, fire, electrical
shock, or other conditions which may cause death, personal
injury or property damage. Consult a qualified installer,
service agency, or your distributor or branch for information or
assistance. The qualified installer or agency must use
factory−authorized kits or accessories when modifying this
product. Refer to the individual instructions packaged with kits
or accessories when installing.
Follow all safety codes. Wear safety glasses, protective
clothing and work gloves. Have a fire extinguisher available.
Read these instructions thoroughly and follow all warnings or
cautions included in literature and attached to the unit.
Consult local building codes and the current editions of the
National Electrical Code (NEC) NFPA 70.
In Canada, refer to the current editions of the Canadian
Electrical Code CSA C22.1.
WAH, WAP, WAM, WAX, REM4
PAGE
. . . . . . . . . . . . . . . . . . . . . . . .
. .
. . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . .
. . . . . . . . . .
. . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . . . . .
alteration,
service,
Specifications subject to change without notice.
Recognize safety information. This is the safety−alert symbol
. When you see this symbol on the unit and in instruction
manuals, be alert to the potential for personal injury.
Understand the signal words DANGER, WARNING, and
CAUTION. These words are used with the safety−alert
1
symbol. DANGER identifies the most serious hazards which
will result in severe personal injury or death. WARNING
1
signifies hazards which could result in personal injury or
1
death. CAUTION is used to identify unsafe practices which
1
may result in minor personal injury or product and property
damage. NOTE is used to highlight suggestions which will
result in enhanced installation, reliability, or operation.
5
!
6
12
UNIT OPERATION AND SAFETY HAZARD
17
Failure to follow this caution may result in equipment
damage, improper operation or personal injury.
21
When coils are pressurized with nitrogen, open the
suction port first to release the nitrogen. Mesh screens
may dislodge if the liquid line is opened first.
21
21
!
22
UNIT OPERATION AND SAFERTY HAZARD
Failure to follow this warning could result in personal
22
injury or death.
23
R−410A systems operate at higher pressures than R−22
systems. Do not use R−22 service equipment or
24
components on R−410 equipment. Ensure service
24
equipment is rated for R−410A.
25

INTRODUCTION

25
These fan coil units are designed for flexibility in a variety of
27
applications that meet upflow, horizontal, or downflow
requirements. Units are available in 1−1/2 through 5 ton
nominal
cooling
field−installed electric heater packages are available in 5kW
@ 240Vac through 30kW @240Vac.
WARNING
!
ELECTRICAL OPERATION HAZARD
Failure to follow this warning could result in personal injury
or death.
Before installing or servicing unit, always turn off all power
to unit. There may be more than one disconnect switch.
Turn off accessory heater power if applicable. Lock out
and tag switch with a suitable warning label.
CAUTION
WARNING
capacities.
Factory−authorized,
496 08 8001 00 2/17/2014
