Summary of Contents for ORIT B.V. 4300 EHP
- Page 1 BlockCutters On the cutting edge for customers’ satisfaction ORIT B.V. Verbal Manual ELECTRIC HYDRAULIC STONE- AND TILECUTTER 4300 EHP...
- Page 2 If you notice any matters that should be altered, notify us. Everyone who makes a good proposal for improvement will receive a nice consideration. We would like to wish you a lot of pleasure with the 4300 EHP. ORIT B.V.
- Page 3 Preface The ORIT 4300 is an electric hydraulically powered cuttingmachine, especially built for cutting concrete tiles and blocks. Use for other purposes is strictly forbidden. A 12-volt battery supplies the electrical power. Because of safety reasons, we chose for a closed battery. Because the charging voltage of a closed battery may not be more than 13 volt, a special charger is delivered in addition.
- Page 4 If the battery needs to be substituted you should live up to the following instructions. Turn off the battery before loosening the battery brakes to prevent sparks. Remove the connecting terminal, which the battery is attached with to the bottom of the battery tank. Before removing the battery from the battery tank, your will first have to loosen the earth connection.
- Page 5 The materials that needs cutting You should be able to cut all concrete products. It is possible that you are not able to cut granite tiles, which are extremely thick. The power of the machine is limited till 13 thousand kilograms. In that case the tiles or blocks needs to be sawn in a bit. It does happen sometimes that the machine pulverizes the tiles.
- Page 6 Partslist Explanation of the numbers: Operationbutton Emmergency button Battery/operation tank Frame Pin knife holder Wheel Frontwheel Cylinderpins Spring Workingtable Lower/upperknife Cilinderrod Holdingplate rubber Lever...
- Page 7 Elektric schedule Hydraulic schedule...
- Page 8 For service and/or repairs after the guarantee period you can go straight to ORIT B.V. in Tilburg. CE-declaration of conformity ORIT B.V. , Juristenlaan 11, 5037 GJ Tilburg Herewith declares that: ORIT brickcutter type 4300 EHP Is in conformity with the provisions of the Machinery Directive and with national implementing legislation Directives: 98/37/EEG...
