Summary of Contents for Edmund Optics 86-885
- Page 1 86-885 MANUAL Edmund Optics Ver. 1.2...
-
Page 2: Table Of Contents
Contents 1. Cautions during Transportation and Installation ------------------------------------------------------------- P3 1.1 Cautions 1.2 Warning Label Positions and Descriptions 2. Specifications -------------------------------------------------------------------------------------------------------- P5 3. Preparation and Operation --------------------------------------------------------------------------------------- P8 3.1 Control Panel & Descriptions 3.2 How to Operate 3.3 Preparations before Use 4. -
Page 3: Cautions During Transportation And Installation
Cautions during Transportation and Installation 1.1) Cautions 1. This product is designed for indoor use, and should be installed on a flat and vibration-free surface. 2. Avoid impacting the product all times. Stable power must be supplied during operation. -
Page 4: Warning Label Positions And Descriptions
1.2) Warning Label Positions and Descriptions Label Description Electricity Warning – Avoid touching before disconnection to power main Do not open - Do not open door during operation (The product automatically stops when opened) UV Light Hazard – Avoid looking directly at light ④... -
Page 5: Specifications
Specifications Item Description 5” in Diameter Effective Area UV Lamp Model No. KGW9n_UVA PL Lamp 9W x 4 EA UV Lamp Lifetime 2,000 Hrs ² UV Intensity 30mW/cm at 365nm 13.3”(W)*10.6”(H)*11.3”(D) Dimensions Speed 6 RPM Turntable 9.6” Glass Plate (effective area shown on plate) Size Safety Feature All functions stop when door opens... -
Page 6: Preparation And Operation
Preparations and Operation 3.1) Control Panel & Descriptions Function Key Description ① Display UV Curing Time / UV Lamp Lifetime ② START / STOP UV Lamp and Turntable ON/OFF ③ Increases UV Curing Time (by 10 seconds) ④ Decreases UV Curing Time (by 10 seconds) ⑤... -
Page 7: How To Operate
Preparations and Operation 3.2) How to Operate Item Operation START / When pressed, lamp turns ON for designated time / When pressed again, lamp STOP turns off (Only operational when door is closed) Increases by 10 seconds per click / Increases rapidly when pressed for more than 2 seconds (Max. -
Page 8: Preparations Before Use
Preparations and Operation 3.3) Preparations before Use ① Select correct voltage depending on location. ② Connect appropriate power cable into power input port, and connect power. ③ Turn on power. Item Description ① Power Select Select Power 100 V / 220 V ②... -
Page 9: Troubleshooting
Troubleshooting Regular check-up is necessary. If problem persists, please contact supplier or manufacturer. Item Unit Problem Possible Cause Solution 1. Lamp is not 1. Check connection UV Lamp properly connected. between lamp No Light / and socket Housing Low in Intensity Malfunctioning 2. -
Page 10: Maintenance
Maintenance 5.1) Decrease in Intensity of UV Lamp 1. Intensity of UV Lamp decreases slowly after it gets used for a certain period of time. 2. When the accumulated usage time for lamp gets close to 2,000 hrs prepare replacement lamps. -
Page 11: Dimensional Information
Dimensional Information - UV System Dimensions...
