Wavetek 132 Manual page 2

Section One SPECIFICATIONS
Physical
OPERATION
Section Two
Inspection
Operating Controls
Operation
Section Three CIRCUIT DESCRIPTION
General
Section Four MAINTENANCE
Introduction
Recommended Test Equipment
Checkout and Calibration
Troubleshooting
Section Five DATA PACKAGE
Introduction
Recommended Spare Parts List
SCOPE OF MANUAL
This manual contains instructions for operating, test-
ing, and maintaining the Wavetek Model 132 VCG/
Noise Generator. The Wavetek product-improvement
program ensures that the latest electronic developments
are incorporated into the Wavetek instruments by the
addition of circuit and component changes as rapidly
as development and testing permit. Due to the time re-
quired to document and print this manual, it is not
always possible to incorporate these changes into the
manual. In this case, data will be found on engineering
change sheets at the back of the manual. If there are no
change sheets, the manual is correct as printed.
CONTENTS
and Electrical
......................
....................
......................
Description
......................
...............
.................
....................
.....................
...............
. . . . . . . . . . . . . .
Specifications
SCOPE OF EQUIPMENT
The Model 132 is a source of analog and digital noise,
as well as a precision source of sine, triangle and square
waveforms. Noise outputs, or waveforms can be used
individually, or combined to provide selectable, cali-
brated signal-to-noise and noise-to-signal ratios to
+60 dB. Waveforms can be varied over a frequency
range of 0.2 Hz to 2 MHz. Length of the digital se-
quence is selectable to a maximum of
Clock rates, variable from 160 Hz through 1.6 MHz,
give added versatility to the noise generator. These
clock rates allow selectable noise bandwidths variable
from 10 Hz to 100
1
3
4
7
11
13
13
13
16
21
21
- 1 bits.
