LEG 1
USE THE SMALLER SCREWS & MILDLY SECURE THE RODS
BELOW THE TRAINGULAR PORTION (LEGS 1&2)
USE ONLY KNOB
PLACE THE RODS ON THE LEGS WITHOUT
STEP 1
PLACE THE TRIANGULAR LEGS (LEGS 1&2) PARALLEL TO
EACH OTHER AND POSITION THE RODS BETWEEN THE
LEGS.
LEG 2
WITH THE ALLEN KEY
MILDLY SECURE THE SCREWS &
DON'T OVER TIGHTEN OR TWIST ROD
STEP 3
USE THE TWO LONG SCREWS TO SECURE THE RODS IN
TRIANGULAR PORTION (LEGS 1&2) WITH THE ALLEN KEY
MILDLY SECURE THE SCREWS &
DON'T OVER TIGHTEN OR TWIST ROD
USE LONGER SCREW
ALONG WITH OTHER
LEG & ROD
THE TRIANGLES (LEGS 3&4)
*DON'T SECURE THE TOP ROD*
PIKLER TRIANGLE
INSTRUCTION MANUAL
STEP 2
STEP 4
1
USE ONLY KNOB
TOP ROD
POSITION
