FRONT FORK
BODY
BACK REST
CENTER SUPPORT
2 Inch - 3 Nos
ALLEN SCREWS WITH KEYS
2 STAR SCREWS
2 Inch Allen
Screw here
TUK TUK - THE TRICYCLE
INSTRUCTION MANUAL
BACK AXLE
WITH WHEEL
RING
BACK
SUPPORT
STEP 1
ATTACH THE BACK AXLE WITH
WHEEL TO BACK SUPPORT AND
MILDLY SECURE WITH THE 2 BIG
ALLEN SCREWS USING ALLEN
KEYS
FRONT FORK
WITH WHEEL
HANDLE BAR
Advertisement
Summary of Contents for ariro Tuk Tuk - The Tricycle
- Page 1 TUK TUK - THE TRICYCLE INSTRUCTION MANUAL BACK AXLE WITH WHEEL FRONT FORK FRONT FORK BODY RING WITH WHEEL BACK SUPPORT BACK REST CENTER SUPPORT 2 Inch - 3 Nos HANDLE BAR ALLEN SCREWS WITH KEYS 2 STAR SCREWS STEP 1...
- Page 2 STEP 2 ATTACH THE CENTER SUPPORT TO BACK SUPPORT AS SHOWN USING ONE SMALL ALLEN SCREWS. MILDLY SECURE THEM STEP 3 NOW FIX THE BODY USING SMALL ALLEN SCREWS AS SHOWN. SECURE THEM TO BE STURDY STEP 4 NOW INSERT THE FRONT FORK WITH WHEEL INSIDE THE HOLE IN BODY...
- Page 3 STEP 5 NOW INSERT THE FRONT FORK RING INTO THE FRONT FORK WITH WHEEL AS SHOWN IN THE IMAGE STEP 6 SECURE THE RING TO FORK USING THE STAR SCREWS PROVIDED. SECURE THEM THROUGHLY STEP 7 2 Inch Allen Screw here NOW SECURE THE HANDLE BAR TO THE FORK USING THE ALLEN SCREWS...
- Page 4 STEP 7 FINALLY SECURE THE BACK REST TO THE BODY USING ALLEN KEYS www.arirotoys.com help@arirotoys.com/ +91 89399 92452...
