Schon LT400 Installation

Please leave this sheet and warranty for the customer for future reference
Faucet Installation
Fig. 1
S-01
S-38
S-37 (ALLEN WRENCH)
Step 1- Install spout S-01 into
faucet body by pushing straight
down. Align spout facing forward
then tighten with allen screw S-38
(packaged separately with allen
wrench S-37). Do Not Over Tighten.
Fig. 4
TUB
DRAIN
**NOTE: If using optional support brace U-SBRC
proceed to step 4a on page 2.
Step 4- Slide decorative escutcheons S-23 onto
bottom of risers S-21 and push part way up. Screw
floor flanges S-24 onto bottom of riser threads S-21.
Step 5- Drill two 1-1/8" holes in floor on 8" centers in
desired location. Drop risers through holes and secure
to floor using floor flanges S-24 and appropriate
screws/bolts (not included).
Step 6- Slide decorative escutcheons S-23 down to
floor to cover floor flanges.
For additional assistance or service call:
Para servicio o ayuda adicional, Ilame al:
Fig. 2
S-07
S-08
C-FB1
S-21
C-FRSR
WHEN USING THE U-SBRC SUPPORT BRACE
IT MUST BE INSTALLED ON C-FRSR RISERS
PRIOR TO SECURING TO FLOOR.
Step 2- Attach hot and cold risers S-21
WASHER
SEE INSTALLATION ON PAGE 20.
to union nuts S-07 on back of faucet
(Tub model LCAT-167 does not have an exposed
body using one S-08 gasket on each drain and support brace will not be used.)
riser.
OPTIONAL SUPPORT
BRACE U-SBRC
S-21
S-23
S-24
MIN. 3-3/4"
MAX. 5-1/2"
Model LT400 (Lever Handles)
Model LT500 (Cross Handles)
S-01
Fig. 5
S-20
Step 7- Attach small end of
handshower hose S-18 with
washer S-20 to outlet below
diverter faucet spout.
Step 8- Attach large end of hand
shower hose S-18 to handshower
S-19 with washer S-20 and place
in holder S-05.
1 800 880-8164 USA
8 a.m. to 6 p.m. EST Monday-Sunday
Screw
S-32
S-12
S-10
C-HCRS
S-33
Step 3- Screw handle hub S-32
OR S-33 onto hot/cold cartridges
S-10 & S-12. Disassemble handle by
unscrewing spokes and install onto
cartridge. Secure with screw included.
Reassemble handle.
S-19
S-20
S-05
S-18
Step 9- Connect
preferred ½" male pipe
(supplied by installer)
into female threaded
riser S-21 from under
flooring. Make hot/cold
water connections. Turn
on water and check all
connections for leaks.
LT400 LT500 (v2) (09/04/08) ©SCHON 2008
Fig. 3
C-HLVR
Spokes
Spokes
