Summary of Contents for AREBOS AR-HE-HS2000CRS/B
- Page 1 User’s Manual – A S Patio Heater 2000W REBO Patio Heater 2000W AR-HE-HS2000CRS/B AR-HE-HS2000WRS/B Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Table Of Contents
User’s Manual – A S Patio Heater 2000W REBO Table of Contents 1. Safety Instructions ......3 1.1 Explanation of the symbols ......................3 1.2 General safety instructions ......................3 1.3 Intended use ..........................5 1.4 Improper use ..........................5 2. -
Page 3: Safety Instructions
User’s Manual – A S Patio Heater 2000W REBO Please read and save these instructions. Read through this user’s manual carefully before using this product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. - Page 4 User’s Manual – A S Patio Heater 2000W REBO by children without supervision. • Children younger than 3 years must be kept away unless they are supervised at all times. • Children aged 3 years and under and under 8 years may only switch the appliance on and off if they are supervised or have been instructed in the safe use of the appliance and understand the resulting hazards, provided that the appliance is placed or installed in its normal position of use Children aged 3 years and under 8 years must not insert the plug into the socket, regulate the...
-
Page 5: Intended Use
User’s Manual – A S Patio Heater 2000W REBO 1.3 Intended use Use the appliance to heat surfaces in covered and uncovered outdoor areas. • The appliance is designed for domestic use and is not suitable for commercial use. • •... -
Page 6: Heater Components
User’s Manual – A S Patio Heater 2000W REBO 2. Heater Components Aluminium box Plastic cover Aluminium fuselage Heating tube Power cord Right housing LED displayer Protection grille 3. Technical Data Model AR-HE-HS2000WRS AR-HE-HS2000CRS AR-HE-HS2000WRB AR-HE-HS2000CRB Voltage AC 220V-240V AC 220V-240V Frequency 50Hz/60Hz 50Hz/60Hz... -
Page 7: Assembly
User’s Manual – A S Patio Heater 2000W REBO 4. Assembly 4.1 Wall mounted function 1. There are 4 brackets and fasteners used with the heater. Furthermore, in the canal of back side of the heater there are 4 square fastener washers 25×25mm. Take the square washers and fasten 2 brackets to the canal of the backside of the heater by the help of screws (Figure 1). -
Page 8: With Heater Holder Function
User’s Manual – A S Patio Heater 2000W REBO 4. Join the brackets on the heater with the brackets, fastened on the wall, with the help of figured screw-nuts (Figure 4). Install the heater under necessary angle (in the direction to the area being heated). - Page 9 User’s Manual – A S Patio Heater 2000W REBO Connect the heater body with the holder: 1. Place 4x feet (1.1) into the slots on the bottom of the base (1.3) of the pole (2). 2. Tighten pole (2) into the stand center (1.2) by turning the pre-attached stand center cover clockwise until tight.
- Page 10 User’s Manual – A S Patio Heater 2000W REBO 5. Use M5x10 (4x) screws attach the fixed support (2x) to the back panel of device. 6. Loosen the Fixing knobs “ ” (2X) of the holder, then assemble the device and the holder as shown following.
-
Page 11: Operation Of Remote Control
User’s Manual – A S Patio Heater 2000W REBO 7. Now the device is attached with the holder. The heater is now ready to use. Ensure you have read these instructions thoroughly prior to use. 5. Operation of Remote Control The functions of the heater may be controlled via the buttons on your remote control and LED •... -
Page 12: Maintenance And Cleaning
User’s Manual – A S Patio Heater 2000W REBO 2. Press in the remote to make the heater standby. 3. Press to increase the power until F9. 4. Press to decrease the power until F1. 5. Press ,the heater is in half of full power. 6. -
Page 13: Disposal Instruction
You can also find more information on the Battery Act on the Internet at www.batteriegesetz.de. You can also visit our website at www.arebos.de to find out about other return options we have created. Our customer service number: +49 (0) 931-45232700... -
Page 14: Eu Declaration Of Conformity
Authorised representative for the technical documentation: Korhan Canbolat Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10-11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
