Summary of Contents for CAN FO5000
- Page 1 INSTRUCTION BOOKLET FO5000 FO5010 BUILT-IN OVENS WITH GRILL INSTALLATION MAINTENANCE...
- Page 2 GENERAL INFORMATION Additional information for installers and users. The manufacturer CAN S.r.l. reserves the right to make changes to its products and to this manual as it deems necessary, without any obligation to provide notification. Drawings, installation diagrams and tables contained in the manual are to be considered indicative and for information purposes only.
- Page 3 CE TEST CERTIFICATE issued by IMQ S.p.a., notified body with identification number 0051 The undersigned, Paolo Moresco, acting as CEO of the company CAN S.r.l., assumes all liability for the veracity of the statements made so far. Puegnago del Garda, 01/01/2020...
-
Page 4: Table Of Contents
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series TABLE OF CONTENTS TECHNICAL DATA SHEET — FO5000 ..................... 5 TECHNICAL DATA SHEET — FO5010 ..................... 7 GENERAL PRELIMINARY INFORMATION ..................9 INTENDED USE ..........................10 OBLIGATIONS AND RESTRICTIONS ....................11 OBLIGATIONS ..........................11 RESTRICTIONS .......................... - Page 5 PROCEDURES TO FOLLOW IN THE EVENT OF MALFUNCTIONING ..........32 MAINTENANCE AND CLEANING ....................33 PROLONGED PERIODS OF INACTIVITY ..................34 DISPOSAL ............................. 34 WARRANTY ..........................34 SPARE PARTS ..........................35 SPARE PARTS FO5000 ........................35 SPARE PARTS FO5010 ........................36 NOTES ............................37 FO Series – ed. 01/2020...
-
Page 6: Technical Data Sheet - Fo5000
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series TECHNICAL DATA SHEET — FO5000 SIZE Width: 457 mm (closed product footprint) Depth: 563 mm Height: 446 mm Weight: 25.20 kg OVEN 1 x OVEN burner: Thermostat with By-Pass ø 0.44 mm Pn 1.80 kW —... - Page 7 BUILT-IN GAS OVENS WITH GRILL ▪ FO Series GAS CAPILLARIES Copper capillary tubes Ø 4 mm — thickness 0.5 mm Aluminium capillary tubes Ø 4 mm — thickness 0.8 mm MATERIALS Stainless steel AISI 304 Glass Aluminium chrome-plated steel Zamak brass copper galvanized iron...
-
Page 8: Technical Data Sheet - Fo5010
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series TECHNICAL DATA SHEET — FO5010 SIZE Width: 457 mm (closed product footprint) Depth: 446 mm Height: 439 mm Weight: 21.10 kg OVEN 1 x OVEN burner: Thermostat with By-Pass ø 0.44 mm Pn 1.80 kW —... - Page 9 BUILT-IN GAS OVENS WITH GRILL ▪ FO Series GAS CAPILLARIES Copper capillary tubes Ø 4 mm — thickness 0.5 mm Aluminium capillary tubes Ø 4 mm — thickness 0.8 mm MATERIALS Stainless steel AISI 304 Glass Aluminium chrome-plated steel Zamak brass copper galvanized iron...
-
Page 10: General Preliminary Information
A copy of this manual is always available for consultation and download on the website www.cansrl.com WARNING! CAN S.r.l. disclaims any liability for uses other than those indicated. Do not use this device for heating environments. WARNING! Do not tamper with the equipment, unless the modification is authorized and carried out by the manufacturer or its authorized technicians. -
Page 11: Intended Use
WARNING! The appliance is equipped with a glass lid. Glass lids can crack if overheated or hit by blunt objects. Always open the lid before turning on any burner and take care to turn off the burners and let them cool for a few minutes before closing the glass lid at the end of each cooking session. -
Page 12: Obligations And Restrictions
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series OBLIGATIONS AND RESTRICTIONS OBLIGATIONS • The place of installation of the equipment must have a suitable ventilation system, compliant with industry regulations, in good condition and perfectly functioning, as well as properly sized for the purpose. -
Page 13: Identification Of The Equipment
Types of gases allowed for the supply of the device (references to EN 437 and EN 30- 1-1) COUNTRIES OF USE Countries where a given gas supply category/pressure can be used among those indicated in the “CATEGORIES/ PRESSURES” boxes (references to EN 437 and EN 30- 1-1) -
Page 14: Equipment Delivery
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series EQUIPMENT DELIVERY The equipment is delivered to the customer in a cardboard box (A), protected by moulded polystyrene shells (B) to avoid damage during transportation and storage. Inside the box, in addition to the equipment, there is also the installation, operation and maintenance manual (C), CONTROL AND MAINTENANCE Upon receipt of the equipment, proceed with unpacking. -
Page 15: Disposal Of Packing
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series DISPOSAL OF PACKING The materials used for packaging are recyclable and must be collected according to local rules on separate collection. CAUTION! Separate the various materials constituting the packaging and dispose of them in compliance with the regulations in force in the country of installation. -
Page 16: Instructions For The Installer
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series INSTRUCTIONS FOR THE INSTALLER CAUTION! Installation and all interventions on the equipment described in this instruction manual must be carried out by qualified technical staff in compliance with current regulations. CAUTION! Always wear personal protective equipment (PPE) suitable for the type of operation/processing being carried out. -
Page 17: Installation On Support Structure
RECESSED HOLE MEASUREMENTS AND SAFETY DISTANCES MODEL FO5000 FO Series – ed. 01/2020... -
Page 18: Positioning The Equipment
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series RECESSED HOLE MEASUREMENTS AND SAFETY DISTANCES MODEL FO5000 If the equipment will be installed on top of any other live appliance, it will be necessary to arrange a suitable separation panel between the two devices. -
Page 19: Gas Connection
Verify that the type of gas with which the equipment will be supplied is among those permitted and listed in this instruction manual (see section “Gas categories”). CAN S.r.l. denies any liability for incorrect connections, not performed in accordance with the rules or performed by unqualified persons. -
Page 20: Connection Tube Requirements
The connection of the equipment to the gas pipeline shall be carried out by means of a suitable connection pipe with the use of certified sealing fittings of the most suitable type for the application. Flexible connection pipes can be used. They shall: • always be easy to inspect, •... -
Page 21: Wiring
The products to which this manual refers are equipped with electronic ignition and are, therefore, equipped with a spark generator supplied in direct current at very low voltage (12 V DC) for the ignition of the burners. The generator is located on the back panel of the product and can be easily inspected. - Page 22 BUILT-IN GAS OVENS WITH GRILL ▪ FO Series To connect the generator to the local low-voltage electricity distribution network, follow these steps: STEP ACTION Connect the free end of the NEGATIVE (-) black conductor to the negative pole of the network terminals or an accumulator.
-
Page 23: Troubleshooting After Installation
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series TROUBLESHOOTING AFTER INSTALLATION If the appliance is not working properly after installation, perform the checks given in the table. problem possible solutions There is a smell of gas near Check that the gas valves are completely closed. If the problem the appliance persists, disconnect the equipment from the gas network and request technical assistance... -
Page 24: User Instructions
NUT M 13X1 VALVE FIXING BLACK/CHROME-PLATED KNOB DIAM. 34 LOW-PROFILE 90° UNIPOLAR SWITCH 3° RED KEY BULB/CABLE FASTENER 2 WAY 12 V ELECTRIC GENERATOR BOTTOM WALL FO5000 RAMP FIXING BRACKET FOR CU5010 FIBER GLASS FOR FO5010 SELF-TAPPING SCREW FO Series – ed. 01/2020... - Page 25 BUILT-IN GAS OVENS WITH GRILL ▪ FO Series FO5000 EXPLODED VIEW FO Series – ed. 01/2020...
- Page 26 UNIPOLAR SWITCH 3° RED KEY BULB/CABLE FASTENER 2 WAY 12 V ELECTRIC GENERATOR RAMP FIXING BRACKET FOR CU5010 LID. CL. SBF F/G. TILT./65 1000 THERM CND 350 BOTTOM WALL FO5000 FIBER GLASS FOR FO5010 SELF-TAPPING SCREW FO Series – ed. 01/2020...
- Page 27 BUILT-IN GAS OVENS WITH GRILL ▪ FO Series FO5010 EXPLODED VIEW FO Series – ed. 01/2020...
-
Page 28: Safety Warnings During Use
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series SAFETY WARNINGS DURING USE CAUTION! During operation and for a few minutes after use, some parts of the equipment reach very high temperatures. Do not come in contact with these parts without adequate personal protective equipment. -
Page 29: Use
The control knob on the gas valve, when rotated counter clockwise activates and controls the oven function, while when rotated clockwise all the way, it activates the grill function. The burners can’t work simultaneously. CAUTION! Before use, check that the external components of the burners are firmly connected to their supports. -
Page 30: Ignition And Use Of The Device In Oven Mode
5 seconds (always keeping it at the MIN mark) and then release it, adjusting the temperature desired. The device can reach a maximum temperature of 200° C Note: this release delay is used to heat the safety thermocouple. -
Page 31: Food Cooking Or Heating
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series FOOD COOKING OR HEATING WARNING! Do not forget the device turned on with the burners running without pans or with empty pans CAUTION! Never cook food directly in contact with the walls or the bottom of the oven cavity. Fire hazard. -
Page 32: Switching On/Use Of The Device In Grill Mode
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series SWITCHING ON/USE OF THE DEVICE IN GRILL MODE CAUTION! When using the oven in GRILL cooking mode, the oven door must always remain fully open. Always pull out the deflector for better protection against heat of the control panel and control units. -
Page 33: Operation Anomalies
CAN S.r.l. ensures optimal collaboration and support if technical or other type of problems should arise, on any of its products. For any information or assistance request contact your nearest retailer or get in touch with CAN S.r.l. FO Series – ed. 01/2020... -
Page 34: Maintenance And Cleaning
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series MAINTENANCE AND CLEANING No specific maintenance procedures are required for the equipment except for proper and regular cleaning. No specific maintenance procedures are required for the equipment except for proper and regular cleaning. -
Page 35: Prolonged Periods Of Inactivity
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series After cleaning make sure that you have correctly reassembled the grills and any accessories removed, taking care not to reverse their positions. The grills must always be stable and their inlets into the equipment must be unobstructed. PROLONGED PERIODS OF INACTIVITY If you plan not to use the equipment for a long period of time (more than 2-3 weeks) proceed as follows:... -
Page 36: Spare Parts
For easier recognition of spare parts, the tables below should be read together with the exploded drawings in the section “Description”. SPARE PARTS FO5000 For better identification of spare parts, coordinate with the “EXPLODED VIEW FO5000" on page 24. CODE ITEM... -
Page 37: Spare Parts Fo5010
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series SPARE PARTS FO5010 For better identification of spare parts, please refer to the “EXPLODED VIEW FO5010" on page 26. CODE ITEM PART PART 2000019 COMPLETE DOOR FO5010 2000321 OVEN DRIP TRAY FO5010 3001102 OVEN WIRE GRILL FO5010 WIRE FRAME FOR GRILES AND DRIP TRAYS (SINGLE PIECE) -
Page 38: Notes
BUILT-IN GAS OVENS WITH GRILL ▪ FO Series NOTES ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________... - Page 39 BUILT-IN GAS OVENS WITH GRILL ▪ FO Series ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________...
- Page 40 BUILT-IN GAS OVENS WITH GRILL ▪ FO Series CAN S.r.l. Via Nazionale 65, 25080 Puegnago del Garda – (BS) ITALY www.cansrl.com info@cansrl.com ph. +39 0365 555909 fax. +39 0365 651822 FO Series – ed. 01/2020...
