- Page 1 PRODUCT MANUAL Elite Hand Pallet Truck E2500PTS Serial Number Range: Year Of Manufacture: KEEP THIS BOOKLET FOR FUTURE REFERENCE Nottingham: 0115 946 1988 www.hscgroupuk.co.uk London: 0208 830 3333 The Hire Supply Company (UK) Limited Nottingham: sales@hscgroupuk.co.uk London: sean@hscgroupuk.co.uk...
- Page 2 (85mm standard & 75mm profile) Note: Owner and operator MUST read and understand this operating instructions before using this pallet truck. HSC Industrial and Commercial Equipment (EU) Limited. First Floor, Penrose 1, Penrose Dock, Cork, T23 KW81. IRELAND. Registered No.: 689232...
-
Page 3: General Specifications
ATTENTION: 1. To prevent possible harm to the environment or human health from uncontrolled waste disposal recycle waste packaging where possible. Recycle responsibly to promote the sustainable reuse of valuable raw materials. 2. In the event of unexpected leaking it is recommended a spill kit with absorbent materials is readily available. - Page 4 (Fig. 1) 1. Handle 2. Pin 3. Axle with hole 4. Split pin 5. Fork frame When attaching the handle, position yourself behind the pallet truck. Then follow the sequenced instructions: 2.1. Insert the handle onto the pump piston (A), then use a hammer to insert the axle with hole (K) into the hydraulic pump and handle from the right to left.
-
Page 5: To Adjust Release Device
3. TO ADJUST RELEASE DEVICE On the handle of this pallet truck, you can find the control lever which can be regulated in three positions : Raise - lever down Drive position - lever in center position Lower - lever up, the lever moves back the drive position when released. If however they have been changed, you can adjust according to following step: 3.1 If the forks elevate while pumping in the DRIVE position, turn the adjusting nut on the adjusting bolt or adjusting screw clockwise until pumping action does not raise the forks and the DRIVE... -
Page 6: Troubles Shooting
4.4 LUBRICATION Use motor oil or grease to lubricate all moveable parts. 5. GUIDE TO SAFETY OPERATION For safe operation of the Hand Pallet Truck, please read all warning signs and instructions here and on the pallet truck prior to use. 5.1 Do not operate the pallet truck unless you are familiar with it and have been trained or authorized to do so. - Page 7 - The impurities in the oil cause the release valve to be unable to close - Replace with new oil. tight. fork - Inspect and replace the waste lowers - Some parts of hydraulic system is parts. without cracked or bored. - Remove the air.
- Page 8 General parts for PWH25-II/PWH30-II/PWH35-II Part No. Description Part No. Description 17010101 Handle assembly 17010116 PU Steering wheel Ø180*50 17010102 Chasis (540*1150) (2.5T/3T) 17010117 Nylon Steering wheel Ø180*50 17010102-1 Chasis (685*1220) (2.5T/3T) 17010116-1 PU Steering wheel Ø200*50 17010102-2 Chasis (540*1150) (3.5T) 17010117-1 Nylon Steering wheel Ø200*50 17010102-3 Chasis (685*1220) (3.5T) 17010116-2 Rubber Steering wheel Ø180*50...
- Page 9 General parts for WH20L-65/WH25L-65 with 65mm profile & PWH25-II-75 with 75mm profile New P/N Description New P/N Description 17010101 Handle assembly 17010124 Axle 16×40 17010102 Chasis (540*1150) (75 low profile) 17010143 Locknut M6 17010102-1 Chasis (685*1220) (75 low profile) 17010126 Rod end 17010102-2 Chasis (540*1150) (65 low profile)
- Page 10 Pump & handle parts details PWH25-II PWH30-II Part No. Description Item Parts No. Parts details 17010201 Small pump core 17010316 Draw-bar 17010202 Cover of spring 17010327 Torsional Spring 17010205 Big spring 17010310 Blade Spring 17010332 Pump seals kit Ø31.5 for 2.5T/3T 17010311 Spring Pin 4x30 17010360 Small cylinder 17010314 Spring Pin 6x30...
- Page 11 Pump & handle parts details for PWH35-II Item Parts No. Parts details Qty. Item Parts No. Parts details Qty. 17010201 Small pump core 17010316 Draw-bar 17010202 Cover of spring 17010327 Torsional Spring 17010205 Big spring 17010310 Blade Spring 17010332-1 Pump seals kit Ø35 for 3.5T 17010311 Spring Pin 4x30 17010360...
- Page 12 Pump & handle parts details WH20L-65/WH25L-65 & PWH25-II-75 with 75mm profile New P/N Description QTY Item Parts No. Parts details Qty. 17010201 Small pump core 17010316 Draw-bar 17010202 Cover of spring 17010327 Torsional Spring 17010205 Big spring 17010310 Blade Spring 17010332 Pump seal kits 17010311 Spring Pin 4x30 17010360 Small cylinder...
- Page 13 Recycling ENVIRONMENTAL PROTECTION: Please recycle any unwanted materials as opposed to disposing them as general waste. It is recommended the original is retained and used to store the product when not in use for prolonged periods of time. If this is not applicable ensure the materials are sorted and recycled in accordance with local regulations SPECIFICATION CHANGE: It is our policy to continually improve products to ensure these meet the rigours of the industry we serve.
