Habitat Radius RADI-3D-SS15-A Assembly Instructions

3 drawer chest

Download this manual

Radius 3 Drawer Chest

Assembly Instructions — Please keep for future reference

Note: There are 'Batch Code' lables where shown on the indicated items, these should be retained.

Important — Please read these instructions before assembly

If you need help or have damaged or missing parts, email:

customerservices@habitat.co.uk

0344 499 4686

or call:

RADI-3D-SS15-A

Dimensions

Width - 90cm

Depth - 48cm

Height - 86cm

Tools required

Need help?

Do you have a question about the Radius RADI-3D-SS15-A and is the answer not in the manual?

Page 1 Note: There are 'Batch Code' lables where shown on the indicated items, these should be retained. Important — Please read these instructions before assembly If you need help or have damaged or missing parts, email: customerservices@habitat.co.uk 0344 499 4686 or call:...
Page 2 Please retain your receipt as Received, please contact the store problems with your Habitat proof of purchase. or Habitat Head Office via its web product, please contact the store site: www.habitat.co.uk from which you purchased it. If you have any comment or...
Page 3 Fitting Wall Strap Step 1 R x 1 Warning : Due to the height of this piece of furniture we strongly recommend that it is attached securely to the wall using the wall strap provided. We have provided a screw for attaching the wall strap to furniture but you must assess the type of wall you want to fit it to and provide the appropriate type of wall fitting.
Page 4 1: General rule: Always use a larger screw and wall plug if you are not sure. different wall types, Habitat cannot provide you with the 2: Ensure you use the recommended drill bit to match the wall exact ﬁxings you will need to plug and hole size.
