Beam i Series Quick Start Manual

Safety information
The BEAM 5i and BEAM 8i router must be used in compliance with any and all applicable national and international laws
and with any special restrictions regulating the utilization of the communication module in prescribed applications and
environments
Hereby, Mobile Onboard declares that this BEAM 5i and 8i router is in compliance with the essential
requirements and other relevant provisions of Directive CE/RED.
For more information
Need help or more detailed information?
Visit the BEAM Onboard Owner Portal for complete,
detailed documentation on the BEAM iSeries routers.
owner.beamonboard.com
Visit our main website for all our products and services.
www.beamonboard.com
Trusted technology for transport
© BEAM Onboard 2022. All rights reserved. All specificationsare subject to change at anytime. E&OE
Automotive Router
Quick start guide
Front view
LCD status screen
Back view
Power socket Ethernet Mobile MAIN
antenna connector
Power socket Ethernet
Mobile AUX
antenna connector
GPS antenna connector
Power socket
pinout
USB (type A)
Mobile AUX Not connected
antenna connector
Reset Wi-Fi antenna
button connector
Mobile MAIN
antenna connector
Reset button
Wi-Fi antenna connectors
Positive / Red wire
Negative / Black wire
