Summary of Contents for NOVO CTCER30
- Page 1 Ceramic Hob Instruction Manual / Installation Manual MODEL: YL-CD3004 Model CTCER30 CTCER60-3 CTCER60-4 CTCER30-4V...
-
Page 2: Safety Warnings
Safety Warnings Your safety is important to us. Please read this information before using your cooktop. Installation Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory. -
Page 3: Health Hazard
installation. • This appliance is to be properly installed and earthed only by a suitably qualified person. • This appliance should be connected to a circuit which incorporates an isolating switch providing full disconnection from the power supply. • Failure to install the appliance correctly could invalidate any warranty or liability claims. - Page 4 • Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot • Keep children away. • Handles of saucepans may be hot to touch. Check saucepan handles do not overhang other cooking zones that are on.
- Page 5 • Do not allow children to play with the appliance or sit, stand, or climb on it. • Do not store items of interest to children in cabinets above the appliance. Children climbing on the cooktop could be seriously injured. •...
- Page 6 hazard. •This appliance is intended to be used in household and similar applications such as: -staff kitchen areas in shops, offices and other working environments; -farm houses; -by clients in hotels, motels and other residential type environments ; -bed and breakfast type environments.
- Page 7 •WARNING: Danger of fire: do not store items on the cooking surfaces. • Warning: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock, for hob surfaces of glass-ceramic or similar material which protect live parts •A steam cleaner is not to be used.
-
Page 8: Product Overview
Product Overview CTCER30 1. max. 200mm 1800 W zone 2. max. 165mm 1200 W zone 3. Control panel 4. Glass plate 1.Heating zone selection controls 2.Timer control 3.Power / Timer regulating controls 4.Child key/lock control 5.ON/OFF control... - Page 9 CTCER60-3 1. max. 200mm 1800 W zone 2. max. 165mm 1200 W zone 3. max. 230/175/120mm 2300/1600/800W zone 4. Glass plate 5. Control panel 1.Cooking zone indicator 2.Timer control 3.Power / Timer regulating controls 4.Child key/lock control 5.ON/OFF control 6.Triple ring control...
- Page 10 CTCER60-4 /CTCER30-4V 1. max. 200mm 1800 W zone 2. max. 165mm 1200 W zone 3. max. 230/138 mm 2200/1000 W zone 4. max. 165mm 1200 W zone 5. Glass plate 6. Control panel 1.Cooking zone indicator 2.Timer control 3.Power / Timer regulating controls 4.Child key/lock control...
-
Page 11: Product Information
Product Information The microcomputer ceramic cooker hob can meet different kinds of cuisine demands because of resistance wire heating, micro-computerized control and multi-power selection, really the optimal choice for modern families. The ceramic cooker hob centers on customers and adpots personalized design. The hob has safe and reliable performances, making your life comfortable and enabling to fully enjoy the pleasure from life. - Page 12 Always centre your pan on the cooking zone. Always lift pans off the ceramic hob – do not slide, or they may scratch the glass. Using your Ceramic Hob - CTCER30 When you have finished cooking 1.
-
Page 13: Using The Timer
4. Beware of hot surfaces “H” will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature. It can also be used as an energy saving function if you want to heat further pans, use the hotplate that is still hot. Using the Timer You can use the timer in two different ways: •... - Page 14 If the setting time exceeds 99 minutes, the timer will automatically return to 0 minute. 4. Touching the ‘Timer’, the timer is cancelled,and the”--“ will show in the minute display. 5. When the time is set, it will begin to count down immediately.
- Page 15 3. Set the time by touching the control of the timer Hint: Touch the “-“ or “+” control of the timer once will decrease or increase by 1 minute. Touch and hold the “-“ or “+” control of the timer will decrease or increase by 10 minutes.
-
Page 16: Using Your Ceramic Hob
Using your Ceramic Hob - CTCER60-3/CTCER60-4/CTCER30-4V To start cooking • After power on, the buzzer beeps once, all the indicators light up for 1 second then go out, indicating that the ceramic hob has entered the state of standby mode. -
Page 17: When You Have Finished Cooking
When you have finished cooking 1. Select a heat setting by touching the control of this zone. 2. Turn the cooking zone off by scrolling down to “0” and then display will show “-”. 3. Turn the whole cooktop off by touching the ON/OFF control. 4. -
Page 18: Using The Timer As A Minute Minder
Using the Timer as a Minute Minder If you are not selecting any cooking zone 1. Make sure the cooktop is turned on and at least one cooking zone is working. Note: you can use the minute minder even if you’re not selecting any cooking zone. - Page 19 Setting the timer to turn one cooking zone off 1. Touch the of the corresponding cooking zone you want to set the timer for. 2. Set the time by touching the control of the Timer, and touch to set the power to the level you want.
- Page 20 NOTE: If you want to change the time after the timer is set, you have to start from step 1 Setting the timer to turn more than one cooking zone 1. If more than one heating zone use this function, the timer indicator will show the lowest time.
-
Page 21: Locking The Controls
Locking the Controls • You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). • When the controls are locked, all the controls except the ON/OFF control are disabled. To lock the controls Touch the keylock control. -
Page 22: Cooking Guidelines
Cooking Guidelines Take care when frying as the oil and fat heat up very quickly, particularly if you’re using PowerBoost. At extremely high termperatures oil and fat will ignite spontaneously and this presents a serious fire risk. Cooking Tips • When food comes to the boil, reduce the temperature setting. •... -
Page 23: Heat Settings
4. Cook any meat first, put it aside and keep warm. 5. Stir-fry the vegetables. When they are hot but still crisp, turn the cooking zone to a lower setting, return the meat to the pan and add your sauce. 6. -
Page 24: Care And Cleaning
Care and Cleaning What? How? Important! Everyday soiling on 1. Switch the power to the • When the power to the cooktop is glass (fingerprints, cooktop off. switched off, there will be no ‘hot marks, stains left by 2. Apply a cooktop cleaner while surface’... -
Page 25: Hints And Tips
This is normal for cookware and crackling or clicking construction of your cookware does not indicate a fault. noises. (layers of different metals vibrating differently). Technical Specification Model CTCER30 CTCER60-3 Cooking Zones 2 Zones 4 Zones Supply Voltage 220-240V~ 50/60Hz 220-240V~ 50/60Hz Installed Electric Power... -
Page 26: Installation
Model CTCER60-4 CTCER30-4V Cooking Zones 4 Zones 4 Zones Supply Voltage 220-240V~ 50/60Hz 220-240V~ 50/60Hz Installed Electric Power 5490-6533W 5490-6533W Product Size W×D×H(mm) 590X520X52 590X520X52 Building-in Dimension (mm) 560X490 560X490 Weight and Dimensions are approximate. Because we continually strive to improve our products we may change specifications and designs without prior notice. -
Page 27: Before Locating The Fixing Brackets
Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air inlet and outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As shown below Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm. -
Page 28: Connecting The Hob To The Mains Power Supply
6. A steam cleaner is not to be used. Connecting the hob to the mains power supply The power supply should be connected in compliance with the relevant standard, or a single-pole circuit breaker. The method of connection is shown below. CTCER30... - Page 29 CTCER60-3/CTCER60-4/CTCER30-4V 220-240V~ 220-240V~ Input Input 220-240V~ N1 N2 Power Cord Power Cord 220-240V~ 400V~ Input Input 220-240V~ 400V~ Power Cord Power Cord...
- Page 30 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents. 2. If the appliance is being connected directly to the mains supply, an omnipolar circuit breaker must be installed with a minimum gap of 3mm between the contacts.
