instructions for
installation and servicing
(For qualified persons)
AIR DESTRATIFIER VENTILATORS
Appliance types:
LLV-400
LLV-450
LLV-500
LLV-650
LLV-800
www.pakole.com
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LLV-400 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pakole LLV-400

  • Page 1 (For qualified persons) AIR DESTRATIFIER VENTILATORS Appliance types: LLV-400 LLV-450 LLV-500 LLV-650 LLV-800 www.pakole.com...
  • Page 2: Table Of Contents

    LLV Air destratifier ventilator family Contents Contents 1. Safety information ������������������������������������������������������������������������������������������������������������������������������������3 2. General Instruction �����������������������������������������������������������������������������������������������������������������������������������4 Data board ��������������������������������������������������������������������������������������������������������������������������������������������������4 Installer’s responsibilities ����������������������������������������������������������������������������������������������������������������������������4 Corrosive materials ������������������������������������������������������������������������������������������������������������������������������������5 Standards and laws ������������������������������������������������������������������������������������������������������������������������������������5 Safety signs �������������������������������������������������������������������������������������������������������������������������������������������������5 Safe usage ��������������������������������������������������������������������������������������������������������������������������������������������������5 3. Transportation, unpacking, handling ����������������������������������������������������������������������������������������������������6 4. Operation principle ����������������������������������������������������������������������������������������������������������������������������������7 5.
  • Page 3: Safety Information

    LLV Air destratifier ventilator family Instructions for Installation and Servicing Safety information GENERAL SAFETY WARNINGS! Failure to follow the warnings and instructions in the enclosed Installation and Maintenance Manual may result in seri- ous injury or property damage. The appliance may only be used by persons who have understood and followed the instructions in the Installation and Maintenance Manual! If you need help or information about the heater, such as installation instructions, contact the manufacturer.
  • Page 4: General Instruction

    The device is equipped with a data board, which is located on the outside of the device� The data board contains information on the type of appliance, the type of gas and the electrical connection� For example: Manufacturer Type LLV-650 PAKOLE Trade Kft. 8000 Székesfehérvár, Börgöndi út 8-10. IP protection: IP40...
  • Page 5: Corrosive Materials

    LLV Air destratifier ventilator family Instructions for Installation and Servicing Corrosive materials ATTENTION! Do not use the device in a place where there may be corrosive substances in the air! The manufacturer accepts no liability for damage to the device if it has not been installed as described above� This responsibility is en- tirely the responsibility of the person performing the design�...
  • Page 6: Transportation, Unpacking, Handling

    LLV Air destratifier ventilator family Instructions for Installation and Servicing • Never use the appliance in connection with another appliance� ATTENTION • Never leave tools or accessories inside or on top of the appliance� • Do not place the device in a flammable environment� FORBIDDEN ! • In the event of a malfunction, do not attempt to service the device, call your distributor immediately�...
  • Page 7: Operation Principle

    LLV Air destratifier ventilator family Instructions for Installation and Servicing Operation principle The device works on the principle of air circulation, which blows hot air accumulated in the upper third of the room back into the living zone, thus reducing heating losses due to air stratification� The device has a control electronics that allows two control modes�...
  • Page 8: Technical Data

    LLV Air destratifier ventilator family Instructions for Installation and Servicing Technical data LLV-400 / LLV-450 / LLV-500 3 figure: LLV-400 / LLV-450 / LLV-500 device dimensions LLV-650 / LLV-800 4 figure: LLV-650 / LLV-800 device dimensions Type LLV-400 LLV-450 LLV-500...
  • Page 9: Direction Of Airflow

    M8 nuts so that the high-pressure air does not turn them over� Slats folded out in two directions at 30 ° Slats extended in 45 ° in two directions For LLV 650-800 For LLV 400-500 devices Type LLV-400 LLV-450 LLV-500 LLV-650 LLV-800 Length of lamella Pieces of lamella pcs�...
  • Page 10: Installation Distances

    Installation distances In the case of under-ceiling installation, there must always be adequate space for testing the equipment� Min 250 mm Min 350 mm Min 400 mm LLV-400���500 LLV-650 LLV-800 Electrical connection • Check the laws / regulations for your installation location�...
  • Page 11: Connecting Cable Data

    LLV Air destratifier ventilator family Instructions for Installation and Servicing ATTENTION CAUTION CAUTION ELECTRIC COMPULSORY: DANGER SUPPLY EARTHING • Safe operation of the device is only established if it has been connected in accordance with the relevant safety regulations and is properly earthed�...
  • Page 12: Decommissioning

    LLV Air destratifier ventilator family Instructions for Installation and Servicing Decommissioning • Disconnect the device from the mains via the multi-pole switch� Improper use NEVER TUG OR TWIST THE ELECTRIC CABLE! Never push, pass through, or secure the power cord with a nail or pushpin� A damaged cable can cause a short circuit or physical injury� ATTENTION: When operating the appli- APPROPRIATE EXHAUST POSITION- ance, do not place any objects or clothing...
  • Page 13: Start

    LLV Air destratifier ventilator family Instructions for Installation and Servicing Start up PLEASE CHECK THE FOLLOWING POINTS BEFORE INSTALLING THE EQUIPMENT: • Mounting points for the device, on the ceiling, wall, etc� • The accuracy of the connection and wiring points of the equipment � • The available power supply�...
  • Page 14: Cleaning The Device

    LLV Air destratifier ventilator family Instructions for Installation and Servicing Cleaning the device Do not spray water on the unit as it may cause electric shock or damage to the unit� Do not use hot water, scouring powders or strong solvents for cleaning� If possible, avoid operating the appliance while cleaning the room�...
  • Page 15: Prevention Of Error

    LLV Air destratifier ventilator family Instructions for Installation and Servicing Prevention of error Error Occurrence Possible cause-control-solution • Obstructed airflow (intake / exhaust side): Remove the obstruction Poor airflow • The fan rotates in the opposite direction: Check the wiring diagram and the connections Excessive airflow • Install the unit higher Low static pressure...
  • Page 16 LLV Air destratifier ventilator family Instructions for Installation and Servicing Warranty and Service Keep this warranty card! Tyype: Serial number : Date of purchase: LIMITED WARRANTY * The manufacturer warrants to the customer that the product and its components are free from defects in material and workmanship�...
  • Page 17 LLV Air destratifier ventilator family Instructions for Installation and Servicing...
