INSTALLATION AND OPERATION MANUAL

Synapse

GXT100

Dual 3Gb/s, HD and SD input, frame synchronizer,

up/down/cross converter, embedder and de-

embedder

Version 1.00 | November 2021

Table of Contents

Need help?

Do you have a question about the Synapse GXT100 and is the answer not in the manual?

Questions and answers

Summary of Contents for EVS Synapse GXT100

Page 1 INSTALLATION AND OPERATION MANUAL Synapse GXT100 Dual 3Gb/s, HD and SD input, frame synchronizer, up/down/cross converter, embedder and de- embedder Version 1.00 | November 2021...
Page 3 You will find the full list of addresses and phone numbers on the following webpage: https://evs.com/contact/offices. User Manuals on EVS Website The latest version of the user manual, if any, and other user manuals on EVS products can be found at the EVS download center, on the following webpage: https://download-area.evs.com. Synapse GXT100 | Disclaimer |...
Page 4: General Information
NEVER bypass any fuse. NEVER replace any fuse with a value or type other than those specified. NEVER attempt to repair this product. If a problem occurs, contact your local EVS distributor. NEVER expose this product to extremely high or low temperatures.
Page 5: Table Of Contents
4. The GXT100 Card 5. Settings Menu 5.1. Introduction 5.2. System Settings 5.3. Up-Conv 5.4. Down-Conv 5.5. Cross-Conv 5.6. Transparent 5.7. Inserter 5.8. Video-Proc 5.9. Audio Proc Amp 5.10. Embedder 5.11. GPI Mode 5.12. Network 6. Status Menu Synapse GXT100 | Contents |...
Page 6 6.1. Introduction 6.2. System Status 6.3. Net Status 7. Events Menu 8. LED Indication 9. Block Schematic 10. Connector Panels Appendices Appendix 1: GPIs Explained Appendix 2: Quad Speed ADD-ON Bus GNU Public License ICONOGRAPHY Warning Note iv | November 2021 | Issue 1.00.B...
Page 7: What's New
The changes linked to new features in version 1.00 of GXT100 are listed below. SMPTE ST 352 Payload Identifier • See section "Inserter" on page 26. Synapse GXT100 | What's New? |...
Page 9: Introduction
Synapse is a modular system designed for the broadcast industry. High density, intuitive operation and high-quality processing are key features of this system. Synapse offers a full range of converters and processing modules. Please visit the EVS website at www.evs.com to obtain the latest information on our new products and updates.
Page 10: Unpacking And Placement
2. Unpacking and Placement Unpacking The EVS Synapse card must be unpacked in an anti-static environment. Care must be taken NOT to touch components on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging.
Page 11: Quick Start
Move up within a menu, or increase the value of a parameter. Move down through a menu or decrease the value of a parameter. When editing parameters, pressing ► twice will reset the value to its default setting. Synapse GXT100 | 3. Quick Start |...
Page 12 How to Change Parameters Using the Front Panel Control With the display as shown below: Pressing selects the SFS10 in frame slot 01. The display changes to indicate that the SFS10 has been selected. In this example the Settings menu item is indicated.
Page 13: Using Cortex With Synapse
For operation of Cortex, please refer to the Cortex help files. Further information about Front Panel Control and Cortex can be obtained from the ERC, ERS, RRC and RRS operational manuals and the Cortex help files. Synapse GXT100 | 3. Quick Start |...
Page 14: The Gxt100 Card
4. The GXT100 Card Introduction The GXT100 is a frame synchronizer and 16-channel embedder and de-embedder, combined with an ultra high-quality up/down/cross converter. The dual input capability can be used as an emergency bypass switch. The optimized scaling and filter algorithms ensure crisp broadcast-ready pictures from a native HD source, by use of 64-tap FIR filters.
Page 15 Full control and status monitoring through the front panel of the SFR04/SFR08/SFR18 frame and the Ethernet port (ACP) • 16-channel embedder in both HD and SD domains • Optional 2 fiber inputs (replacing 2 SDI inputs) or 2 fiber outputs (replacing 2 SDI outputs) on I/O panel. Synapse GXT100 | 4. The GXT100 Card |...
Page 16 Conversion Capabilities Applications • OB van output card with 16-channel embedding (in combination with 2 x DIO48) • 2 x 1 HD protection switch with SD monitoring output • Dual domain (HD & SD) production down converter with individual timing adjustment. 8 | November 2021 | Issue 1.00.B...
Page 17 The new DTV caption format cannot be translated back to EIA-608. However the EIA-708 may include EIA-608 data as "NTSC closed captions", for compatibility with old decoders. This card only de-embeds the NTSC closed captions, not the DTV closed captions. It will not function with a DTV-only 708 closed-caption source. Synapse GXT100 | 4. The GXT100 Card |...
Page 18: Settings Menu
5. Settings Menu 5.1. Introduction The Settings menu displays the current state of each GXT100 setting and allows you to change or adjust Settings can be changed using the front panel of the Synapse frame (SFR18, SFR08 or SFR04) or with Cortex.
Page 19 720p25 • 720p24 • SD525 • SD625 #Output_Map_B With this setting you can select the 3Gb/s mapping in case output B format is 1080p50 or 1080p60. Can be manually set to Level A or Level B. Synapse GXT100 | 5. Settings Menu |...
Page 20 #F_delayB F-Delay sets the amount of delayed Frames for outputs B1 and B2. The available range is from 0 to 250 fields (dependent on the I/O). Default is #V_delayB The V-Delay setting allows adjustment of the vertical phase of the output signal for outputs B1 and B2 with respect to the selected reference input. The V-Delay setting gives a delay in addition to the reference timing.
Page 21 V_only: vertical filters will be active which “soften” the image and prevents “ring”-effects in down converted content. • H_And_V: same horizontal filter as described under H_Only will be active, together with the vertical filters described under V_only. Synapse GXT100 | 5. Settings Menu |...
Page 22 • H2_Only: less steep filter with aliasing and soft for C for less ringing, more sharpness but with aliasing: • H2_And_V: same horizontal filter as described under H2_Only will be active, together with the vertical filters described under V_only. This setting is only for Channel A. Default is Off. This only works when down-converting.
Page 23 WSS (widescreen signaling) or WSS-extended (extended form of widescreen signaling). With this setting you can select which of the above protocols should be used to detect aspect ratio changes. By default it is set to VI. Synapse GXT100 | 5. Settings Menu |...
Page 24: Up-Conv
NoWSS/VI_prstA With this setting you can set to which preset the card should jump outputs A1 and A2, when no WSS or VI information is found. Can be any preset between 1 and 16 or Hold (holds current active preset). By default it is set to Hold.
Page 25 Channel A is up-converting. The best result is generated when the up-converter is active and the 601to709 setting is selected. It is also possible to switch the filter off. The default setting is Off. Synapse GXT100 | 5. Settings Menu |...
Page 26: Down-Conv
Up_CtrlB With this item you select how the presets for Channel B are controlled in up converter mode: Manually (manual), via GPI-triggers (GPI, GPI-A, GPI-B, GPI-C) or via changes of the SD Aspect Ratio (SD-AR). By default it is set to Manual. Up_Prst_ActB With this item you can manually change the currently active preset of channel B in up converter mode.
Page 27 The horizontal scaling of the TV picture of channel A in down converter mode is set using #Dn_H-scaleA. #Dn_H-scaleA can be set within the range of 50% to 200% of the input signal (only used when #Dn_ArcA is set to variable). Default value is 100%. Synapse GXT100 | 5. Settings Menu |...
Page 28 #Dn_V-ScaleA Sets the vertical scaling of the TV picture of channel A in down converter mode. Can be set within the range of 50% to 200% of the input signal (only used when #Dn_ArcA is set to variable). Default value is 100%. #Dn_H-EnhA With this item you can set the horizontal picture enhancement of channel A in down converter mode between 0 and 100%.
Page 29: Cross-Conv
Channel A in cross converter mode. Changing this will not change the active preset, unless the currently active preset is the same you are going to edit. All menu settings that are preceded with a ‘#Cr‘-prefix are part of the preset. Synapse GXT100 | 5. Settings Menu |...
Page 30 #Cr_ArcA With this item you set the Aspect Ratio of the output of channel A in cross converter mode. Can be Anamorphic, V-Zoom, CenterCut, LBox-16:9, LBox-14:9, PBox-4:3, PBox-14:9 or Variable (custom set AR, set by H-scale and V-scale settings). The following table shows the possible aspect ratios. Setting Result: Anamorphic...
Page 31: Transparent
With this item you can set the horizontal picture enhancement of channel B in cross converter mode between 0 and 100%. By default set to 0%. 5.6. Transparent In Transparent mode (no conversion), the card is not transparent for horizontal and vertical blanking, except for audio. Synapse GXT100 | 5. Settings Menu |...
Page 32 Setting Description Tr_CtrlA With this item you select how the presets for Channel A are controlled in Transparent mode: manually (Manual), via GPI-triggers (GPI-A, GPI-B or GPI-C) or via changes of the HD or SD aspect ratios (S2016 or SD_AR). By default it is set to Manual.
Page 33 50% to 200% of the input signal (only used when #Up_ ArcB is set to variable). Default value is 100%. #Tr_H-EnhB With this item you can set the horizontal picture enhancement of channel B in Transparent mode between 0 and 100%. By default set to 0%. Synapse GXT100 | 5. Settings Menu |...
Page 34: Inserter
5.7. Inserter This card can insert several data values in the VBI of the outputs. With the following settings you can choose what you want to insert. SMPTE ST 352 Video Payload Identifier The SMPTE ST 352 Video Payload Identifier, also known as VPID, is transported within the ancillary data of an SDI stream.
Page 35 With the #WSS-InsertA setting set to Extended, you can select WSS extended values from the #VI-DataA setting, which you want to be inserted. Possible VI settings are 4:3_0 through 4:3_7 and the settings 16:9_0 through 16:9_7. Default is 4:3_0. Synapse GXT100 | 5. Settings Menu |...
Page 36 #WSS-StndA With the #WSS-InsertA setting set to Standard, you can select WSS standard values with this setting, which you want to be inserted. possible are all WSS values from 1_vid through 8_vid and the settings from 1_flm through 8_flm. Default is 1_vid. #WSS-ExtndA With the #VI-InsertA setting set to Extended, you can select VI values with this setting, which you want to be inserted.
Page 37: Video-Proc
G-GainB controls the Green gain of channel B. The control range is between 50% and 150%. The default setting is 100%. B-GainB B-GainB controls the Blue gain of channel B The control range is between 50% and 150%. The default setting is 100%. Synapse GXT100 | 5. Settings Menu |...
Page 38: Audio Proc Amp
BlackA BlackA controls the total R-G-B Black gain. The range is between –128bit and 127bit. The default setting is 0bit. R-BlackA R-BlackA controls the Red-Black. The control range is between –128bits and 127 bits in steps of 1 bit. The default setting is 0 bit. G-BlackA G-BlackA controls the Green-Black.
Page 39: Embedder
Note: With this card the ADD-ON bus can only be used to either embed audio or de-embed audio. When one of the EmbXx_Inp settings is set to embed from the ADD-ON bus, no audio will be de-embedded towards the bus anymore, not for any of the channels. Synapse GXT100 | 5. Settings Menu |...
Page 40 #EmbC_Grp With this setting you select in to which audio group (= 4 audio channels) of the outputs you want to embed the third group of 4 forwarded audio channels coming from the de-embedders/add-on bus. Can be group1, group2, group3 or group4.
Page 41: Gpi Mode
Please refer to "Appendix 1: GPIs Explained" on page 45 for a more elaborate explanation of the GPI settings. GPI-DebounceTime This setting allows you to specify the permitted delay for valid signals on all GPIs (general purpose inputs). Values can be from 1ms through 40ms. default is 10ms. Synapse GXT100 | 5. Settings Menu |...
Page 42: Network
5.12. Network Setting Description IP_Conf0 With this setting you can either let the card obtain an IP address automatically via DHCP, or assign an IP address manually. By default this is set to DHCP. mGW0 With IP_Conf0 set to manual, this setting lets you set a Standard Gateway. Default is set to 0.0.0.0.
Page 43: Status Menu
4:3_0 • 16:9_0 • 4:3_1 • 16:9_1 • 4:3_2 • 16:9_2 • 4:3_3 • 16:9_3 • 4:3_4 • 16:9_4 • 4:3_5 • 16:9_5 • 4:3_6 • 16:9_6 • 4:3_7 • 16:9_7 • NA (no VI detected) Synapse GXT100 | 6. Status Menu |...
Page 44 sInp1_WSS-Stnd This status item displays the detected standard WSS value of input 1. This is displayed as follows: • 1_vid • 1_flm • 2_vid • 2_flm • 3_vid • 3_flm • 4_vid • 4_flm • 5_vid • 5_flm • 6_vid •...
Page 45 Displays whether or not OP47 is detected on input A. OP47-Det-B Displays whether or not OP47 is detected on input A. WST-Det-A Displays if teletext/closed captions have been detected on input A. WST-Det-B Indicates if teletext/closed captions have been detected on input B. Synapse GXT100 | 6. Status Menu |...
Page 46: Net Status
CC_Det_A Displays whether or not Closed Captioning has been detected on input A. CC_Det_B Displays whether or not Closed Captioning has been detected on input B. 6.3. Net Status Item Description IP_Addr0 This item displays the status of the IP address. It can be manual, DHCP asking (default), DHCP Leased or DHCP Infin.
Page 47: Events Menu
A priority that marks the importance of an event. This value is defined by the user and can have any value between 1 and 255, or 0 when disabled. • A slot number of the source of this event. Synapse GXT100 | 7. Events Menu |...
Page 48 Message String The message string is defined in the card and is therefore fixed. It may be used in controlling software like Synapse Set-up to show the event. Tags The tag is also defined in the card. The tag has a fixed meaning. When controlling or monitoring software has to make decisions based on events, it is easier to use the tag instead of interpreting a string.
Page 49: Led Indication
Data Error LED This LED indicates a CRC error. Connection LED This LED lights up after the card has initialized. The LED lights up for 0.5 seconds every time a connection is made to the card. Synapse GXT100 | 8. LED Indication |...
Page 50: Block Schematic
Block Schematic 42 | November 2021 | Issue 1.00.B...
Page 51: Connector Panels
3Gb/s, HD, SD Output A1 3Gb/s, HD, SD Output A2 GPI input (BPH17) Ethernet (BPH19) 3Gb/s, HD, SD-SDI Output B1 3Gb/s, HD, SD-SDI Output B2 Unused inputs and outputs must be terminated with the correct impedance. Synapse GXT100 | 10. Connector Panels |...
Page 52 GPI Pinning Pin Function GPI in 1 GPI in 2 GPI in 3 GPI in 4 GPI in 5 GPI out 1 GPI out 2 Ground 44 | November 2021 | Issue 1.00.B...
Page 53: Appendices
Pool B consists only of GPI 5 (also in priority mode), controlling the Output mode setting. Pool A now works as follows: GPI_1 Status GPI_2 Status GPI_3 Status GPI_4 Status Set Value Up-conv Preset 1 Up-conv Preset 2 Up-conv Preset 3 Up-conv Preset 4 Up-conv Preset 5 Synapse GXT100 | Appendices |...
Page 54 Up-conv Preset 4 (because highest takes priority) Up-conv Preset 5 (because highest takes priority) Pool B now works as follows: GPI_5 Status Set Value A out only B out only 46 | November 2021 | Issue 1.00.B...
Page 55 Up-conv Preset 2 Up-conv Preset 3 Up-conv Preset 4 Pool B now works as follows: GPI_4 Status GPI_5 Status Set Value Audio Preset 1 Audio Preset 2 Audio Preset 3 Audio Preset 3 (because highest takes priority) Synapse GXT100 | Appendix 1: GPIs Explained |...
Page 56 Example 3: Two Pools in Priority Mode Let’s say we would like to control the up-converter presets using Pool A (Up_CtrlA set to GPI-A) in priority mode, the audio presets using Pool B (Audio_Ctrl set to GPI-B) in priority mode, and Out mode control using Pool C (Out-mode-Ctrl set to GPI-C) also in priority mode.
Page 57: Appendix 2: Quad Speed Add-On Bus
Channel 1-32 (or less) are injected into the large, dark green arrow from the master card to the ADD- ON card and looped onto the next ADD-ON card via the dark green arrow. The ADD-ON card injects up to 32 channels into the large brown arrow. Synapse GXT100 | Appendix 2: Quad Speed ADD-ON Bus |...
Page 58 An ADD-ON card will also actively loop extra processed channels into the next ADD-ON card, and finally into the master card. • The cross looping of the original design is now a straight loop. • The quad speed bus can also work in one direction. You can use a Quad Speed audio bus to de-embed audio from the master and present on the ADD- ON card as AES/EBU, Bitstream (like Dolby) or analog audio.
Page 59 The next ADD-ON card (sitting in the next n+1 slot) can also freely select any 8 from 32 channels. (The DLA42 can also take 3 channels from the ADD-ON bus and 5 channels from its physical input). This looping works up to 3 times. Synapse GXT100 | Appendix 2: Quad Speed ADD-ON Bus |...
Page 60 The brown arrow is the return path and sends the (processed) audio back to the master card. This path is 32 channels wide and is clocked from the master card. The ADD-ON card can for instance overwrite 8 of the 32 channels. These 32 channels are then transported to the next ADD-ON card, which overwrites another 8 channels.
Page 61: Gnu Public License
Under this license, you are eligible to receive a copy of the source code of this software, including any changes. EVS Broadcast Equipment SA shall provide the source code on request either through physical distribution or electronic communication. For physical distribution you may be charged a fee that covers distribution costs.
