INSTALLATION INSTRUCTIONS:
• DISC SANDER SHIELDS
• UPPER BELT SANDER SHIELDS
• LOWER BELT SANDER SHIELDS
Disc Sander Shields
Upper and Lower Belt Sander Shields
5795 Logistics Parkway • Rockford, Illinois 61109 • Toll-Free 1-800-922-7533 • Phone 815-874-7891 Fax
815-874-6144 • Web Site www.rockfordsystems.com • E-Mail customerservice@rockfordsystems.com
Manual No. KSL-282
Advertisement
Table of Contents
Summary of Contents for Rockford Systems KYL-229
- Page 1 INSTALLATION INSTRUCTIONS: • DISC SANDER SHIELDS • UPPER BELT SANDER SHIELDS • LOWER BELT SANDER SHIELDS Disc Sander Shields Upper and Lower Belt Sander Shields 5795 Logistics Parkway • Rockford, Illinois 61109 • Toll-Free 1-800-922-7533 • Phone 815-874-7891 Fax 815-874-6144 • Web Site www.rockfordsystems.com • E-Mail customerservice@rockfordsystems.com Manual No.
- Page 2 • U se the T-handle knobs to adjust the shield up Mounting or down. Hole 4. Permanently attach danger signs No. KSC-046 and No. KSC-048 (if furnished). Make sure they are read- ily visible to all personnel who work on or around the machine. Rockford Systems, LLC—www.rockfordsystems.com Call: 1-800-922-7533...
- Page 3 3. Remove the end cap from bottom of shield arm. T-Nut Mounting Arm Shield Arm 4. Loosen the two buttton-head cap screws (through access holes on shield arm) and slide mounting arm from shield arm. Set aside. Mounting Arm (Continued on next page.) Rockford Systems, LLC—www.rockfordsystems.com Call: 1-800-922-7533...
- Page 4 9. Use the T-handle knob to adjust the shield up or down. 10. Permanently attach danger signs No. KSC-046 and No. KSC-048 (if furnished). Make sure they are readily visible to all personnel who work on or around the machine. Rockford Systems, LLC—www.rockfordsystems.com Call: 1-800-922-7533...
- Page 5 4. Attach end cap to open end of mounting arm using the furnished nylon push-in fasteners. 5. Permanently attach danger signs No. KSC-046 and No. KSC-048 (if furnished). Make sure they are read- ily visible to all personnel who work on or around the machine. Rockford Systems, LLC—www.rockfordsystems.com Call: 1-800-922-7533...
- Page 6 Rockford Systems, LLC. This warranty will not apply to any product which will have been subject to misuse, negligence, accident, restriction and use not in accordance with Rockford Systems, LLC’s instructions or which will have been altered or repaired by persons other than the authorized agent or employees of Rockford Systems, LLC.
