1880 RANGE SD/SC BACKLIT EXIT SIGN
Installation Leaflet
Mounting Instructions
1. Remove cover (frame)/legend as instructions detailed below.
2. Pierce body as required for fixing.
3. Follow the wiring instructions as detailed later.
4. Follow initial testing procedure as detailed later.
Cover/Legend Removal
Earthing Class I IP54
Use Key Provided
Secure Legend
panel with hand
Locate Tool under
edge of frame
Gently pull back on
tool to remove frame,
leaving legend free.
Lift legend to access
gear tray
