Summary of Contents for POSSWAY V4 PRO

Page 1 USER MANUAL WWW.POSSWAY.COM...
Page 2: Read Before Riding
Your board is not completely waterproof, you can easily go through the puddles but don’t soak the board in the water. Water damage is not covered under the warranty. WARNING: RISK OF ELECTRONIC SHOCK! Do not open or tamper with electronics housing without Possway’s guidance, which also voids the warranty.
Page 3 THANK YOU FOR BUYING OUR ELECTRIC SKATEBOARD PROTECT · Always wear a helmet. · Find an open, flat area with clean pavement for your first ride. · Read the warning on the skateboard and at the beginning of this manual. ·...
Page 4: Parts Diagram
PARTS DIAGRAM Mileage 13km / 8mph* N.W. 6.4kg / 14lb Entire Low speed 0-7km/h / 0-4mph Size 900*230*125mm board Capability Medium speed 0-15km/h / 9mph Max load 100kg / 220lb Max speed 0-38km/h / 23mph * Type 83mm Hub Motor Motor 0-38km/h / 23mph* Max speed...
Page 5 PARTS DIAGRAM Deck Power Button Battery Case Drive Truck Kit Charge Port Front Truck...
Page 6 QUICK START GUIDE Accelerate Brake ODO : 00163 KM KM/H Max: KM/H B-MI+ Power On Switch Ride Mode If you're a beginner, please roll the throttle wheel forward gently to start with a slow speed to avoid falling.
Page 7: Power On/Off
POWER ON / OFF POWER ON/OFF THE BOARD Press the power button for 1 second. Auto Power ON Push the skateboard forward and after a beep, the skateboard will turn on automatically. Auto Power OFF When the skateboard is stationary for 10 minutes, 10 Mins the power will be turned off automatically.
Page 8: Remote Control
REMOTE CONTROL Throttle Wheel Remote Control Battery Board Battery Display ODO : 00163 KM KM/H Cumulate Mileage ODO : 00163 KM Max: KM/H B-MI+ Single Mileage Speed KM/H Function Key Top Speed Max: 31 KM/H B-MI+ Power Button Hold to Turn on/off Speed Mode Brake Mode Click to confirm options...
Page 9: Double-Click
MARCHING DIRECTION ODO : 00163 KM KM/H Max: KM/H B-MI+ FW: Forward Double-click to switch marching direction. ODO : 00163 KM KM/H Max: KM/H B-MI+ Do not switch directions while riding to avoid falling. ODO : 00163 KM KM/H Max: KM/H B-MI+ BW: Backward...
Page 10: Ride Mode
RIDE MODE SWITCH RIDE MODE Click the button to switch Ride Mode options. ODO : 00163 KM ODO : 00163 KM KM/H KM/H Max: KM/H Max: KM/H ODO : 00163 KM B-MI+ B-MI+ KM/H Max: KM/H LO: 0-7km/h (4 mph) MI: 0-15km/h (9mph) B-MI+ ODO : 00163 KM ODO : 00163 KM...
Page 11 ADJUST THE BRAKE STRENGTH B-LO ODO : 00163 KM B-MI KM/H B-HI Max: KM/H B-PRO ODO : 00163 KM B-MI KM/H Max: KM/H B-MI+ Pull the throttle wheel back on the remote control and do not release it. At the same time, short press the to switch the three gears of the braking strength.
Page 12 ADJUST SPEED UNIT ① Turn off the remote. THUMBNHEEI:OK UMIT:KM/H WHEEI SPEED:48 FREQUECY:2402 ② Press the button THUMBNHEEI:OK button to enter UMIT:KM/H WHEEI SPEED:48 FREQUECY:2402 setting mode. ODO : 00163 KM ③ Roll the throttle wheel and adjust the speed unit. Max: B-MI+ ④...
Page 13 SET CRUISE CONTROL ODO : 00163 KM KM/H Max: KM/H B-MI ODO : 00163 KM KM/H Max: KM/H ① Accelerate to the speed you want. B-MI+ ② Short press the Power button to display CRU, and enter Cruise Control. ③ Push to accelerate, brake, or press the Power button again to exit Cruise Control.
Page 14 PAIR INSTRUCTION The board and the remote are already paired for sale, if you want to change the drive motors or other settings, follow the steps below to do the re-connecting. Signal Signal light ① Press the power button of the board to turn it on. The remote control and skateboard signal light ②...
Page 15 CHARGE THE BOARD hrs/2A WARNING: Never leave board unattended while charging. Please don't charge After fully charged, the skateboard the board with a charger with output indicator light changes from amperage over 2A. flashing to solid red.
Page 16: Safety Instructions
SAFETY INSTRUCTIONS The electric skateboard is not a toy, should be treated with appropriate caution. Ensure that you use the board in a safe appropriate environment, and always wear appropriate safety gear. Safety Gear: we recommend that you wear full safety gear while riding. Please wear a suitable skateboard helmet, elbow pads, knee pads, and gloves.
Page 17: Precautions For Use
PRECAUTIONS FOR USE RIDING OUTSIDE OF YOUR PRIVATE PROPERTY Abide by the laws and regulations in your state or country. Respect other drivers and pedestrians on the road. Avoid riding in busy traffics and crowded areas. Do not park your board in a way that blocks people or traffic,or may create a safety issue. Cross road at designated crosswalks or signaled intersections.
Page 18: Battery Safety
BATTERY SAFETY Lithium-ion battery can explode or cause a fire if they are used incorrectly.Therefore,it is recommended to read the following instructions very carefully: ● Each time before riding the board,carefully check the battery pack and especially the protective seal.Make it is undamaged and intact.lf in doubt,take the battery to a chemical waste disposal facility.
Page 19: Warranty
WARRANTY LIMITED WARRANTY We offer 6 months (180 days) warranty on parts from the date when you receive the board. ● If a defect arises during the Warranty Period, Company will , at is options : ● 1 ）Send the new parts to replace the defect parts. 2）Exchange the affected Products with functionally equivalent Products that are new or formed from new and/or previously used parts that are equivalent to new in performance and reliability.
Page 20 After-sales service: service@possway.com If the parameters are updated without notice, please refer to the official website.2022.03.31...
