'72 Stock Refurbishment
Multi-stage Thermostat for Cab
Contents
Introduction ...........................................................................................2
Block diagram .......................................................................................2
Description ............................................................................................2
Temperature measurement ....................................................................3
Output switching ...................................................................................3
Operator interface..................................................................................4
System layout diagram ..........................................................................4
Power supply .........................................................................................5
Installation .............................................................................................5
System connection diagram...................................................................5
System wiring list..................................................................................5
Technical Specification .........................................................................6
Ordering information.............................................................................8
Supplier information..............................................................................8
Copyright (C) 1997 Tactical Controls Limited
This document contains proprietary information which is protected by copyright. All rights reserved. This document or parts thereof may not
be reproduced in any form without written permission of the publishers.
The information in this document is subject to change without notice and should not be construed as a commitment by Tactical Controls
Limited. Tactical Controls Limited shall not be liable for errors contained herein or for incidental or consequential damages in connection
with the furnishing, performance or use of this material.
LUL, Bakerloo Line
Heating, Ventilating
& Air-conditioning
Advertisement
Table of Contents
Summary of Contents for Tactical EBMST
- Page 1 The information in this document is subject to change without notice and should not be construed as a commitment by Tactical Controls Limited. Tactical Controls Limited shall not be liable for errors contained herein or for incidental or consequential damages in connection...
- Page 2 Tactical Controls Limited Multi-Stage Thermostat Instruction Manual Introduction This instruction manual describes a microprocessor-based Multi-Stage Thermostat (MST) with application to the LUL, Bakerloo Line '72 Stock Refurbishment Heating, ventilating & Air-conditioning for Cab. The MST is designed to measure the cab temperature and switch the heating or air- conditioning according to the selected setpoint.
- Page 3 Tactical Controls Limited Multi-Stage Thermostat Instruction Manual The supply to the microprocessor is derived from the -52Vdc supply via a step-down switch mode power supply. It is surge and transient protected. The supply voltage is monitored for low supply voltage cutout. The 4 output stages are switched off if the supply voltage is above -32Vdc and resumes when the supply voltage is below -36Vdc.
- Page 4 Tactical Controls Limited Multi-Stage Thermostat Instruction Manual SETPOINT LOGIC 23°C OUTPUT STAGE 1 STAGE 2 STAGE 3 STAGE 4 TEMP. rising falling rising falling rising falling rising falling HIGH HEAT 20-off 19-on LOW HEAT 21-off 20-on LOW COOL 23-on 22-off...
- Page 5 WITH SOCKET CONTACTS STAGE3 PART NO. CIR03R16S-1P-F80-T12 Tactical Controls Limited Title: STAGE4 EBMST - EXTERNAL CONNECTION DIAGRAM Drawing No.: Size: EBMST\IM\CONNECT 28-OCT-1997 CONNECTOR 3 TO PIN CONTACT ALL DIMENSIONS ARE IN MM. GENERAL TOLERANCE X = +/-0.5 X.X = +/-0.05 Filename: Rev.
- Page 6 Tactical Controls Limited Multi-Stage Thermostat Instruction Manual Technical Specification Supply Voltage -32 to -63 Vdc; -52 Vdc nominal. Ripple Unaffected by 5 volt peak to peak. Input protection Reverse polarity protection. Surges and transients to BRB/RIA 12 and RIA18 section 5, burst transient.
- Page 7 Tactical Controls Limited Multi-Stage Thermostat Instruction Manual Diagnostic and test Key switch One change over contact, when key in non-removable position, input is connected to the sensor simulation potentiometer. When the key- switch is in removable position, the input is switched to the NTC sensor input.
- Page 8 Multi-Stage Thermostat Instruction Manual Ordering information Ordering code: EBMST You are welcome to order the unit by code or by description - EBMST Multi-Stage Thermostat for LUL, Bakerloo Line '72 Stock Refurbishment Heating, Ventilating & Air- conditioning for Cab. Supplier information...
