Tactical TTC Instruction Manual

Time and temperature controller

Advertisement

Quick Links

Time and Temperature Controller
Contents
Introduction ........................................................................................ 2
Block diagram ..................................................................................... 2
Description.......................................................................................... 3
Power supply....................................................................................... 4
Sensor input ........................................................................................ 4
Control outputs ................................................................................... 4
User interface ...................................................................................... 4
Installation .......................................................................................... 5
Layout diagram ................................................................................... 5
Fascia label.......................................................................................... 6
Dimensional drawing ........................................................................... 6
Technical Specification ........................................................................ 7
Ordering information ........................................................................... 8
Supplier information ............................................................................ 8
Copyright (C) 1999 Tactical Controls Limited
This document contains proprietary information which is protected by copyright. All rights reserved. This document or parts thereof may not be
reproduced in any form without written permission of the publishers.
The information in this document is subject to change without notice and should not be construed as a commitment by Tactical Controls Limited.
Tactical Controls Limited shall not be liable for errors contained herein or for incidental or consequential damages in connection with the
furnishing, performance or use of this material.
(TTC)
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TTC and is the answer not in the manual?

Questions and answers

Summary of Contents for Tactical TTC

  • Page 1 The information in this document is subject to change without notice and should not be construed as a commitment by Tactical Controls Limited. Tactical Controls Limited shall not be liable for errors contained herein or for incidental or consequential damages in connection with the...
  • Page 2 CONTROL OUTPUT OUTPUT MAINS POWER SUPPLY SUPPLY PUSH BUTTONS INPUT Tactical Controls Limited Title: TTC - BLOCK DIAGRAM Drawing No.: Size: TTC\IM\BLOCK FIRST ISSUE 29-MAR-1999 Filename: ALL DIMENSIONS ARE IN MM. GENERAL TOLERANCE X = +/-0.5 X.X = +/-0.05 Rev.
  • Page 3 Tactical Controls Limited Time and Temperature Controller Instruction Manual Description The operator panel consists of a single Printed Circuit Board (PCB) which houses the power supply, sensor input conditioning circuitry, microcontroller, 7-segment Light Emitting Diode (LED) display for temperature and timer indication, status indicating LEDs, control and setting push buttons, and output circuitry for temperature and timer.
  • Page 4 Tactical Controls Limited Time and Temperature Controller Instruction Manual Power supply The control panel requires 240Vac 6VA max. 50Hz supply. Sensor input A Platinum Resistance Thermometer (PRT100) is supplied as the temperature sensor. Control outputs Relay outputs are used for both temperature and timer output. The rating for both relays is 240Vac 5A max.
  • Page 5 Tactical Controls Limited Time and Temperature Controller Instruction Manual Installation The operator panel is mounted on the inside of the steel fascia plate using 6 M3 nuts and washers, M4x7 clear hole spacers on the 6 M3 studs. The fascia label is put on the front of the fascia plate using double sided adhesive.
  • Page 6 Tactical Controls Limited Time and Temperature Controller Instruction Manual Fascia label Dimensional drawing 220.0 105.0 105.0 95.0 240.0 95.0 90.0 90.0 28.0 13.0 2 CUTOUT FOR DISPLAY 21.0 4 X Ø6.0 50.0 70.0 80.0 50.060.0 15.0 6 HOLES FOR KEYS 6 X M3X20 6 X Ø3.5...
  • Page 7 Tactical Controls Limited Time and Temperature Controller Instruction Manual Technical specification Sensor input PRT100 Level detection Volt-free input for level detection Setpoint 0 to 99ºC; default to 50°C Temperature Control ON/OFF with 1ºC hysteresis Temperature Output Relay 10A max. (5A continuous) 240Vac Timer Control 0 to 99 minutes;...
  • Page 8 Tactical Controls Limited Time and Temperature Controller Instruction Manual Ordering information Ordering code: TTC You are welcome to order the unit by code or description - TTC Time and Temperature controller. Supplier information Tactical Controls Limited Unit 1 Parkland Business Centre...
