Summary of Contents for FUHR SmartTouch NB506NR
- Page 1 881STIG01 NB506NR SmartTouch comfort access system featuring long-range transponder technology Installation manual These instructions are to be passed on by the fitter to the user...
- Page 2 General information/important notes SmartTouch is a cutting-edge access control system featuring long-range transponder technology. It makes it extremely easy to open doors fitted with FUHR’s multitronic 881 and autotronic 834 motorised locking systems. SmartTouch function The system’s SmartTouch function allows you to open a door fitted with a motorised lock with outstanding ease.
- Page 3 User transponders do not have the right to pair or unpair other transponders, and cannot be used to change the detection range. User transponders can be identified by the grey band around their perimeter. grey band www.fuhr.de...
- Page 4 Fitting the SmartTouch components General layout drawing Recess on outside of Sensor door leaf Plug connector Smart radio module Lock recesses cut with milling cutter Illuminated (LED) pushbutton Motorised drive mechanism Motor plug www.fuhr.de...
- Page 5 Terminal 4 white cable Terminal 5 brown cable Terminal 6 green cable Cable C: The long 2-core connecting cable ends in a plug. Insert this plug into the socket on the back of the motorised drive mechanism. www.fuhr.de...
- Page 6 Insert this plug into the socket on the back of the Smart radio module. You can now insert the motorised lock in the profile of the door leaf. Please ensure that there are no kinks in the cables and that they are not squeezed or pulled. www.fuhr.de...
- Page 7 Smart radio module has been set tween the radio module and the sensor – see too low; alternatively it may be that the section 4. SmartTouch function has been entirely disabled. www.fuhr.de...
- Page 8 Technical specifications 6.1 Smart radio module Frequency: 868.92 MHz Modulation: Security: Rolling-code / AES 128-bit/master key principle Anti-collision check: Antenna: On-board Power supply: 12 V DC Current consumption: 15 mA Activity indicator: Green light-emitting diode Temperature range: -10°C to +50°C Dimensions: 43 x 40 x 15 mm Connecting cable:...
