- Page 1 ALS Brake Wired Install Guide ALS Brake Wired Install Guide (9.03.2022) V1.1 – Changed connector to DTM06-4S V1.2 - CAN Protocol Update (from firmware 0.130 onwards) www.alsense.eu © Alsense Motorsport SRL...
-
Page 2: Table Of Contents
ALS Brake Wired Install Guide Table of Contents ALS Brake Wired www.alsense.eu Introduction Specifications Physical Installation Electrical Installation Configuration CAN Temperature Data Decoding Troubleshooting / FAQ Support Default CAN Specifications System Configuration System Information Data Reporting © Alsense Motorsport SRL... -
Page 3: Introduction
ALS Brake Wired Install Guide 1. Introduction Thank you for purchasing the ALS Brake Wired. The following guide is aimed at providing an overview of the typical install process for both a single sensor as well as for a complete set. -
Page 4: Physical Installation
ALS Brake Wired Install Guide 3. Physical Installation Before installing the sensor in its final position, please ensure that: All the necessary configuration parameters have been set (number of channels and order, emissivity, startup delay time). We can perform these for you if you get in touch with us before shipping or using the ‘Notes’... - Page 5 ALS Brake Wired Install Guide We do mounting the sensor such that it avoids direct exposure to significant heat sources (i.e. exhausts). The IR sensor has a horizontal FOV of 110°. As the sensor is placed further away, the maximum width of the brake diameter increases.
- Page 6 ALS Brake Wired Install Guide Maximum Disc Width (mm) Mounting Distance (mm) Figure 1 - Channel assignment / sensor data order © Alsense Motorsport SRL...
- Page 7 ALS Brake Wired Install Guide Figure 2 - Visual Representation of channel assignments © Alsense Motorsport SRL...
-
Page 8: Electrical Installation
ALS Brake Wired Install Guide 4. Electrical Installation Depending on the option you have ordered, the sensor will come with either an unterminated end or a DTM06-4S connector. The mating connector is DTM04-4P Unterminated 12V – Orange / White ●... -
Page 9: Configuration
ALS Brake Wired Install Guide Always use twisted paired cable for CAN Low and CAN High wiring as it greatly improves the signal’s tolerance to electrical noise. Also try and keep wiring stubs (cables going from the main CAN bus lines to individual devices) at a minimum. Our sensors come with a 0.5m cable, it’s generally ok to have another 0.5m in addition to that. -
Page 10: Can Temperature Data Decoding
ALS Brake Wired Install Guide can be sent. Please consult Appendix A: ALS Brake Wired CAN Protocol for complete information on the CAN protocol. Typical Configuration Procedure: Ensure the sensor is powered and with correct CAN connectivity to the device you’re using to transmit CAN messages from. -
Page 11: Troubleshooting / Faq
ALS Brake Wired Install Guide 7. Troubleshooting / FAQ Situation 1: Not getting any data in my CAN dash/logger Use a multimeter to check that the sensor is getting 12V on its power supply pins. b. Double check wiring and make sure your CAN stubs’ length is not more than 150cm. -
Page 12: Support
ALS Brake Wired Install Guide 8. Support Please make sure to check the downloads section of our support page as it provides the product’s datasheet and configuration files for the most common CAN dashboards/loggers. Extra help can be obtained using our built-in ticket support system or directly via phone. -
Page 13: Default Can Specifications
ALS Brake Wired Install Guide Appendix A: ALS Brake Wired CAN Protocol V1.0 Updated 12.01.2020 A. Default CAN Specifications 1. Base Id ● FL - 0x400 ● FR - 0x420 ● RL - 0x440 ● RR - 0x460 Baud Rate: 500kbps B. -
Page 14: System Information
ALS Brake Wired Install Guide Direction: From Device CAN Id: <Old Base Id> + 0x01 Byte Name Formula Description New Base Id MSB New Base ID for CAN messages. Requires a power cycle. I.e. 0x310 would be: New Base Id LSB... -
Page 15: Data Reporting
ALS Brake Wired Install Guide FW Minor Emissivity = Value / I.e. setting to 75 is 0.75 Sample Rate = Value 1 - 64 Hz (Values outside this range get truncated to the closest valid one) Initial Configuration Duration = Value Number of seconds to allow at startup for configuration. - Page 16 ALS Brake Wired Install Guide Chan 3 Chan 3 Name: DATA_TEMPS_2 Direction: From Device CAN Id: <Base Id> + 0x11 Time Interval: Depending on <Sample Rate> Byte Name Formula Description Chan 4 = (Value + 200) The temperature reading is offset by 200* C and then multiplied by 10.
- Page 17 ALS Brake Wired Install Guide Chan 10 Chan 10 Chan 11 Chan 11 Name: DATA_TEMPS_4 Direction: From Device CAN Id: <Base Id> + 0x13 Time Interval: Depending on <Sample Rate> Byte Name Formula Description Chan 12 = (Value + 200) The temperature reading is offset by 200* C and then multiplied by 10.
- Page 18 ALS Brake Wired Install Guide FW Minor Emissivity = Value / 100 I.e. setting to 75 is 0.75 Sample Rate = Value 1 - 64 Hz (Values outside this range get truncated to the closest valid one) Reserved = Value...
