Features:
• Football goal transport system
• Air or PU tire with ball bearings
• Lift the goal 65mm
• 2 Left / 2 right systems needed
Easy lift football goal • Easy lift voetbaldoel
Easy lift but • Easy lift fußballtor
Where quality comes first...
EL118_LEFT
www.alusport.be
info@alusport.be
Advertisement
Related Manuals for AluSport EL118 LEFT
Summary of Contents for AluSport EL118 LEFT
- Page 1 Easy lift but • Easy lift fußballtor 1 / 6 Features: • Football goal transport system • Air or PU tire with ball bearings • Lift the goal 65mm • 2 Left / 2 right systems needed EL118_LEFT www.alusport.be info@alusport.be...
- Page 2 • Assemble the bolt 'M10x35' to the 'L-Profile' with all the parts needed • Assemble the wheel / lever assembly to the L-assembly with the circlips • Place the lift system on the goal Weight Gewicht = 3 Kg Poids EL118_LEFT www.alusport.be info@alusport.be...
- Page 3 Spacer • Afstandbus • Entretoises • Distanzmuffe 25x2.5 - 21.5 Spacer • Afstandbus • Entretoises • Distanzmuffe Spring washer • Veerring • Rondelle ressort • Spannscheibe Washer • Rondel • Rondelle • Unterlegscheibe Wheel • Wiel • Roue • Rad EL118_LEFT www.alusport.be info@alusport.be...
- Page 4 Equipment you Easy lift football goal • Easy lift voetbaldoel can count on... Easy lift but • Easy lift fußballtor 4 / 6 Small diameter on this side EL118_LEFT www.alusport.be info@alusport.be...
- Page 5 Equipment you Easy lift football goal • Easy lift voetbaldoel can count on... Easy lift but • Easy lift fußballtor 5 / 6 EL118_LEFT www.alusport.be info@alusport.be...
- Page 6 Where quality comes first... Easy lift football goal • Easy lift voetbaldoel Easy lift but • Easy lift fußballtor 6 / 6 EL118_LEFT www.alusport.be info@alusport.be...
