INSTRUCTION MANUAL

TEMPERATURE SWITCHES

TSZ3H-24

These temperature switches with display are designed for using as two-state

controller (on/off type control) for compare the temperature set-point with the

actual temperature value in range -50 to 250°C, with the possibility of

switching

the electrically isolated contacts of a connected relay

SENSIT s.r.o.

Školní 2610, 756 61 Rožnov pod Radhoštěm, ID No. 64087484, VAT No. CZ64087484, Phone: +420 571 625 571, Fax: +420 571 625 572

Company is incorporated in the Companies Register at the Regional Court in Ostrava, Section C, File 13728, sensit@sensit.cz, www.sensit.cz

5407.1

01.17

Supersede

Table of Contents

Need help?

Do you have a question about the TSZ3H-24 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sensit TSZ3H-24

Page 1 Školní 2610, 756 61 Rožnov pod Radhoštěm, ID No. 64087484, VAT No. CZ64087484, Phone: +420 571 625 571, Fax: +420 571 625 572 Company is incorporated in the Companies Register at the Regional Court in Ostrava, Section C, File 13728, sensit@sensit.cz, www.sensit.cz 5407.1...
Page 2 Continuity of the standards and working measuring instruments is ensured within the meaning of the Section 5 of Act no.505/1990 on metrology. The manufacturer offers a possibility to supply the sensors calibrated in SENSIT s.r.o. laboratory (according to EN ISO/IEC 17025 standard) or in an Accredited laboratory. Application: These temperature switches with display are designed for using as two-state controllers (on/off type control).
Page 3 Declaration of conformity: SENSIT s.r.o. provides the product with the EU Declaration of Conformity issued according to Act No. 90/2016 Coll. and Act No. 22/1997 Coll., as subsequently amended. The product is in accordance with the following directives:  European Parliament and Council Directive 2011/65/EU of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment ...
Page 4 Control buttons and indicating LED: LED L1, green: relay1 in operating mode: short-circuited - is alight / break - is not alight LED L2, red: relay2 in operating mode: short-circuited - is alight / break - is not alight relay2 in emergency mode: short-circuited - blinks slowly break - is not alight mode for displaying or value setting - blinks quickly...
Page 5 function 03 - temperature is read out by means of two sensing elements; relay1 and relay2 are controlled by individual temperatures independently from each other function („Fnc“) → sensing element1 („rt1“) → temperature t („tL1“) → temperature t („tH1“) → sensing element2 („rt2“) →...
Page 6  Instruction Manual, including Guarantee Certificate  Delivery Note Likvidace: SENSIT s.r.o. has signed an agreement with the Company RETELA s.r.o., on the collective performance by §37h - paragraph1, letter c) of the Act No.185 / 2001 Sb. on waste, as amended. Complaints and repairs: Guarantee and after-guarantee repairs of sensors are ensured by the manufacturer.
Page 7  That is claimed without the Warranty Certificate or nameplate. Rights and obligations regarding the rights arising from defective performance will be governed by the applicable legislations and the applicable Business Terms and Conditions of SENSIT s.r.o. and this Warranty Certificate. Date of sale confirmation:...
