Summary of Contents for Entec HDBT100PL
- Page 1 User Manual HDBT100PL HDMI/IR/RS232 Twisted Pair PoC Extender All Rights Reserved Version: HDBT100PL_2014V1.0...
- Page 2 HDMI/IR/RS232 Twisted Pair PoC Extender SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
- Page 3 HDMI/IR/RS232 Twisted Pair PoC Extender NOTICE: Please read this user manual carefully before using this product. Pictures shown in this manual are for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till March 2014.
-
Page 4: Table Of Contents
HDMI/IR/RS232 Twisted Pair PoC Extender Table of Contents 1. Introduction ......................... 1 1.1 Introduction to HDMI/IR/RS232 Twisted Pair PoC Extender ......1 1.2 Features ......................1 1.3 Package Contents ..................... 1 2. Introduction of Product Appearance ................2 2.1 Product Appearance of HDMI Pro Transmitter ........... 2 2.2 Product Appearance of HDMI Pro Receiver ............ -
Page 5: Introduction
HDMI/IR/RS232 Twisted Pair PoC Extender 1. Introduction 1.1 Introduction to HDMI/IR/RS232 Twisted Pair PoC Extender HDMI/IR/RS232 Twisted Pair PoC Extender is an HDMI/IR/RS232 twisted pair extender including one transmitter (HDMI Pro Transmitter) and one receiver (HDMI Pro Receiver). It is a professional 1x1 extender, with a single CAT5e cable, the input HDMI signal can be long-distance transmitted, and the control signal (IR &... -
Page 6: Introduction Of Product Appearance
HDMI/IR/RS232 Twisted Pair PoC Extender 2. Introduction of Product Appearance 2.1 Product Appearance of HDMI Pro Transmitter Figure 1 Interfaces of HDMI Pro Transmitter Name Description On: Used to show the output status. It will blink when the HDMI output port connect with terminal display device, the LED turn off when there is no connect. -
Page 7: Product Appearance Of Hdmi Pro Receiver
HDMI/IR/RS232 Twisted Pair PoC Extender Transmitter or HDMI Pro Receiver connecting with power adapter is enough.) 2.2 Product Appearance of HDMI Pro Receiver Figure 2 Interfaces of HDMI Pro Receiver Name Description On: Used to show the working status, blinks when in normal working state, turns off when stop working. -
Page 8: Twisted Pair Cable Connection
HDMI/IR/RS232 Twisted Pair PoC Extender 2.3 Twisted Pair Cable Connection The twisted pair used in HDMI Pro Extender MUST be a straight-through cable. The connectors can be T568A or T568B, but both sides must be the same. TIA/EIA T568B TIA/EIA T568A Cable color Cable color green white... -
Page 9: System Connection
HDMI/IR/RS232 Twisted Pair PoC Extender 3. System Connection 3.1 Usage Precautions Please cut off the power of the HDMI source device and the output displaying device before accessing with HDMI Pro Extender, as it may damage to HDMI Pro Extender. Ensure that all connections (including the power cord) are done before turning on the power to work with HDMI Pro Extender. -
Page 10: System Diagram
HDMI/IR/RS232 Twisted Pair POC Extender 3.2 System Diagram Figure 3 System Diagram 3.3 Connection Procedure Step1. Connect HDMI source (such as DVD player) to HDMI IN port of the transmitter HDMI Pro Transmitter with HDMI cable. Step2. Connect HDBT OUT port of HDMI Pro Transmitter and HDBaseT port of HDMI Pro Receiver, with single CAT5e cable. -
Page 11: System Applications
HDMI/IR/RS232 Twisted Pair PoC Extender 3.4 System Applications As its good performance in control and transmission, HDMI Pro Extender can be widely used in computer realm, monitoring, large screen displaying, conference system, education and bank securities institutions etc. 4. Specification Model HDMI Pro Transmitter HDMI Pro Receiver... - Page 12 HDMI/IR/RS232 Twisted Pair PoC Extender HDMI Standard Support HDMI1.4a and HDCP Impedance 75Ω Temperature -10 ~ +40℃ 10% ~ 90% Humidity Input: 100VAC ~ 240VAC, 50/60Hz Power Supply Output: DC 24V, 1.25A Power Consumption Case 152x 28x 84 mm 152x 28x 84 mm Dimension(W*H*D) Net Weight 0.8Kg...
-
Page 13: Panel Drawing
HDMI/IR/RS232 Twisted Pair PoC Extender 5. Panel Drawing Figure 4 Panel Drawing of HDMI Pro Transmitter Figure 5 Panel Drawing of HDMI Pro Receiver... -
Page 14: Troubleshooting & Maintenance
HDMI/IR/RS232 Twisted Pair PoC Extender 6. Troubleshooting & Maintenance Problems Causes Solutions Incorrect setting on the Check the display’s setting display Output images in display show with ghost Try another high quality A cable of bad quality connection cable Check with oscilloscope or No signal at the input / multimeter if there is any output end... -
Page 15: After-Sales Service
HDMI/IR/RS232 Twisted Pair PoC Extender 7. After-sales Service If there appear some problems when running the device, please check and deal with the problems reference to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: It is warranted that the product will be free from defects in materials and workmanship for three years, which starts from the first day you buy this product (The purchase invoice shall prevail).
