- Page 1 INSTALLATION, OPERATION & MAINTENANCE MANUAL ACMO-AVK DIAPHRAGM AUTOMATIC CONTROL VALVE SERIES 879 - M117 VALVE TIMER HKEY Ver. 1.6 Rev. 02 - 20210309 COPYRIGHT©AVKGROUP - ACMO - www.acmosrl.com ACMO-AVK_IOM_valve-timer_M117_EN_2021...
- Page 3 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 INDEX 1.0 Intro 2.0 KEY: Turning on/off 3.0 Main menus 3.1 Device information menu 3.2 Program menu 3.3 BASE connection menu 4.0 Launch menu 4.1 Option 1) “BASE”...
- Page 4 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 1.0 INTRO The timer activates and deactivates a hydraulic valve at preset times. It is made up of two parts, a “programming card” (hereinafter the KEY) and a “control unit” (hereinafter the BASE), which activates the hydraulic valve through a solenoid.
- Page 5 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 2.0 KEY: TURNING ON/OFF Press the OK / turn on button for 3 sec. to turn on the KEY. Press the OK / turn on button for 3 sec. to turn off the KEY.
-
Page 6: Main Menus
ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 3.0 MAIN MENUS Use the arrow button to scroll the menus; press the OK button to enter a menu. Press the ESC button to exit a menu and return to its title. - Page 7 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 Press again the arrow button to display the card auto power off time: Information Auto power off time 3 minutes OK=MODIFY ESC=EXIT Press the OK button to modify the time:...
-
Page 8: Program Menu
ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 3.2 PROGRAM MENU Enter the menu to display and modify the valve automatic program. Menu PROGRAM OK=ENTER Press the OK button to select the program and display the automatic parameters to activate/deactivate the valve. - Page 9 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 A turn can last from a minimum of 1 minute to a maximum of 23 hours and 59 minutes. After the last turn, press the down arrow button to move to the next menu:...
- Page 10 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 3.3 BASE CONNECTION MENU Enter the menu to connect to the BASE and operate on it. Note: Start the BASE before operating on it, see chapter “BASE turning on/off”.
- Page 11 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 4.0 BASE: LAUNCH MENU Possible BASE status: 1) “BASE” manual mode (the program is not running) 2) “BASE” automatic mode (the program is running) 3) “BASE”...
- Page 12 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 … and it will be visible during the whole activation (about 30 sec. generally). Finally, once the valve has been activated, the following message will be displayed:...
- Page 13 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 4.2.2 “BASE” AUTOMATIC MODE (ACTIVATED) The KEY displays the following message after the automatic mode activates the solenoid: 00051 Activated in AUTOMATIC MODE...
- Page 14 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 Press the ESC button to go back to the “BASE connection menu” without selecting any option. Press the OK button to turn off the BASE and display the following message:...
- Page 15 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 5.2 BASE SET UP MENU Once entered the BASE set up menu the following submenus appear: DISPLAY BASE PROGRAM • COPY BASE PROGRAM •...
- Page 16 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 5.2.3 SEND BASE PROGRAM Enter this menu to send to the BASE the ACTIVATION settings of the KEY. Base SEND PROGRAM TO BASE...
- Page 17 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 5.2.5 RESTORE THE BASE TO FACTORING SETTINGS NOTE: Be aware that all data will be erased. Enter this menu to restore the BASE to the factory settings. After about 1 minute the radio turns off and the BASE is out of reach.
- Page 18 ACMO-AVK | IOM Manuals ACMO-AVK AUTOMATIC CONTROL VALVE SERIES 879 M117 VALVE TIMER HKEY - ver. 1.6 Press the ESC button to go back to the source menu. Press the OK button twice to display the archived operations: Hystoric SHOW HISTORICAL...
- Page 20 Headquarters: Legal Office: 31056 Roncade (TV) - Italy - Via T. da Modena, 28 - Z.I. 00136 Roma - Italy - Via Franco Michelini Tocci, 93 tel +390422840220 r.a. - fax +390422840923 tel +39066628238 - fax +39066628335 info@acmospa.com inforoma@acmospa.com www.acmosrl.com...
