SICO 3 Series Owner's Manual

Tri-height stage system
Hide thumbs Also See for 3 Series:

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL: Instructions and Warnings
BEFORE YOU BEGIN...
WARNING
To avoid injury, read
and understand
these instructions
before you start to
set up the stage.
Printed in USA (11-99)
® SICO is a registered trademark of SICO Incorporated.
STAGE SYSTEM
TOOLS REQUIRED
Hex wrench (provided) to unlock decks for reversing
the surfaces -- if reversible decks were ordered.
Two 9/16-in. wrenches to attach hand rails to stair-
ways.
If you have any problems when installing,
contact SICO Customer Service at
1-800-328-6138.
TRI-HEIGHT
Series 3
Part No. 111452 Rev. A

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SICO 3 Series

Summary of Contents for SICO 3 Series

  • Page 1 If you have any problems when installing, before you start to contact SICO Customer Service at 1-800-328-6138. set up the stage. ® SICO is a registered trademark of SICO Incorporated. Printed in USA (11-99) Part No. 111452 Rev. A...
  • Page 2 INTRODUCTION Stage Configurations A Tri-Height Stage System consists of individual 4x8-ft or 6x8-ft stage sections that can be folded for storage. The stage sections are available in the following height combinations: 30 - 36 - 42 in. (762 - 914 - 1067 mm) 24 - 30 - 36 in.
  • Page 3 POSITIONING THE FIRST SECTION NOTE: Adjustable-height stage sections are shown in all illustrations. 1. Move the first section approximately to its desired location. CAUTION: When moving, push or pull from the end of the folded unit. Pulling on the crossbar along the side of the unit could un- lock the stage and allow it to open.
  • Page 4 POSITIONING THE FIRST SECTION -- continued 4. Adjustable-Height Stages. On one side of the stage section, pull out on the end leg lock crossbar. Nonadjustable-Height Stages. Discon- nect one end of the bungee cord and lower the deck locking tube to the floor. 5.
  • Page 5 INSTALLING ADDITIONAL SECTIONS 1. Move a second frame unit next to the first one. 2. Set up the second unit in the same way you did the first one. 3. Lift the edge of the second unit’s deck onto the unit-to-unit connector bracket(s) A of the first unit.
  • Page 6 ATTACHING A RAMP NOTE: SICO ramps are provided in 6-ft or 8-ft (183 or 244 cm) section lengths, with an incline of one in. per foot (83 cm per meter). Detailed instructions for attaching a ramp to the Tri-Height Stage are shipped with the ramp.
  • Page 7 ATTACHING A THREE-HEIGHT STAIRWAY -- continued To change the steps to a lower setting: NOTE: Two people are required. 1. Simultaneously pull out on the latch handles on each side of the stairway, and lower the steps until the latches are in the appropriate notch.
  • Page 8 ATTACHING A TWO-HEIGHT STAIRWAY To transport the Two-Height Stairway, tip it to the side as shown. Move the stairway to its desired location. The stairway is adjustable to either of two stage heights by installing the lock pin assembly onto the appropriate studs.
  • Page 9 ATTACHING GUARD RAILS AND BACKDROP Use platform guard rails in all Tri-Height Stage setups. These rails are availabe in 3-, 4-, 6-, and 8-ft versions. NOTE: Instructions on installing ramp guard rails are shipped with the ramp. Flat sections of ramps use the standard platform guard rails shown here.
  • Page 10 ATTACHING TABLE/CHAIR STOPS Table/chair stops are available in 3-, 4-, 5-, 6-, and 8-ft versions for locations where a platform guard rail is not used (guard rails have a built-in chair stop). To install a table/chair stop, position it on the edge of the deck as shown and firmly tighten the large knob near each end.
  • Page 11 DISASSEMBLING THE STAGE Disassemble the stage by reversing the setup procedure. 1. Remove any backdrops and closure draper- ies. 2. Remove the guard rails and table/chair stops. 3. Remove the stairway(s) by pulling down on the rings to release the deck lock pin on each side (see Page 7 or 8).
  • Page 12 To receive assistance for: - Selecting replacement parts / decals - Repairing the product - Adjusting and operating the product - Obtaining On-line assistance TELEPHONE: 1-800-424-0796 FAX: (952) 829-5141 WEB SITE: WWW.SICOINC.COM SICO AMERICA INC. 7525 Cahill Road Minneapolis, MN 55439 USA...
