- Page 2 I N S T R U C T I O N G U I D E...
- Page 3 Type C Chair Silla tipo C Chaise de type C C-Stuhl Sedia tipo C...
- Page 4 COMPONENTS Lumbar Support Cushion Seat Backrest Head Support Cushion Mechanism Gas Lift Castors X5 Gas Lift Cover Side Covers Hexkey 2*10mm M5 Small Side Cover Screw Washers 4*18mm M8 Screws Base 4*25mm M8 Screws Rubber Gasket...
-
Page 5: Mounting Steps
MOUNTING STEPS Mount the lumbar and head support cushions on the backrest Attache the backrest to Fasten the backrest with provided screws. the seat. Fasten the side covers, and put the small side cover on... - Page 6 Align the butterfly mechanism with the screw holes at the bootom of the seat as shown in image above. The Rubber Gasket Rubber gaskets can reduce the noise when the chair is in motion. You can choose whether to install it. Align the mechanism with Tighten the screws Place the rubber gasket on the screw hole...
- Page 7 Push and twist the wheels into the star base. And place the cylinder cover over the gas lift. Finish...
