Helping Hand KINGFISHER HA0680 User Manual

KINGFISHER BATHBOARD
Part No: HA0680 and HA0686 (with handle)
Max. Safe user weight 200kg (31 stone)
The King sher Bathboard is designed to make
Bathboard assembly
getting in and out of the bath easier and safer.
The Bathboard can also be used for showering.
Lay the bathboard upside down, so you can see the rotating disc.
Assembling the xing brackets to the Bathboard:
Rubber Adjuster
Buffer Knob
Fixing
Bracket
Positioning the Board in the bath:
Place the Bathboard on top of the bath with the handle and/or soap
dish on the wall side. Ensure that the area around is clean and ideally
Fixing the bathboard onto your bath
the board should be at the opposite end to the taps ( g.3).
Slide the brackets out to the side of the bath. Check the position of the
Bathboard and then tighten up each adjuster knob to lock the brackets
in place ( g.4). Take care not to overtighten the adjuster knobs.
Please ensure that the tting guide marks are over the supported
area of the bath tub sides ( g.5).
Check that the board is secure before every use.
Fitting Guide
Mark
Bromyard Road, Ledbury
Hereford HR8 1NS
sales@HelpingHand.co.uk
www.HHAdlEssentials.co.uk
Slide the foot onto the rotating disc with the locking handle facing towards the
centre of the bathboard, until it locks in place. It will only t this way round.
Four xing brackets t into outer slots on
the underside of the Bathboard ( g.1).
Repeat with the other leg and your bathboard is ready to t onto your bath.
Hold the adjuster knob on the bracket and
Fit the head of the angled bolt through
the 'D' shaped hole at the end of the slot
( g.2). ensuring that the bolt ts at onto
the shoulders of the slot, with the rubber
Fig.1
bu er facing outwards. Slide the brackets
towards the middle of the board.
Place the bathboard on top of the bath with the handle to the wall side.
Ensure that the area around is clean. Ideally the board should be at the opposite end to
the taps. Make sure the tting guides overlap the inside of the bath, see above.
Slide the foot out until it is in rm contact with the side of the bath. You may need to
adjust the angle of the foot if you are xing the bathboard in the curve of the bath.
Secure the suction cup to the bath side by pushing the locking lever down.
Lock the foot in place by attening the lever into the bathboard.
Repeat this process with the other foot.
Your bathboard is now secure and ready to use
Fig.5
The Surefoot bathboard is designed to make
getting in and out of the bath safer and easier,
it can be used for showering and bathing.
Fitting Guide
Mark
Fig.2
Fig.3
Fig.4
Adjuster Knob
