Summary of Contents for EFI AC I Series
Page 1
EFI TECHNOLOGY AC**I For ASW-NEXT Short User Manual July 2022 Technical support: asw_support@immo-tools.lt...
Page 2
” in the part name. This user manual applies to CDI units manufactured by EFI TECHNOLOGY. They can be recognized by presence of EFI TECHNOLOGY logo on the label or on the plastic casing of CDI unit. Technical support: asw_support@immo-tools.lt...
Page 3
1. How to connect? ACII / AC2I / AC5I / AC8I / AC13I / AC14I / AC21I / AC23I AC24I / AC25I / AC32I AC19I / AC20I / AC27I (also comes with black connectors with the same pin-out) Technical support: asw_support@immo-tools.lt...
Page 4
2. Software features • Read / Write internal ST7 EEPROM (if equipped) • Read / Write external SPI EEPROM • Read / Set keys To read existing and to store new desired values of transponders. Up to 4 keys can be programmed during this procedure.
Page 5
➢ You want to set / delete key(s) manually in CDI unit Press „Read /Set Keys“ button. Diagnostic connection to CDI unit will be established and transponder values will be read. Select position to set key to. Read key you want to store to CDI unit with any transponder programmer. Let‘s say you‘ve got Enter this value to the „Set / Remove key“...
Page 6
You may delete unneeded keys and set as many keys as you need (max 4): • Use „Save to text file“ to access transponder data later if no physical transponder is prepared yet. • Press „Apply changes“ button to write key programming values to control unit Please note that CDI unit will treat itself as not completely programmed with only one key stored.
Page 7
➢ You want to learn keys to the VIRGIN CDI unit • Make yourself two valid T5-11 transponders or take two ready suitable keys of TEMIC-11 / TYPE-11. To make T5-11 transponders please program to one of them, for example: BE FA 00 00 00 11 22 33 (7D 5F 00 00 00 88 44 CC)* and...
