User's Guide
CT60
Rugged
Tablet PC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Intermec CT60

  • Page 1 User's Guide CT60 Rugged Tablet PC...
  • Page 2 User Guide CT60 Rugged Tablet PC...
  • Page 3 Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. E 2003 by Intermec Technologies Corporation. All rights re- served. The word Intermec, the Intermec logo, Norand, ArciTech,...
  • Page 4: Table Of Contents

    Bottom Guide Pin Holes: Tips for Proper Use and Care CT60 Rugged Tablet PC User’s Guide ........
  • Page 5 ......Internal Flex Space for OEM modules CT60 Rugged Tablet PC User’s Guide ....
  • Page 6 Backlight Adjustment Auto Dim CT60 Rugged Tablet PC User’s Guide ........
  • Page 7 What if the Pen Still Will Not Align? If the “ Start” Button Disappears? External Peripherals Support? USB Networking In the CT60? How Can USB be Used In the CT60? CT60 Rugged Tablet PC User’s Guide ..
  • Page 8: Before You Begin

    Your safety is extremely important. Read and follow all warnings and cautions in this document before handling and operating Intermec equipment. You can be seriously injured, and equip- ment and data can be damaged if you do not follow the safety warnings and cautions.
  • Page 9 Note: Notes either provide extra information about a topic or contain special instructions for handling a particular condition or set of circumstances. viii CT60 Rugged Tablet PC User’s Guide...
  • Page 10 Before You Begin Global Services and Support Warranty Information To understand the warranty for your Intermec product, visit the Intermec web site at http://www.intermec.com, click Support, and then click Warranty. Disclaimer of warranties: The sample code included in this doc- ument is presented for reference only.
  • Page 11 Telephone Support These services are available from Intermec Technologies Corpo- ration. Service Description Factory Repair and Request a return On-site Repair authorization number for authorized service center repair, or request an on-site repair technician. Technical Support Get technical support on your Intermec product.
  • Page 12 Who Should Read this Guide? This guide provides you with information about the features of the CT60, and how to install, operate and maintain it. Before you configure the CT60, you should be familiar with basic Windows-based PC operation, and how it relates to pen computing.
  • Page 13 The CT60 Rugged Tablet PC gives you the power of a desktop computer, yet it is designed for use on foot, in a vehicle, or in an office. It is ideal for highly mobile applications in the most demanding environments.
  • Page 14: Introduction

    Standard Features Your CT60 Data Collection Tablet PC includes the following features at a minimum: S Fully sealed aluminum housing with lifetime warranty S 933 MHz Mobile Intel® Pentium® III MHz processor-M S 256 MB main memory S 512 KB L2 cache S 4 MB dedicated video memory S 10.4”...
  • Page 15: Accessories And Options

    S External 1.44 MB 3.5” bootable floppy disk drive S (USB) Keyboard(s) Note: A GPS option is sold for the sole purpose of providing and accurate and easily obtainable signal for location of equipment for time or signal synchro- nization. CT60 Rugged Tablet PC User’s Guide...
  • Page 16: Exterior Features

    It blinks as the battery charges and remains a constant green when the batteries are fully charged. The indicator identi- fies a positive connection when the CT60 is in the docking sta- tion with an external power source. The indicator will be green when external power is connected.
  • Page 17: Backlight Control Sensor

    (four to five seconds) causes an emergency forced shut down of the computer. When the CT60 is operating, the side switch will function ac- cording to the selection on the Advanced tab of the Power Op- tions.
  • Page 18: Cardbus/Pcmcia Expansion Slot

    There is a limit of 128 concurrent devices per USB port. The CT60 can supply up to 0.5 amps of current through the USB port. External USB hubs are available that will supply power to external devices without using the CT60’s power supply.
  • Page 19: External Power Connector (15 Vdc Input)

    External Power Connector (15 VDC input): This connector allows the user to plug the power supply directly into the CT60 for operation and battery charge. The CT60 may also be charged through a port replicator or docking station. Docking Connector...
  • Page 20: Hard Drive Compartment

    Operation” for instructions on changing batteries. Hard Drive Compartment: The hard drive compartment allows field upgrades or repairs without opening the CT60. Some customers may have IT De- partments trained to replace hard drives at the customer loca- tion.
  • Page 21: Tips For Proper Use And Care

    Tips for Proper Use and Care The CT60 is a hardened field computer, but it is an electronic device and reasonable precautions should be taken: S Do not subject the computer to extreme heat by placing it on the dashboard of a vehicle with the display facing the sun.
  • Page 22 This chapter outlines pen operation, battery care and use, and connectivity options for the CT60. CT60 Rugged Tablet PC User’s Guide...
  • Page 23: Hardware Operation

    The On/Off button is recessed to prevent accidentally turning the Tablet PC on or off. The CT60 performs its self-check rou- tines during the start up process. All units are configured at the factory to automatically boot to the Microsoft Windows Desk- top unless a custom-configuration has been requested.
  • Page 24 Settings tab. The CT60 utilizes a proximity-sensing electromagnetic digitizer. This component tells the computer the pen’s exact position. The computer senses the pen as it nears the display and the cur- sor appears when the pen is approximately an inch away.
  • Page 25: Battery Use And Care

    10% per month at normal temperatures. How to Install New Batteries The CT60 has the capability to run on one or two batteries in the field. It does not require both batteries to run. The two-bat- tery design allows users to hot swap batteries without turning the computer off.
  • Page 26: How To Recharge Your Batteries

    The CT60 is fully functional as it charges. Using the computer as it charges will only slightly lengthen the recharging process.
  • Page 27: When Batteries Have Finished Charging

    Settings for the display and the hard drive shutdown, as well as the use of suspend, stand-by and hibernate mode, result in lower overall drain on the battery, effectively increasing the computer’s operating time. CT60 Rugged Tablet PC User’s Guide...
  • Page 28: When To Replace Your Battery

    400-500 charge/discharge cycles for optimal battery performance. Where to Purchase Replacement Batteries The CT60 uses long lasting Li-Ion batteries that are custom made for Intermec Technologies Corporation. If you need to purchase replacement batteries for your CT60 Computer, con- tact your Intermec representative.
  • Page 29: Safety And Handling For Batteries

    Safety and Handling Considerations for Batteries To make the batteries as safe as possible, Intermec, along with approved vendors, have incorporated several built in safety fea- tures to protect the pack. The safety circuit built in your battery cannot protect against handling abuse.
  • Page 30: Disposing Of Batteries

    Disposing of Batteries The batteries used in the Intermec CT60 Computers are not considered hazardous waste by EPA regulations, however local regulations may require specific methods of disposal. We strongly encourage recycling. Tips for Best Battery Performance S Fully discharge your battery before recharging.
  • Page 31: Removable Hard Drive

    Any tampering of the hard drive will result in a void warranty. Connectivity Connectivity with the CT60 is via the docking connector on the backside of the unit. Most units ship with a port replicator, desk dock, or vehicle dock that provides standard ports for communications, key- board, and power supply.
  • Page 32: Port Replicators

    External Power: Use only the approved power supplies provided especially for the CT60, which supply the required DC power from a standard AC outlet. Keyboard: Industry standard 5 DIN PS2 style keyboard connector.
  • Page 33 The standard port replicator also doubles as a desktop stand for the CT60. Simply press the male docking connector on the port replicator into the female docking connector on the back of the unit. COM 3 or VGA Thumb Screws...
  • Page 34 External power should be connected to the port replicators after being firmly connected to the CT60. Some custom configurations provide access to ports in the computer housing. CT60 Rugged Tablet PC User’s Guide...
  • Page 35: Desktop Docking Station

    S Power connector S One USB port S One SVGA video port If the CT60 is configured with video output capabilities, one COM port can be used as a VGA port. Note: If a desk dock is equipped for network com- munication, the connection is made through the USB port.
  • Page 36: Vehicle Docking

    Security keys for fleet users are identical to eliminate logistic problems. Note:The vehicle dock cannot be installed without a base to mount it in the vehicle. Contact your Inter- mec Representative for a current list of vehicle mount providers. CT60 Rugged Tablet PC User’s Guide...
  • Page 37: Cardbus/Pc Cards

    3.3-volt cards, while 16-bit PC cards can be 5-volt or 3.3-volt. The Type III slot in the CT60 will support both Cardbus or PC cards. To insert a card, take off the hatch plate by removing the two screws that hold the hatch cover. Cards should be inserted face up (i.e.
  • Page 38: Internal Flex Space For Oem Modules

    Cardbus/PC card door and antenna op- tions, which is located on the upper left-hand side of the com- puter. CT60 Rugged Tablet PC User’s Guide...
  • Page 39 This section describes some of the features of Microsoft’s XP Tablet PC Edition software. Your screens may appear differently, depending on the software load and configuration. CT60 Rugged Tablet PC User’s Guide...
  • Page 40: Software Operation

    The Tablet PC screen display rotates almost instantly, so you can go back and forth as often as desired or needed for a specific task. CT60 Rugged Tablet PC User’s Guide...
  • Page 41 How Do I Rotate the Screen on My CT60? In the system tray, tap on the display settings icon; this will open the display properties menu. See figure below. 1 Tap Settings→Advanced→LynxEM+6 tab. 2 Tap ON under Rotation, then tap OK.
  • Page 42: Adjusting Screen Brightness

    The screen brightness is often the number one consumer of power, so you can conserve battery power by turning down the brightness on your CT60. You can adjust the default settings for both AC and DC power. When you are plugged into AC power, your screen can be at its brightest, and when you unplug your computer, your screen will automatically dim to conserve power.
  • Page 43: Handwriting Using The Input Panel

    Tap the Input Panel button on the task bar. The Tablet PC In- put Panel opens. The Writing Pad and on-screen Keyboard are shown below. To hide the Input Panel, tap the Input Panel but- ton again. The Writing Pad On-Screen Keyboard CT60 Rugged Tablet PC User’s Guide...
  • Page 44: How To Convert Handwriting

    How to Restore Default Settings in Windows Journal You can restore all Windows Journal settings to their defaults such as Pen settings, Highlighter settings, Menu and tool bar positions, Find pane, and note list pane positions and Stationery settings. CT60 Rugged Tablet PC User’s Guide...
  • Page 45 1 Tap on Start. 2 Tap on Run. 3 Type in: journal /RepairNoteWriter. 4 Tap on OK. 5 Launch the Journal application. Check in Printers to ensure Journal Note Writer is now present. CT60 Rugged Tablet PC User’s Guide...
  • Page 46: Improve Handwriting Recognition

    1 Launch Sticky Notes. The application automatically opens to a new note. 2 Start writing on the surface of the note. 3 Tap the red record button to record a voice message for a maximum of 30 seconds per note. CT60 Rugged Tablet PC User’s Guide...
  • Page 47: Use The Pen To Write

    1 On the taskbar, tap the Start button, and then Control Pan- 2 Tap Performance and Maintenance, and then tap Power Options. 3 Tap the Power Meter tab. 4 Total battery power remaining is shown under Power status. CT60 Rugged Tablet PC User’s Guide...
  • Page 48: Using Power Schemes

    Power Options in the Con- trol Panel, you can adjust individual settings of any available power scheme, or you can create your own power schemes to suit your particular system and preferences. CT60 Rugged Tablet PC User’s Guide...
  • Page 49: Standby

    The same user rights that apply to Windows XP Professional also apply to Windows XP Tablet PC Edition. Can I Reinstall or Remove One of My Tablet PC Components? Tablet PC components cannot be independently installed, re- moved, or reinstalled. CT60 Rugged Tablet PC User’s Guide...
  • Page 50: Ct60 Utilities

    — Chapter Software Operation CT60 Utilities The CT60 comes with a Utilities program that provides addi- tional functionality to your computer. To launch the Utilities program, tap on the icon found in the quick launch bar. If the icon is not found, you can launch the program by tapping on Start→All Programs→XRT Control Utilities.
  • Page 51: Advanced Backlight

    Sliding the pink line left or right will set the light level at which you want the backlight to go off. If the ambient light is greater than this setting (such as ambient light is to the right of this line) the backlight is turned off. CT60 Rugged Tablet PC User’s Guide...
  • Page 52: Auto Dim

    Note: The auto dim adjustment tab size can be ad- justed. Typing Alt-S using a keyboard allows grabbing the red line and sliding it until the desired size of the tab is reached. CT60 Rugged Tablet PC User’s Guide...
  • Page 53 At light levels lower than this, Auto dimming takes place, as represented by the sloping yellow line. This full brightness setting can be adjusted by dragging the orange line to the right or to the left. CT60 Rugged Tablet PC User’s Guide...
  • Page 54 This chapter contains some common frequently asked questions about the CT60. If you do not find an answer to your question here, please contact Technical Support at 800-755-5505 and one of our representatives will be able to help you. CT60 Rugged Tablet PC User’s Guide...
  • Page 55: Faqs

    What Options are Available for Loading Software into the CT60? S USB Floppy Drive S USB CD-ROM S Local Area Network S Direct Cable Connection How Do I Install Drivers for Peripheral Devices Sold by Intermec? Device drivers for peripherals that Intermec distributes reside on the CT60 where they can be installed as needed.
  • Page 56: If The Computer Locks Up Or Freezes

    <CTRL><ALT><DEL> function or hold the side power button for a period of 4-5 seconds to force a “hardware shutdown.” How Do I Clean the Dock Connector On the Back of the CT60? Use a non-metallic bristle brush to sweep out any dust or foreign particles.
  • Page 57 This can be done at your discretion. Windows XP also gives you the option of locking the task bar so this will not happen. Intermec highly recommends locking your taskbar if you are using Windows XP.
  • Page 58 What Do I Do When the Battery Discharges and Will Not Charge in the Computer? There are several fused circuits in the CT60 designed to protect the core electronics. In the event that the unit will not initiate the charge cycle, there may be a blown fuse in the circuit. See Battery Use and Care in Chapter 2 for more information on charging your batteries.
  • Page 59: How Can Usb Be Used In The Ct60

    How Can USB Networking Be Used In the CT60? Intermec provides desk dock and wall dock options with a USB network adapter that communicates to the CT60 via the dock- ing connection and connects to the network hub by way of stan- dard network patch cabling.
