Summary of Contents for Gopel Electronic USB 4112
- Page 1 USB/ basicCON 4112 4:1 LVDS Multiplexer User Manual (Translation of Original docu) Document version 1.1 GOEPEL electronic GmbH Goeschwitzer Str. 58/60 •D-07745 Jena + 49-3641-6896-597 • ats_support@goepel.com • www.goepel.com...
- Page 2 © 2014 GOEPEL electronic GmbH. All rights reserved. The software described in this manual as well as the manual itself are supplied under license and may be used or copied only in accordance with the terms of the license. The customer may make one copy of the software for safety purposes. The contents of the manual is subject to change without prior notice and is supplied for information only.
-
Page 3: Table Of Contents
ONSTRUCTION AND UNCTION 2.3.1 General ..............2-4 2.3.2 Hardware Initialization ..........2-4 2.3.3 Addressing ............. 2-5 2.3.4 Power Supply ............2-5 2.3.5 Connector Pinout ............ 2-5 ..............2-6 CCESSORIES G-API PROGRAMMING ..........3-1 USB 4112/ basicCON 4112 – User Manual... -
Page 5: Installation
Installation). USB 4112: The USB 4112 board can only be operated when it is installed in one of the GOEPEL electronics USB Racks USB 1004, USB 1008 or USB 1016. Please make absolutely certain that all of the hardware installation procedures described below are carried out with your system switched off. -
Page 6: River Nstallation
After driver installation/ hardware installation, you can check by the Device Manager whether the devices are properly embedded by the system. The following figure shows the successful embedding of a USB 4112 board or basicCON 4112 device: Figure 1-1: Device Manager Display Please note that the Device Manager shows all USB controllers. -
Page 7: Hardware
Hardware Hardware Definition The USB 4112 LVDS Multiplexer board with USB 2.0 Interface of GOEPEL electronic GmbH is used to distribute LVDS signals (ANSI TIA/EIA-644). The board is a 4 to 1 multiplexer for LVDS signals with a bandwidth up to 3.125 GBit/s at maximum. - Page 8 Hardware basicCON 4112 is a GOEPEL electronic GmbH stand-alone device based on a USB 4112 board to be connected directly to a PC or Laptop. It has been developed for the independent operation out of complex test systems. basicCON 4112 can be supplied via the USB interface or via the ext.
-
Page 9: Technical Data
4 HP x 100 mm x 160 mm ¨ basicCON 4112: 130 mm x 55 mm x 200 mm ¨ The dimensions given for USB 4112 (without front panel and connectors) correspond to standard dimensions in a GOEPEL electronics USB-Rack. 2.2.2 Properties... -
Page 10: Construction And Function
All boards have five HF connections at the frontal panel to connect the LVDS cables. At the rear side of the USB 4112 board there is a 132 poles backplane connector for connecting the board in a GOEPEL electronics USB Rack. -
Page 11: Addressing
(if applicable) in the order of ascending serial numbers in a GOEPEL electronics USB Rack. 2.3.4 Power The USB 4112 board is supplied via the USB Rack in that it has been installed. Supply Power supply for basicCON 4112 can be effected via the USB interface (as far as it is configured for the required current of about 500 mA). -
Page 12: Accessories
Accessories The following accessories can be delivered for USB 4112/ basicCON 4112 devices: LVDS HF connecting cable ¨ (when ordering, please state the required length and the connector type of the transmitting side) USB 4112/ basicCON 4112 – User Manual... -
Page 13: Api Programming
Please consult the G-API documentation for further information. This documentation and the installation software are located in the G-API folder on the supplied Product CD. USB 4112/ basicCON 4112 – User Manual... - Page 15 Driver Installation... 1-2 Hardware Installation ..1-1 Pinout ......2-5 Power supply ....2-5 Hardware Explorer ..... 3-1 Stand-alone Device ..2-2 Hardware Initialization ..2-4 Use ....... 2-4 USB cables ......2-3 USB 4112/ basicCON 4112 – User Manual...
