Model PROIWT Communication Interface
for
PRO PP Facemask
User Manual
1001 Corporate Lane, Suite 240
Export, PA 15632
USA
Phone: 412-856-9200
Fax: 412-856-9203
https://www.biomarineinc.com/
Document: 046121, Revision C
B5-06-6000-54-0
September 2021

Advertisement

loading
Need help?

Need help?

Do you have a question about the BIOMARINE PROIWT and is the answer not in the manual?

Questions and answers

Related Manuals for CSE BIOMARINE PROIWT

Summary of Contents for CSE BIOMARINE PROIWT

  • Page 1 Model PROIWT Communication Interface PRO PP Facemask User Manual 1001 Corporate Lane, Suite 240 Export, PA 15632 Phone: 412-856-9200 Fax: 412-856-9203 https://www.biomarineinc.com/ Document: 046121, Revision C B5-06-6000-54-0 September 2021...

  • Page 2: Table Of Contents

    Model PROIWT Communication Interface Revision: C 046121 User Manual Table of Contents Cautions and Limitations MSHA Electrical Approval Introduction Installation Communication System Use Communication System Post Use Illustrated Parts List...

  • Page 3: Cautions And Limitations

    Model PROIWT Communication Interface Revision: C 046121 User Manual Cautions and Limitations Failure to properly use and maintain this product could result in injury or death. • Never substitute, modify, add, or omit parts. Use only exact replacement parts in the configuration as •...

  • Page 4: Msha Electrical Approval

    Model PROIWT Communication Interface Revision: C 046121 User Manual MSHA Electrical Approval Innovative Wireless Technologies 1100 Main Street, Lynchburg, VA 24504 USA Model: PROIWT Permissible Communication Interface MSHA Approval No: 23-A120005-0 Tested for intrinsic safety in methane-air mixtures only. Warnings: MSHA approved for use with one of the following IWT communication systems only: Wireless Mesh Communication and...

  • Page 5: Installation

    Model PROIWT Communication Interface Revision: C 046121 User Manual Installation The PROIWT interface will install into the PRO PP facemask in place the facemask voice emitter front cover. The speaker portion of the system will clip to the lapel of the user’s shirt or to the harness of the BioPak 240R respirator.
  • Page 6 Model PROIWT Communication Interface Revision: C 046121 User Manual 3. Remove the nose cup from the circumference of the voice emitter. Do not remove the nose cup from the breathing port. Voice Emitter Nose Cup 4. Remove the voice emitter by pushing down on the release tab and pulling straight out. Warning: Do not damage the voice emitter cup of the facemask during PROIWT installation.
  • Page 7 Model PROIWT Communication Interface Revision: C 046121 User Manual 5. Install the trapezoid-shaped foam piece into the open end of the vice emitter as depicted below. Foam Insertion Foam Positioning 6. Reinstall the voice emitter into the mask making sure that the release tab fully engages.
  • Page 8 Model PROIWT Communication Interface Revision: C 046121 User Manual 7. Reinstall the nose cup around the perimeter of the voice emitter as depicted below. If the mask is fitted with a drink tube, make sure the drink tube is properly positioned as depicted. Nose Cup Installation Drink Tube Positioning...
  • Page 9 Model PROIWT Communication Interface Revision: C 046121 User Manual 8. Position the oval-shaped foam piece around the perimeter of the PROIWT microphone as depicted below. 9. Position the PROIWT interface assembly onto the speech body channel as depicted below. Verify that the rubber skirt of the mask has not been forced out of the speech channel body groove.

  • Page 10: Communication System Use

    Model PROIWT Communication Interface Revision: C 046121 User Manual 11. Prior to the using the system, leak test the facepiece to verify proper installation of the interface. Leak testing can be achieved utilizing the Biomarine PRO PP Field Test Kit, part number B6-02- 5003-43-0.

  • Page 11: Communication System Post Use

    Model PROIWT Communication Interface Revision: C 046121 User Manual Communication System Post Use At the completion of a mission, follow all instruction provided by Innovative Wireless Technologies to shut down the Innovative Wireless Technologies SENTINEL Wireless Mesh Communication and Tacking System.

  • Page 12: Illustrated Parts List

    Model PROIWT Communication Interface Revision: C 046121 User Manual Illustrated Parts List Item No. Part Number Description B6-02-5003-61-0 PROIWT Communication Interface-Complete B6-02-5003-61-1 Mask Interface Component B6-01-5000-18-0 Microphone Cable, 12” B6-01-5000-19-0 Microphone Cable, 18” B2-06-6002-87-0 Speaker & Radio Cable B2-06-6002-88-0 Optional Speaker Debris Screen (not depicted) B5-06-6000-54-0 User Manual (not depicted) B2-02-7001-93-0...
  • Page 13 Model PROIWT Communication Interface Revision: C 046121 User Manual This page intentionally left blank)
