Graphite
Instruction Manual
Graphite 5 Model GR905
Free-standing Multi Fuel Non-Boiler Stove
Published July 2014
Please note
This appliance has been
independently tested and is recommended
as suitable for use in Smoke Control Areas
when burning wood logs (see pages 12–
20). It must, at all times, be operated in
accordance with the instructions to
minimise the amount of smoke produced.
You will need to refer to the serial number
of your stove should you ever need to
make a claim under the Graphite Warranty.
You will find the serial number, beginning
with GR, on the CE plate at the rear of
the stove as well as on the lid of the outer
packaging.
Write the date the stove was delivered to
you below as this is likely to differ from the
purchase date.
-
-
www.hi-flame.com
Ref: GR905 / UK-NI-ROI / V3 18-07-14
