Avson 370-237V80 Owner's Manual

Chevrolet tahoe
Hide thumbs

Advertisement

Quick Links

Download this manual
WARNING:
CHOKING HAZARD-Small parts.
Not for children under 3 yrs.
CAUTION
Screws contain potentially
hazardous sharp points or sharp
edges. Adult assembly required.
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
ASSEMBLY INSTRUCTION
Chevrolet Tahoe
OWNER'S MANUAL
Toy must be assembled by adult before use.
To reduce the risk of injury, adult
supervision is required. Never use on road
ways, near motor vehicles, on or near steep
inclines or steps,swimming pools or other
bodies of water. Always wear shoes, and
never allow more than one rider.
WARNING:
WARNING
INfmd003_US
370-237V80

Advertisement

loading
Need help?

Need help?

Do you have a question about the 370-237V80 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avson 370-237V80

Summary of Contents for Avson 370-237V80

  • Page 1 INfmd003_US 370-237V80 Chevrolet Tahoe OWNER'S MANUAL WARNING: WARNING: CHOKING HAZARD-Small parts. Toy must be assembled by adult before use. Not for children under 3 yrs. WARNING CAUTION To reduce the risk of injury, adult Screws contain potentially supervision is required. Never use on road...
  • Page 2 Specifications: Battery： 12V/7AH*1 Motor: 35W*2 Suitable ages: Maximum weight: 25kg Speed : 1.5-3km/h Power way: Charging type Charg: 12 hours ; Use: 83 hours Use of time: Input AC -240V, 50/60Hz, output DC 12V 1000 mA Charger: WARNING 1.The pictures in this instruction is only for explaining the operation and structure of the product, when there's any difference with the real product, please confirm with the real product.
  • Page 3 STORAGE BATTERY INFORMATION AND MAINTENANCE ● Please charge hours before first time use. ● Please use the suitable adapter to charge storage battery, otherwise the ride-on will be damaged. ● Please charge the car once the speed is slower than normal, otherwise it will decrease storage battery life.
  • Page 4 PREVENT FIRE AND ELECTRIC SHOCK: - Use the only rechargeable battery and charger supplied with your vehicle. - NEVER substitute the battery or the charger with another brand. Using another battery or charger may cause a fire or explosion. - Do not use the battery or charger for any other product. Overheating, fire or explosion could occur.
  • Page 5 Charge the Battery The first charge will take about 12 hours. 1. Charge the battery directly from the 2. Take out the battery. Charge the socket near the seat. battery independently. • Plug the battery connector into the charger port. •...
  • Page 6 PART • Please identify all parts before assembly and save all packaging material until assembly is completed to ensure that no parts are discarded. • Metal parts have been coated with lubricant for protection during shipment. Wipe all metal parts with a paper towel to remove any excess lubricant. Charger Main body Steering wheel...
  • Page 7 Assembly Wheel cover lnsert the rear support and fasten with 9 Rear wheels: Assemble all the parts in sequence as screws. picture and use the socket tool to fasten. Repeat the same procedures for the other side. Washer Wheel cover (12 x 1.5mm) Plug connectors, place the steering wheel Front wheels:...
  • Page 8 Battery assembly: "Snap" the tabs on the seat into the slots Plug connectors as the picture. of the vehicle. “Snap” the tabs on the windshield into the Secure the seat by the seat lock. slots in the front top side of the vehicle. “Snap”...

  • Page 9: Operating Your Vehicle

    Operating your vehicle Power switch Switch button ON and OFF. Forward Push the shifter in upward position and press the accelerator slowly. Reverse Push the shifter in downward position and press the accelerator slowly. Low speed Vehicle has been pre-set to operate at low speed (1.5 mph,(3 km/h) maximum).

  • Page 10: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Circuit breaker tripped Circuit breaker may "trip" and stop the vehicle if it is overloaded or the driving conditions too severe. The breaker will automatically reset after approximately 10 seconds, and the vehicle will operate normally.
  • Page 11 Problem Possible Cause Solution Check all wires and connectors. Make sure that the motor harness connector Loose wire or connectors is plugged into the battery tightly, and that there are no loose wires around the motor. Circuit breaker may "trip" and stop the vehicle if it is overloaded or the driving Car was conditions too severe.
  • Page 12 Problem Possible Cause Solution A new battery should have been charged for at least 12hours before using the vehicle for the first time. After that, it must Undercharged be recharge the battery for at least 8-10 battery hours after each use. Never charge longer than 24 hours.
  • Page 13 Parts Diagram Note: Some parts shown are assembled to both sides of the vehicle. No. Part Quantity No. Part Quantity 1. Front End Assembly 9. Gear Box 2. Side Support Bracket 10.Rear Wheel Assembly 3. Front Steering Assembly 11. Rear Axle 4.
