Cudy POE300 Quick Installation Manual

4
Specifications
Model POE300
Output Voltage 53VDC
PoE Power 30W&60W max
Standard 802.3af/at/bt
Pin Polarity 1/2(-)3/6(+),4/5(+)7/8(-)
Data Rates 10/100/1000Mbps
AC Input Voltage: 100 to 240 VAC
Input Power
AC Input Current: 0.5A 100-240 VAC
Requirements
AC Frequency: 50 to 60 Hz
Dimensions 168mm x 73.5mm x 44mm
System Indicator: AC Power
Indicators
User Indicator: Channel Power
Connectors Shielded RJ-45, EIA 568A and 568B
Over current protection
Over load protection
Protection
Over voltage protection
Anti-interference protection
Operating Temperature: 0 to 40℃
Environmental
Operating Humidity:Maximum 85%
Conditions
Storage Temperature:-40 to 60℃
CE Mark Warning
This is a class B product. In a domestic environment, this product
may cause radio interference, in which case the user may be
required to take adequate measures.
EU declaration of conformity
Cudy hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of directives
2014/30/EU, 2014/35/EU, 2009/125/EC and 2011/65/EU.The
original EU declaration of conformity may be found at
http://www.cudy.com/
For support and warranty, please visit: http://www.cudy.com/.
Specifications are subject to change without notice. Cudy is a
registered trademark of Shenzhen Cudy Technologies Co., Ltd.
Other brands and product names are trademarks or registered
trademarks of their respective holders.Copyright©2020
Shenzhen Cudy Technology Co., Ltd. All rights reserved.
EU Address: Otto esser 2c, 65451 Kelsterbach, Germany
Quick Installation Guide
Model: POE300
810600065
